Wayne-Dalton 3973C Instruction Manual

3 r Bu't
itter
Wayne-Dalton CorP.
PO Box 67 Mt HoPe,0H 44660
(BBB) 827-3667
www wayne-dalton.com
Model No,3973C
WARNING! DURING PROGRAMMING
THE GARAGE DOOR MAY OPERATE KEEP PEOPLE AND OBJECTS CLEAR OF THE MOVING DOOR T(
PREVENT
DOOR DAMAGE OR POSSIBLE
PERSONAL INJURY.
Transmitter Programming
NSTE: Any of the three transmitter
buttons can be programmed
to activate the door. In multi-door
installations,
each button or a combir
buttons prrf,rd at the same time can be programmed to activate a separate
door. 0nly one button at a time (per-transmitter)
can be prog
activate a door
To program the transmitter:
t. ilace the emergency disconnect
handle in the manual door operated
position. This is for safety reasons.
2. press prggram button on DoorMaster'"
light fixture idrive@,
Prodrive'" Quantum@
or Classic drive@ opener,
LED will tighi or rdrive@
opener will beep once indicating
that it is ready to learn a transmitter,
3. Wlthin 30 seconds,
press and hold the desired transmitter button(s);
LED will turn off or idrive@
opener will beep once, 0n the DoorMt
release the transmitter
button and press again LED will light briefly then turn off
4. Return the emergency
disconnect
handle to motor operated positton.
5. Press same tranmitter
button(s)
again; door should operate.
. . . $ t a r -
.
ir-ansmitter
is now programmed to operator,
N0TE: idrive@
model only:The rirst.transmitter
command after prograrnming
will only open the door through a six inch up/down cycle Normal door
--t'/
<6
V
Battery: Failure of opener to respond to transmitter
rnay be due to weak or dead battery, Replace the battery.'To
change the battery ins
the coin slot and tnirito accesst'he
battery compartment.
The transmitter
uses (1) GR2016 battery, Install fresh battery with the positiv
z2ti.sr,,rfacing
uO Snap top case"half
onto bottom case half Dispose of dead battery properly,
^/I\
WARNING! FIRE AND BURN HAZARD DO NOT RECHARGE,
DISASSEMBLE
HEAT, OR INCINERATE
KEEP BATTERY
OUT OF THE
(i'
CHILDREN INSTALL
BATTERY CORRECTLY
DISPOSE
OF USED BATTERIES
PROMPTLY
^7 ! \WARNINc! tF SWALLoWED,
CoNTACT PHYSICIAN
IMMEDIATEIY,
U
NoTE: The idrive@
and DoorMasterrM
opener can be actrvated
by up to six remote control devices (including wall station and keyless entr
if a seventh control is programmed,
the first of the programmed
controls will be overridden
and will no longer activate the operator To cle
programming of all remote control devices,
press and hold the DoorMaster"
lightfixture
program button, idrive@
opener progrann button
appioximatety
ten seconds. When the DoorMaster'*
status LED goes out oi idrrve@
opener beeps three times, then all controls are erase(
NoTE: The prodriverM,
Quantum@ and Classicdrive@
opener can be activated
by up to B remote transmitters,
2 wall stations and 2 keylel
gth remote is programmed the first remote programmed
will be lost from memory.
The same is true if a third wall station or a third keyles
prggrammed,
thejirst will no longer be in membry and will not operate the opener To clear the programming of all remote control devicer
ioti tne prodrive", guantum@
or Classic drive@
opener prograrn button for approximately
ten seconds,
When the Prodrive@, Quantum@,
(
status LED goes out, then all controls are erased,
,1\
WARNING! NEVER LET CHILDREN OPERATE
OR PLAY WITH DOOR CONTROLS KEEP REMOTE CONTROLS
AWAY FROM CHILD
1|!.]} INJURY
COULD RESULT
SHOULD
A CHILD BECOME TRAPPED
BETWEEN
THE DOOR AND THE FLOOR
WARNING! ALWAYS KEEP MOVING DOOR IN SIGHT AND AWAY FROM PEOPLE AND OBJECTS UNTIL IT IS COMPLETELY
CLOSED TO
.]fRE-VENI;i.SER,I,0.U&NJURY
OR DEATH AVOtD STANDTNG
rN THE,QREN,
D00FW4Y 0R WALKING THR0,UGL"I,THE DOORWAY
WH1LE D00R I
MOVING
- a r ' q e . - r a n s m i t f : '
i]utlon
--
idrrve@
Torsion
ogfarn DUIIon
idriveo
Torquelvlasier
program button
Copyright 2007 WaYne-Dalton
CorP
P/N 300623
{r4li!+-,
Rev. 4 51112007
