Master Battery MasterPower Beta RHI Series Instruction Manual

Hybrid inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Beta RHI Series Hybrid Inverter
Instruction Manual
(RHI-3P(3-10)K-HVES-5G)
Ver1.5
Master Battery, S.L.
Paseo de Extremadura, 39,
28935 Móstoles, Madrid, Spain.
Tel: +34 918 021 649
Fax: +34 917 750 542
Email: info@masterbattery.es
Web: www.masterbattery.es
Please adhere to the actual products in case of any discrepancies in this user manual.
If you encounter any problem on the inverter, please find out the inverter S/N and
contact us, we will try to respond to your question ASAP.
Master Battery, S.L.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MasterPower Beta RHI Series and is the answer not in the manual?

Questions and answers

Related Manuals for Master Battery MasterPower Beta RHI Series

Summary of Contents for Master Battery MasterPower Beta RHI Series

  • Page 1 Beta RHI Series Hybrid Inverter Instruction Manual (RHI-3P(3-10)K-HVES-5G) Ver1.5 Master Battery, S.L. Paseo de Extremadura, 39, 28935 Móstoles, Madrid, Spain. Tel: +34 918 021 649 Fax: +34 917 750 542 Email: info@masterbattery.es Web: www.masterbattery.es Please adhere to the actual products in case of any discrepancies in this user manual.

  • Page 2: Table Of Contents

    Contents 1. Introduction ………………………………………………………………………………………………………………… 1.1 Product Description ………………………………………………………………………………………………………… 1.2 Packaging ………………………………………………………………………………………………………………………… 2. Safety & Warning ……………………………………………………………………………………………………… 2.1 Safety ……………………………………………………………………………………………………………………………… 2.2 General Safety Instructions …………………………………………………………………………………………… 2.3 Notice For Use ………………………………………………………………………………………………………………………… 3. Overview ………………………………………………………………………………………………………………………… 3.1 Screen ………………………………………………………………………………………………………………………………… 3.2 Keypad …………………………………………………………………………………………………………………………………… 3.3 Terminal Connection …………………………………………………………………………………………………………...

  • Page 3: Introduction

    1. Introduction 1. Introduction 1.2 Packaging 1.1 Product Description The Beta RHI series is designed for residential hybrid systems, which can work with batteries to Please ensure that the following items are included in the packaging with your machine: optimize self-consumption. The unit can operate in both off- and on-grid modes. The Beta RHI series has 6 different models: RHI-3P3K-HVES-5G, RHI-3P4K-HVES-5G, RHI-3P5K-HVES-5G, RHI-3P6K-HVES-5G, RHI-3P8K-HVES-5G, RHI-3P10K-HVES-5G...

  • Page 4: Safety & Warning

    2. Safety & Warning 2. Safety & Warning 2.1 Safety The following types of safety instructions and general information appear in this document as WARNING: describedbelow: To reduce the risk of fire, over-current protective devices (OCPD) are DANGER: required for circuits connected to the inverter. “Danger”...

  • Page 5: Notice For Use

    2. Safety & Warning 3. Overview 3.1 Screen Beta RHI series adopts LCD screen, it displays the status, operating information and settings of the inverter. WARNING: 3.2 Keypad The RHI series does not support parallel (three- and single-phase) operation on the AC-BACKUP port. Parallel operation of the unit will void the warranty. There are four keys in the front panel of the inverter (from left to right): ESC, UP, DOWN and ENTER keys.

  • Page 6: Installation

    4. Installation 4. Installation 4.1 Select a Location for the Inverter Install on a wall or strong structure capable of bearing the weight of the machine (24kg). To select a location for the inverter, the following criteria should be considered: Install vertically with a maximum incline of +/- 5 degrees, exceeding this may cause Exposure to direct sunlight may cause output power derating.

  • Page 7: Mounting The Inverter

    4. Installation 4. Installation 4.2 Mounting the Inverter Dimensions of mounting bracket: 2. Lift up the inverter (be careful to avoid body strain), and align the back bracket on the inverter with the convex section of the mounting bracket. Hang the inverter on the mounting bracket and make sure the inverter is secure (see Figure 4.5) Figure 4.3 Inverter wall mounting Once a suitable location has be found accordingly to 4.1 using figure 4.3 and figure 4.4...

  • Page 8: Battery Terminal Components

    4. Installation 4. Installation 4.4 Battery Terminal Components 4.5 AssemblingtheACConnector Quick connector is used for battery connection. The connector is suitable for tin-plated cables There are two AC terminals and the assembly steps for both are the same. with a conductor cross section of 2.5-6mm2 (AWG14-10). TakeouttheACconnectorpartsfromthepackaging.

  • Page 9: Meter Installation

    4. Installation 4. Installation 4.6 Meter Installation Beta RHI-(3-10)K-HVES-5G series inverter integrated export power control function, this function A) Stripped the insulation sleeve of cable for 70mm, so that bared copper-cored connector reaches for 13mm. Cable through nut and sleeve of socket element, insert corresponding need connect a 3-Phase power meter for export power controlling.

  • Page 10: Communication Cable Assembly

    4. Installation 4. Installation 4.7 Communication C able Assembly 4.8 External Ground Connection The RHI series inverter uses RS485 cable to communicate with the Meter and CAN to An external ground connection is provided at the right side of inverter. communicate with the battery's BMS.

  • Page 11: Led Indicates

    4. Installation 4. Installation 4.11 Inverter Monitoring Connection The inverter can be monitored via Wi-Fi or GPRS. All Beta communication devices are optional. For connection instructions, please refer to the Beta Monitoring Device installation 1--8 RJ45 plug Correspondence between the cable s Rj45terminal and the stitch es of plug, Pin5 and Pin6 manuals.

  • Page 12: Operation

    5. Operation 5. Operation 5.2 Information In the information section, operating data and information data can be viewed. Sub-sections include: Pressing the ESC main menu 1.General Info key calls back the previous menu 2.System Info Information 3.Energy Records UP/DOWN 4.PVEnergy Records 5.BMS Info Settings 6.Meter Info...
  • Page 13 5. Operation 5. Operation Display Description Display Description Duration Duration V_DC1: Shows input 01 voltage value. V_DC1: 000.0V BattChgE Total: 10 sec 10 sec Shows the total battery charged energy. I_DC1: 000.0A I_DC1: Shows input 01 current value. 0000000kWh V_DC2: Shows input 02 voltage value. V_DC2: 000.0V BattChgE Today:...

  • Page 14: Settings

    5. Operation 5. Operation 5.3 Settings The following submenus are displayed when the Settings menu is selected: Display Description Duration 1. Set Time/Date 2. Set Address Battery V: Shows battery voltage(From BMS). Battery V: 000.0V 10 sec Battery I: +00.0A Battery I: Shows battery current(From BMS).

  • Page 15: Advanced Information

    5. Operation 5. Operation 5.4 Advanced Information 5.4.2 Warning Message The display shows the latest warn messages. NOTE: Screens can be scrolled manually by pressing the UP/ DOWN keys. To access to this area is for fully qualified and accredited technicians only. Press the ESC key to return to the previous menu.

  • Page 16: Advanced Settings

    5. Operation 5. Operation 5.4.4 Communication Data 5.5 Advanced Settings The screen shows the internal data of the Inverter, which is for service technicians only. NOTE: To access to this area is for fully qualified and accredited technicians only. 01-05: 00 00 00 00 00 Enter menu “Advanced settings”...
  • Page 17 5. Operation 5. Operation 5.5.2 Grid Switches This function is used to start or stop the generation of the inverter. Battery Select: PYLON Grid ON Grid OFF Figure 5.21 Battery Select Figure 5.19 Set Grid ON/OFF Screens can be scrolled manually by pressing the UP/DOWN keys. Overdischg SOC: 020% Press the ENTER key to save the setting.

  • Page 18: Meter Select

    5. Operation 5. Operation 5.5.5 Storage Energy Set There are two settings available in this section: Meter select and Storage Mode Select. Time Charging Mode: "Optimal Income" is the switch to turn on/off the Time Charging Mode. Customer can define the charge/discharge current as well as when to charge/dischage Meter Select the battery.
  • Page 19 5. Operation 5. Operation 5.5.6 STD.Mode Settings 5.5.8.2 Backflow Power These settings are reserved for maintenance personnel and technicians. Determine the allowed backfeed power. (System export to the grid) Do not change anything without instructions. Selecting “STD Mode. Settings” displays the sub-menu shown below: Backflow Power +0000W 1.

  • Page 20: Afci Function

    5. Operation 5. Operation 5.5.12 Compensation Set 5.6 AFCI function This function is used to calibrate inverter output energy and voltage. Inverters have the built-in AFCI function which can detect the arc fault on the DC circuit and shut down the inverter to prevent a fire disaster. Two sections are included: Power Parameter and Voltage Parameter.

  • Page 21: Commissioning

    6. Commissioning 7. Troubleshooting 6.1 Preparation of Commissioning Beta RHI Series inverter does not require any regular maintenance. However, cleaning the heatsink Ensure all the devices are accessible for operation, maintenance and service. Check and confirm that the inverter is firmly installed. will help inverter dissipating heat and increase the lifetime of inverter.
  • Page 22 7. Troubleshooting 7. Troubleshooting When faults occur, the “Fault” state will be shown on the main screen. Alarm Message Failure description Solution Follow the steps below to check what fault occurs. 1. Check if there’s arc in PV connection ARC-FAULT ARC detected in DC circuit Steps: Enter →...
  • Page 23 7. Troubleshooting 7. Troubleshooting Alarm Message Failure description Alarm Message Failure description Solution Solution 1. Check inverter inductor connection. OV-DC01/02/03/04 Over DC voltage 1. Reduce the module number in series. UN-BUS01/02 Under DC bus voltage 2. Check driver connection. 1. Restart inverter. Under grid frequency UN-G-F01/02 1.

  • Page 24: Specifications

    8. Specifications 8. Specifications Technical Data RHI-3P3K-HVES-5G* RHI-3P4K-HVES-5G* Technical Data RHI-3P3K-HVES-5G* RHI-3P4K-HVES-5G* Input DC (PV side) Output AC(Back-up) Recommended max. PV power Rated output power 4800W 6400W Max. input voltage Peak apparent output power 1000V 10000VA, 60 sec 10000VA, 60 sec Rated voltage 600V Back-up switch time...
  • Page 25 8. Specifications 8. Specifications Technical Data RHI-3P3K-HVES-5G* RHI-3P4K-HVES-5G* Technical Data RHI-3P5K-HVES-5G RHI-3P6K-HVES-5G Input DC (PV side) General data Dimensions(W/H/D) Recommended max. PV power 535*455*181mm 8000W 9600W Weight 25.1kg Max. input voltage 1000V Topology Transformerless Rated voltage 600V Self consumption (Night) <7 W Start-up voltage 160V...
  • Page 26 8. Specifications 8. Specifications Technical Data RHI-3P5K-HVES-5G RHI-3P6K-HVES-5G Technical Data RHI-3P5K-HVES-5G RHI-3P6K-HVES-5G Output AC(Back-up) General data Rated output power Dimensions(W/H/D) 535*455*181mm Peak apparent output power Weight 25.1kg 10000VA, 60 sec 12000VA, 60 sec Back-up switch time < 40ms Topology Transformerless Rated output voltage Self consumption (Night) <7 W...
  • Page 27 8. Specifications 8. Specifications Technical Data RHI-3P8K-HVES-5G RHI-3P10K-HVES-5G Technical Data RHI-3P8K-HVES-5G RHI-3P10K-HVES-5G Input DC (PV side) Output AC(Back-up) Recommended max. PV power Rated output power 12800W 16000W 10kW Max. input voltage Peak apparent output power 1000V 16000VA, 60 sec Rated voltage 600V Back-up switch time <...

  • Page 28: Appendix

    8. Specifications 9. Appendix 9.1 Grid standard selection guide Technical Data RHI-3P8K-HVES-5G RHI-3P10K-HVES-5G NOTE: General data Please check if the grid code setting comply with local requirement. Dimensions(W/H/D) 535*455*181mm Weight 25.1kg Topology Transformerless For different countries and regions, corresponding grid code needs to be selected in the Self consumption (Night) <7 W inverter LCD to meet the requirements of local network provider.
  • Page 29 9. Appendix Code in LCD Country/Region Comments G98 NI North Ireland For North Ireland Low Voltage Grid <16A G99 NI North Ireland For North Ireland Low Voltage Grid >16A User-define Customized Protection Limits Gen50 Generator Connected, Frequency-Derating, 50Hz Gen 60 Generator Connected, Frequency-Derating, 60Hz East Denmark For East Danish low voltage grid...

This manual is also suitable for:

Rhi-3p3k-hves-5gRhi-3p4k-hves-5gRhi-3p5k-hves-5gRhi-3p6k-hves-5gRhi-3p8k-hves-5gRhi-3p10k-hves-5g
