MCS IUMI
Renusol Europe GmbH
EN | Read these installation instructions carefully before starting the installation!
Piccoloministraße 2
Only competent, qualified persons are allowed to carry out the installation!
51063 Köln /Cologne
Deutschland / Germany
MCS Linking
Solar Mounting System name:
Solar Mounting Reference number:
Mounting System Type:
Designed for:
Designed to Mount:
Permissible solar panel dimensions:
1/8 | Renusol Europe GmbH | MCS IUMI VS+ RH1 v01 | DOC_REN_RH1_01 | 29.07.2024 - Version: 1.6
| VS+ |
RH1 V01
VarioSole, VarioSole+ / VS+ (with RH1 Roof Hook)
REN_RH1_01
Above Roof
Pitched Roof 22.5°-65° - Single lap interlocking roman tile
Solar PV - Portrait
min: 1500x900x30 mm up to max: 2093x1134x50 mm
Contact informations:
E-Mail: info@renusol.com
Phone: 0221-788707 - 0
https://www.renusol.com/en/contact
Advertisement
Related Manuals for Renusol MCS IUMI VS+ RH1 V01
Summary of Contents for Renusol MCS IUMI VS+ RH1 V01
- Page 1 Pitched Roof 22.5°-65° - Single lap interlocking roman tile Designed to Mount: Solar PV - Portrait Permissible solar panel dimensions: min: 1500x900x30 mm up to max: 2093x1134x50 mm 1/8 | Renusol Europe GmbH | MCS IUMI VS+ RH1 v01 | DOC_REN_RH1_01 | 29.07.2024 - Version: 1.6...
- Page 2 Please check the structural integrity of the building. The building must be able to bear the additional loads imposed by the PV system. 2/8 | Renusol Europe GmbH | MCS IUMI VS+ RH1 v01| DOC_REN_RH1_01 | 29.07.2024 - Version: 1.6...
- Page 3 60x38x4800 mm Clamp+ (black) Connector number Dimension R400531 41x35 mm R400532 50x37 mm R400533 60x38 mm SIT 30 13 mm (TX 30) 3/8 | Renusol Europe GmbH | MCS IUMI VS+ RH1 v01 | DOC_REN_RH1_01 | 29.07.2024 - Version: 1.6...
- Page 4 Place the roof hook in the correct position in order to mark the cut-out on the tile Notch the tile to create space for the roof hook arm 4/8 | Renusol Europe GmbH | MCS IUMI VS+ RH1 v01| DOC_REN_RH1_01 | 29.07.2024 - Version: 1.6...
- Page 5 62 mm. Compatible module thickness: 30 mm to 50 mm. Compatible module thickness: 30 mm to 50 mm. 5/8 | Renusol Europe GmbH | MCS IUMI VS+ RH1 v01 | DOC_REN_RH1_01 | 29.07.2024 - Version: 1.6...
- Page 6 Attach the rail with a torque of 15 Nm 15 Nm Side view: Click the clamp foot into the rail channel 90° x > 35 mm 6/8 | Renusol Europe GmbH | MCS IUMI VS+ RH1 v01| DOC_REN_RH1_01 | 29.07.2024 - Version: 1.6...
- Page 7 Compatible module thickness: 30 mm to 50 mm. Maximum end clamp position on cantilevered section of rail 265 mm (module edge to fixation) 10 Nm 7/8 | Renusol Europe GmbH | MCS IUMI VS+ RH1 v01 | DOC_REN_RH1_01 | 29.07.2024 - Version: 1.6...
-
Page 8: General Installation Instructions
The mounting system may be dismantled by following the steps in the installation manual in reverse order. 8/8 | Renusol Europe GmbH | MCS IUMI VS+ RH1 v01| DOC_REN_RH1_01 | 29.07.2024 - Version: 1.6...
