Summary of Contents for Dracal Technologies BAR20-N
- Page 1 User Manual BAR20-N USB Precision Barometer with NMEA Output Model name Part number Description USB-BAR20-N 601027 USB precision barometer with NMEA output HS code: 9025.80.15.00...
-
Page 2: Table Of Contents
6 Installation and Setup 7 Usage Guidelines and Applications 8 Care, Storage, and Recalibration 8 Troubleshooting Guide and Support 9 Return Process and Warranty Information 9 Accessories and Peripherals 9 Disassembly and Environmental Considerations 10 Document Revision History Dracal Technologies Inc. -
Page 3: Compliance Certification
It is available upon request to the relevant authorities. Signed for and on behalf of: Dracal Technologies Inc., January 2024 Ariane Garon President Dracal Technologies Inc. BAR20-N – USB Precision Barometer with NMEA Output... -
Page 4: Overview
*OpenCPN, Expedition, and other trademarks mentioned on this page are the property of their respective owner(s). Neither Dracal Technologies Inc. nor any software programs or other goods or services offered by Dracal Technologies Inc. are affiliated with, endorsed by, or sponsored by the owners of those trademarks. -
Page 5: Product Overview And Specifications
(1 to 120 kPa) and boasts a high-resolution ADC (24-bit) that can detect the slightest atmospheric pressure changes. Transmitting data to your computer over USB, the BAR20-N appears as a serial port (Virtual COM port) and provides atmospheric pressure readings at 1-second intervals using MDA and XDR NMEA sentences. -
Page 6: Safety Guidelines
TIP: As for any precision measurement equipment, powering the unit at least 15 minutes before using it is advised. Installation Connect the BAR20-N to a USB port on your computer. Driver Installation a. Windows should automatically detect the BAR20-N as a Virtual COM Port and install the necessary drivers*. -
Page 7: Usage Guidelines And Applications
Integration with GPS Systems The NMEA output of the BAR20-N makes it ideal for integration with GPS systems and other NMEA-compatible devices. It can provide real-time atmospheric pressure data to enhance the accuracy of location-based services and weather monitoring applications. -
Page 8: Care, Storage, And Recalibration
Care, Storage, and Recalibration Care Use within the specifications available in the BAR20-N datasheet. NOTE: Note that this product is not waterproof and requires protection if contact with water is possible. Storage Store within the housing temperature and humidity ranges specified in the BAR20-N datasheet. -
Page 9: Return Process And Warranty Information
Briefly, Dracal Technologies only warrants to the original product purchaser for 24 months (2 years) from the delivery date. Accessories and Peripherals To use Dracal Technologies’ the user must have a computer or device with a powered USB port. Disassembly and Environmental... -
Page 10: Document Revision History
CE and REACH Compliance These USB sensors comply with CE (Conformité Européenne) and REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulations, meeting European safety and environmental impact standards. Document Revision History Version 1.0 2024-03-21 Creation of the User Manual. Dracal Technologies Inc. - Page 11 +1 450.812.8612 Dracal Technologies Inc. A204 - 7900 Taschereau Blvd Brossard (Quebec) J4X 1C2 Canada...
