Sustainable Solutions Fluid F4013 Installation Instructions

Free standing tub filler

Advertisement

Quick Links

Limited Lifetime Faucet Warranty
Fluid
warrants its faucets to be free from defects in material and workmanship for as long as the
original consumer/purchaser/owner owns his or her home.* Plastic and rubber components are war-
rantied for a period of two years. This warranty applies only to original installation locations. If a defect
is found in normal residential use, Fluid
will, at its election, repair, provide a replacement part or
product, or make the appropriate adjustment.
Fluid
reserves the right to examine the product in question and its installation prior to replacement.
This warranty is limited to replacement of defective parts only. Damage to a product caused by
accident, improper installation, misuse or abuse, improper care of nishes, hard water or mineral
deposits, potassium or salt based water softener systems or exposure to corrosive materials is not
covered by this warranty. Improper care and cleaning will void the warranty.** Replacement parts
can be obtained from your local dealer or directly from the Fluid
apply). Dated proof of purchase must accompany all warranty claims. This warranty applies only to
Fluid
faucets installed in the United States of America, Canada or Mexico (North America).
Fluid
recommends using a certi ed plumber for faucet installation and repair. Incidental and con-
sequential damages, labor charges, repair or replacement costs are expressly excluded. In no event
shall the liability of Fluid
exceed the purchase price of the faucet. Some states and provinces do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitation may
not apply to you. This warranty gives you speci c legal rights which vary from state/province to state
/province. If you nd any such problem with your product, please immediately contact your nearest
Fluid
dealer or sales representative.
Need Help?
For additional assistance
Toll Free: 1 800 460 7019
Fax: 1 604 430 5050
help@sustainablesolutions.com
www.sustainablesolutions.com
* Two year warranty on commercial applications.
** Never use cleaners containing abrasive cleansers, ammonia, bleach, acids, waxes, alcohol, solvents
or other products not recommended for surface nishes. This will void the warranty.
This product meets or exceeds the following standards:
ASME A112.18.1 / CSA B125.1
This product has been tested and certi ed by IAPMO.
IAPMO LISTED
warehouse, (shipping charges may
Sustainable Solutions
Phone: 1 800 460 7019
www.SustainableSolutions.com
TM
Installation Instructions for
Free Standing Tub Filler
Do not complete and cover over concealed base
installation until it has been fully water pressure
tested for any leaks.
Please Keep This Manual For Future Reference

Advertisement

loading
Need help?

Need help?

Do you have a question about the Fluid F4013 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sustainable Solutions Fluid F4013

  • Page 1 This product has been tested and certi ed by IAPMO. Do not complete and cover over concealed base installation until it has been fully water pressure tested for any leaks. Sustainable Solutions Phone: 1 800 460 7019 www.SustainableSolutions.com IAPMO LISTED...
  • Page 2 Recommended Installation Layout Technical Information Min: 7-7/8” 200 mm Min: 3-1/8” 80 mm Flow Rate: Spout Flow Rate: 6 gpm (22 lpm) at 45 psig Hand Shower Flow Rate: 1.8 gpm (6.8 lpm) at 60psig Operation Pressure: 20 - 80 psig Cold &...
  • Page 3 Tools Required for Installation Concealed Base Installation Instructions for Concrete Floor Te on Tape Screw Driver NOTE: Plan out the proper location of free standing tub ller. Adjustable Wrench Allen Wrench Mark the location of 4 mounting bolts for the concealed base on the mounting Drill with proper drill bit oor and ensure that the nished oor is set in the depth between the MIN of 70mm and the MAX of 100mm from the bottom of the concealed base.
  • Page 4 Tools Required for Installation Faucet Installation Instructions Lift and remove the top plastic cover. Screw Driver Te on Tape Use the supplied 8mm H8 Allen wrench to remove the plastic seal plugs, and discard. Use the supplied 5mm H5 Allen wrench to untighten the 4 screws and Adjustable Wrench Allen Wrench (Supplied) remove the mounting plate.
