Enpress ONE E3-M Installation And Operation Manual

Hide thumbs Also See for ONE E3-M:

Advertisement

Table of Contents

DISTRIBUTED BY:
INSTALLATION AND OPERATION MANUAL
METERED ENPRESS BYPASS SOLUTIONS
FOR PIONEER
Pb AND PIONEER
As
®
®
This manual should be kept for future reference. If you have any questions regarding your water lter,
contact your local dealer, OEM, or the manufacturer at the following:
ENPRESS, LLC. // 34899 Curtis Blvd., Eastlake Ohio 44095 // Phone: 866.859.9274
// Fax: 440.510.0202 // info@enpress.com
EPA Est. 092577-OH-001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONE E3-M and is the answer not in the manual?

Questions and answers

Related Manuals for Enpress ONE E3-M

Summary of Contents for Enpress ONE E3-M

  • Page 1 This manual should be kept for future reference. If you have any questions regarding your water lter, contact your local dealer, OEM, or the manufacturer at the following: ENPRESS, LLC. // 34899 Curtis Blvd., Eastlake Ohio 44095 // Phone: 866.859.9274 // Fax: 440.510.0202 // info@enpress.com...

  • Page 2: Where To Install

    WHERE TO INSTALL CITY WATER INLET WATER METER GROUNDED & UNSWITCHED 115 - VOLT OUTLET GROUND STRAP PRESSURE TANK RELIEF VALVE MUST BE INSTALLED SERVICE PUMP WELL INLET A ratio of 1:3 silica vs total hardness will maintain silica in solution and optimize performance. PIONEER As —...

  • Page 3: Parts Diagram

    CT-PCBBOARD-NONWIFI-V2 TEFLON TAPE THREADS DO NOT OVERTIGHTEN ONE E3-M Power Supply CT-PIONEERPOWERSUPPLY DRAIN VALVE ONE E3-M 10' Power Extender CT-POWEREXTENDER10 LED REPLACEMENT NOTIFICATIONS EASY FILTER REPLACEMENTS WITH NO TOOLS REQUIRED EASY TO UNDERSTAND LED REPLACEMENT NOTIFICATIONS E3-M uses state-of-the-art snap ring technology to eliminate the need for cumbersome tools.
  • Page 4 ASSEMBLY INSTRUCTIONS STEP 1: TANK ASSEMBLY (SEE DIAGRAM ON PREVIOUS PAGE) STEP 1A Wrap #9 (Drain Valve Assembly) with three clockwise wraps of Te on tape. Install/thread ® #9 (Drain Valve Assembly) into #3. HAND-TIGHTEN ONLY. STEP 1B Connect #3 to #2 on the bottom of Filter Housing #1. The threaded Drain Valve Assembly should be on the inlet side (right side) at the bottom of the tank.

  • Page 5: Installing The Cartridge

    INSTALLING THE CARTRIDGE STEP 2: REMOVING THE TOP CAP STEP 2A Unseat the snap ring by pushing down on the top cap with both hands. Remove the ring by taking the handle and pulling inward, then upward; the ring should slide completely out. STEP 2B Remove the snap ring on the top of the tank, then remove the top cap from the housing assembly.

  • Page 6: Replacing The Cartridge

    REPLACING THE CARTRIDGE Turn off the water supply to the system by shutting off the inlet and outlet valves on the bypass. (Optional) Install a 3/8" PEX tubing hose to the provided tting and shut-off that connects to the inlet side of the ltration system.

  • Page 7: Contents Of Box

    Filter Housing Vertical Elbows (2) In/Out Head w/ Filter Adapter 2.5" Inlet Cap Drain Valve Assembly Contents of the box you receive will vary depending on your order. If you have questions or concerns, please contact ENPRESS, LLC at 866.859.9274.
  • Page 8 Micron Rating and Flow Rate of Lead and PFOA/PFOS Odor Reduction Capacity^ Drop Spec ONE E3-M System and PIONEER Pb Filter ® >300,000 gallons @ 15 GPM (1,135,533 Liters @ 56.8 lpm) with greater than 90% 8 GPM (30.2 lpm)
  • Page 9 The arsenic removal component of this system must be replaced at the end of its useful life of 125,000 gallons. The replacement component, CT-5020- 0640RD-F11, can be purchased from the original source of this system (retailer or distributor), from other sources of this treatment system, or directly from the manufacturer at www.enpress.com or (440) 510-0108.
  • Page 10 WATER TOTALIZER NOTIFIER The overall purpose of this device is to receive a water meter input and totalize the amount of water that passes through the meter. When there is ow through the water meter, the lights ash at a rate that increases with the water ow rate. When the total amount of water owed reaches within 10% of a pre-selected amount, the totalizer turns yellow.

  • Page 11: Warranty

    • The warranty provided herein applies only when used within the product speci cations and service life from the date of installation, beyond which ENPRESS LLC is absolved of any and all liability for any use of the product.
  • Page 12 All information contained herein is the property of ENPRESS LLC. ENPRESS LLC makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and tness for a particular purpose. ENPRESS LLC shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

This manual is also suitable for:

Cta0840bbbkp5-06l00
