TXFF15D10
Dual 10" Under Seat Subwoofer Enclosure
For FORD Trucks
2015+ F-150 Super Crew
2017+ F-250 / F-350 Super Duty Crew Cab
INSTALLATION GUIDE
NOTE! Read this installation guide thoroughly before disassembling or modifying the
vehicle. Installation of this product requires technical skill, experience and specialized
tools. If in doubt, it's recommended to have it professionally installed by an authorized
Stinger or AudioControl Dealer.
A video installation guide is available at:
Advertisement
Table of Contents
Related Manuals for AudioControl Stinger TXFF15D10
Summary of Contents for AudioControl Stinger TXFF15D10
- Page 1 NOTE! Read this installation guide thoroughly before disassembling or modifying the vehicle. Installation of this product requires technical skill, experience and specialized tools. If in doubt, it’s recommended to have it professionally installed by an authorized Stinger or AudioControl Dealer. A video installation guide is available at:...
-
Page 2: Installation Notes
INSTALLATION NOTES The TXFF15D10 is designed to mount under the rear seat of FORD Super Crew Trucks Some installation steps are more easily completed with a second person. Speaker wire is required. Final enclosure impedance: 2ohms. Recommended amplifier rating: 400-1,200 watts @ 2ohms. INCLUDED HARDWARE D = Driver P = Passenger... -
Page 3: Installation
INSTALLATION Step 1 Lift up the Rear seat to expose the 4 front seat mounting bolts. Use a 13mm socket to loosen the 4 hex bolts enough to allow the brackets to slide under the seat brackets. Seat Bolts Flathead Screwdriver Step 2 Use a large flathead screw driver and slide it under the seat frame. - Page 4 INSTALLATION Step 3 Place the speaker enclosure in the vehicle with the rear of the enclosure facing the back seat. Route speaker wire to the rear of the enclosure and connect using either the Push Terminals or the Quick-Plug connector. Red = Positive (+) Black = Negative (-) NOTE: Do not connect speaker...
-
Page 5: Specifications
COMPLETED Step 5 Crank up the volume. SPECIFICATIONS Model Number TXFF15D10 Subwoofer Model SPC-10S4 (x2) Subwoofer Size 10” Enclosure DC Resistance (Re) 2 ohm Frequency Response 20Hz - 250Hz RMS Power Min 400w - Ideal 800w -Max 1200w Total Weight 49.4 lbs Height 8.7 In... - Page 6 Complimentary Layout Page (tape measure and calculator not included)
- Page 7 Complimentary Layout Page (tape measure and calculator not included)
- Page 8 Mobile audio support: Phone: 425-777-7723 Email: support@audiocontrolmobile.com As Technology advances, AudioControl reserves the right to © 2024 Stinger. All rights reserved. AudioControl is a Stinger Technical Support Phone: 727-592-5991 Email: support@stingersolutions.com © 2024 AAMP Global. All rights reserved. | IG-TXFF15D10 REV 091024...
