5.REMOTE INTRODUCTION
BT
6.TECHNICAL FEATURES
POWER SUPPLY
Voltange
Idling current
SIGNAL STAGE
Distortion - THD @ 1kHz, 1V RMS Output
Bandwith @-3 dB
S/N ratio Full Power A-
Hight level input range
THD+N VS Power 1%
INPUT STAGE
High Level(Speaker)
CONNECTION
From/To Personal Computer
CROSSOVER N.5(one each output channel)
Filter Type
Slope Setting
Crossover frequency
Phase control indepent setting for each channel
DSP
8.5-15VDC
1.5A
0.01%
10-20kHz
98 dB
3V-15V
(СH1 CH2 CH3 CH4 ) 4X50W ATTS
1.2.3.4
1 x USB/B(1.1/2.0) 5M
Full/High/Low Pass /Band Pass
6/12/18/24/30/42/48 dB
68 steps @ 20- 20kHz
0 - 180
,
Ower s Manual
DSP Car Power Amplifiers
DSP
A6
Advertisement
Related Manuals for awave DSP A6
Summary of Contents for awave DSP A6
- Page 1 5.REMOTE INTRODUCTION Ower s Manual DSP Car Power Amplifiers 6.TECHNICAL FEATURES POWER SUPPLY Voltange 8.5-15VDC Idling current 1.5A SIGNAL STAGE Distortion - THD @ 1kHz, 1V RMS Output 0.01% Bandwith @-3 dB 10-20kHz S/N ratio Full Power A- 98 dB Hight level input range 3V-15V THD+N VS Power 1%...
- Page 2 PRODUCTBRIEFINTRODUCTION PRODUCTBRIEFINTRODUCTION 3.SOFTWARE INSTALLATION 1.DSP AND DRC INSTALLATION 2.Click NEXT 1.Insert CD, Double-Click DSP How to install External dimensions 174mm 4.GUI OPERATION INSTRUCTION Guide to GUI after installation WARNING: do not use aggressive cleaning agents or abrasive cloth to clean the display.Simply use 1.
