- Page 1 Manual 2 Hp Dust collector Applies for: Code Model 103165 COPO-2 COPO-2 Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
List of parts Assembly Keep this manual for future references. Parts The illustrations in this manual are for reference only. They might be different from the real tool. Startup Maintenance Troubleshooting Notes Authorized Service Center Warranty policy COPO-2 ENGLISH... -
Page 3: Technical Data
Technical data COPO-2 Code 103165 Description Dust collector Voltage Frequency 127 V 60 Hz Power 2 Hp Bag capacity Inlet port 40.6 gal 4” Air volume 1 500 CFM (2 550 m Collects up to 3 microns Maximum motor speed... -
Page 4: General Safety Warnings For Electrical Tools
General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For The Use Of A Dust Collector
Safety warnings for the use of a dust collector Hazardous materials While operating the equipment WARNING • Do not vacuum or use the equipment CAUTION • Keep away from openings and moving near flammable liquids, gases, or explosive vapors such as parts: hair, loose clothing, fingers, and any other body gasoline or other fuels, lighter fluid, hot liquids, cleaners, parts. -
Page 6: List Of Parts
List of parts • Unpack the equipment and check for any damage during transportation. • Clearly identify the individual parts as shown in the parts list. 1. Hanger. 2. Bracket (4). 3. Vacuum hood. 4. Motor. 5. Keyed switch. 6. Upper bag (filter). 7. -
Page 7: Assembly
Assembly • Assemble the equipment in the location where it will be operated, on a well-leveled floor capable of supporting its weight. The space should have good lighting and ventilation. • There should be adequate ventilation and illumination in the area. Wheel assembly •... - Page 8 Assembly Components • Carefully stand the equipment upright. • Secure the double inlet (A) to the bottom of the suction bell, under the motor, using the four Phillips head screws. • If a single hose is required, install the cap (B) on either of the two inlets.
-
Page 9: Parts
Parts Filter Motor Safety switch Dust collector Power hood cord Collector Hose Double connector with cap Base Bracket Wheels Second hose (optional) ENGLISH... -
Page 10: Startup
Start Up Operation • Position the dust collection on a flat, level surface next to the dust-producing machine. • Connect the collector hose to the dust-producing machine using a hose clamp. Use a 4” to 2 1/2” (not included) adapter if necessary. •... -
Page 11: Troubleshooting
Troubleshooting Problem Cause Solution The motor doesn´t 1. Defective plug, cord, switch, or motor. 1. Check the wiring, replace the faulty parts. work. 2. Burnt fuse or circuit breaker. 2. Check the fuse or switch, replace them if necessary. Excessive dust in the 1. -
Page 12: Notes
Notes ENGLISH... -
Page 13: Authorized Service Center
In the event of any problem contacting a Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800-018-7873 to get information about the nearest Service Center. DE TODO PARA LA CONSTRUCCIÓN FIX FERRETERÍAS... -
Page 14: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
