- Page 1 RAZER LAPTOP COOLING PAD MASTER GUIDE F O R G AM E RS . BY G A ME R S . ™...
- Page 2 Stay smooth when things heat up with the Razer Laptop Cooling Pad – a smart stand that dynamically controls fan speeds based on your laptop’s temperature. Featuring an airtight pressure chamber, customizable fan curves, and a 3-port USB A hub for maximum connectivity, give your laptop the boost it needs to run at its best.
-
Page 3: Table Of Contents
2. WHAT'S NEEDED ............................ 4 3. LET'S GET YOU COVERED ........................5 4. GETTING STARTED ..........................6 5. USING THE COOLING PAD ........................9 6. CONFIGURING YOUR RAZER LAPTOP COOLING PAD ................11 7. SAFETY AND MAINTENANCE ........................26 8. LEGALESE ..............................28 ™... -
Page 4: What's Inside
1. WHAT'S INSIDE ▪ Razer Laptop Cooling Pad USB Type A connector Fan speed button (remappable) Power port Power button USB Type A ports Anti-slip rubber pads Magnetic frame slot* Fan cover 140 mm High-velocity fan Intake mesh air filter... -
Page 5: What's Needed
PRODUCT REQUIREMENTS ▪ 14 to 18-inches laptop † ▪ USB Type A port ▪ AC power outlet RAZER SYNAPSE REQUIREMENTS ▪ Windows® 10 64-bit (or higher) ▪ Internet connection for software installation † For the full compatibility list, visit: support.razer.com ™... -
Page 6: Let's Get You Covered
3. LET'S GET YOU COVERED Register your product and score exclusive benefits razerid.razer.com/warranty Your product’s serial number can be found here. ™ F O R G AM E RS . BY G A ME R S . -
Page 7: Getting Started
Optimize cooling performance by using the appropriate frame for your laptop. Frame A Frame B Frame C For Razer Blade 14 / 15 / 16 For Razer Blade 17 / 18, OR For laptops without other laptops over 15.6” bottom ventilation other laptops over 14”... - Page 8 laptops, ensure the support setting and selected frame match your laptop’s design. Cooling performance may vary depending on the specific laptop model size, and internal components. Cooling results may differ based on environmental conditions, laptop configuration and usage. 2. Connect the cooling pad to any of the USB ports on your system. Type A 3.
-
Page 9: Organizing Cables
Press Install Razer Synapse when prompted or download its installer from razer.com/synapse begin customizing your cooling pad’s lighting and cooling modes. ORGANIZING CABLES When connecting the cooling pad to your laptop, make sure that the cables are neatly routed underneath the pad to keep them organized. -
Page 10: Using The Cooling Pad
5. USING THE COOLING PAD POWER ON/OFF Press the Power button to power on or off the cooling pad. Press ADJUSTING THE FAN SPEED Press the Fan speed button to switch between available fan speeds on the cooling pad. > MEDIUM >... - Page 11 Additional Chroma lighting options can be accessed via the Razer Synapse app. When the cooling pad is connected to a system with Razer Synapse installed, the lighting will sync with your laptop’s standby mode, turning off and on, and resuming previous settings when exiting standby.
-
Page 12: Configuring Your Razer Laptop Cooling Pad
All features listed here are subject to change based on the current version, connected device(s), and supported add-ons. SYNAPSE TAB The Synapse tab is your default tab when you first launch Razer Synapse. Use the following buttons below to navigate the user interface: Minimize Clicking this button will minimize the app to the taskbar while it runs in the background. - Page 13 This button expands the browser window to fill the entire screen. To restore the window to its original size, click the maximize button again. Close This button will close all relevant tabs and terminate the application completely. Previous Tab Clicking this button will return you to the last tab you have visited. Next Tab Clicking this button will move you to the next page if you’ve recently used the Previous Tab button.
- Page 14 Dashboard The Dashboard subtab is an overview of your Razer Synapse, where you can access all your Razer devices, modules, and online services. Gamer Room The Gamer Room subtab shows all devices with the Razer Aether Light feature. From here, you can view and manage your Gamer Room-supported devices.
- Page 15 Synapse Override This section allows you to select and customize your device’s lighting and make it react to Chroma- enabled games and Chroma Connect apps using Razer Synapse. Controlled By Gamer Room App This section displays all supported devices controlled remotely by the Gamer Room app.
- Page 16 The Modules subtab displays all installed and available modules for installation. Global Shortcuts Bind operations or Razer Synapse functions to custom key-combinations from any Razer Synapse- enabled device inputs, which apply across all device profiles. Only Razer Synapse-enabled device inputs will be recognized.
- Page 17 LAPTOP COOLING PAD The LAPTOP COOLING PAD tab is the main tab for your Razer device. You can view your system’s current CPU and GPU status, and change device settings such as fan speed, button assignments, and lighting. Any changes under this tab will be saved automatically to your local system and cloud storage.
- Page 18 Profile Profile is a data storage system that keeps all your Razer peripheral settings. By default, the profile name is based on your system’s name. Clicking the dropdown bar ( ) will display all profiles for this device so you can quickly switch between them.
- Page 19 This option enables you to return the button to its original setting. Keyboard Function This option changes the button assignment into a keyboard function. You can also choose to enable Turbo mode, which allows you to emulate repeatedly pressing the keyboard function while the button is held down.
- Page 20 Switch Chroma Effect allows you to easily switch between all Chroma Effect Profiles in Chroma Studio. This function will only be visible when the Chroma Studio module is installed. Razer Hypershift Setting the button to Razer Hypershift will allow you to activate Hypershift mode if the button is held down. Launch Launch Program lets you open an app or a website using the assigned button.
- Page 21 ▪ Mute Volume - Mutes the audio. ▪ Mic Volume Up - Increases the microphone volume. ▪ Mic Volume Down - Decreases the microphone volume. ▪ Mute Mic - Mutes the microphone. ▪ Mute All - Mutes both microphone and audio output. ▪...
- Page 22 Lighting The Lighting subtab enables you to modify your Razer device’s light settings. Brightness You can turn off your Razer device’s lighting by toggling the Brightness option or increase/decrease the luminance using the slider. Switch Off Lighting This is a power saving tool which allows you to disable your device’s lighting in response to your system’s display turning off.
- Page 23 The lighting will scroll in the Select a wave direction direction selected If you have other supported Razer Chroma-enabled devices, you can synchronize their quick effects with your Razer device by clicking the Chroma Sync button ( Advanced Effects The Advanced Effects option allows you to choose a Chroma Effect Profile you want to use on your Razer Chroma-enabled peripheral.
- Page 24 You can also sort apps based on alphabetical order, last played, or most played. Apps will still be listed here, even if not linked to a Razer device. To add an app that is not listed on the screen, you can...
- Page 25 Selecting the Reset button will reactivate all tutorials that help you acquaint yourself with Razer Synapse’s features. Profile Migration Move all your connected Razer Synapse 3 Profiles, Macros, and Chroma effects to the New Razer Synapse. ™ F O R G AM E RS . BY G A ME R S .
- Page 26 This option lets you change the display language of Razer Synapse. About The About section shows the current software version, displays the copyright statement, and provides relevant links for Razer’s terms of use. You may also use this option to quickly access Razer’s social communities. ™...
-
Page 27: Safety And Maintenance
7. SAFETY AND MAINTENANCE SAFETY GUIDELINES To achieve maximum safety while using your Razer Laptop Cooling Pad, we suggest that you adopt the following guidelines: Don’t take apart the device, and don’t attempt to operate it under abnormal current loads. Doing so will void your warranty. - Page 28 For thorough cleaning, remove the fan cover and mesh air filter, then use compressed air, a soft brush, or cloth to remove dust or debris from the device, fan, and filter as needed. Once clean, reattach both the filter and cover. CAUTION: The fan cover and mesh air filter should only be removed for maintenance purposes.
-
Page 29: Legalese
Product. In no event shall Razer's liability exceed the retail purchase price of the Product.
