Summary of Contents for Sterling THERM2200
- Page 1 Sterling Power Products THERM : Air Conditioner Range Handbook THERM2200 RoHS compliant www.sterling-power.com www.sterling-power-usa.com Warranty (2 years return to factory)
-
Page 2: Contents Page
If you are unsure of any step or guideline then please consider reaching out to Sterling via our web contact form or our phone service and we shall offer our support. -
Page 3: Safety And Legal
- Warranty is null and void if damage occurs due to negligent repairs. - Customer is responsible for inbound shipping costs of the product to Sterling Power either in the USA or England. -
Page 4: Safety Guidelines
Ensure the product is correctly set up for your battery. Keep out of reach of children WARNING : Do NOT remove the panelling to inspect the internals unless expressly told to by Sterling. This is not a product designed to be user-serviced. WARNING : Do NOT use the device in situations where there is danger of gas / dust / vapour explosions, or around potentially flammable produce. -
Page 5: Specifications
STERLING POWER SPECIFICATIONS FOOTPRINT AND SPEC SHEET Dimension (mm) Specifications and technical data Rated Cooling Capacity 600W-2200W Operating Voltage DC - 12V DC - 24V Current draw 30A-60A 15A-30A Power 300W-700W Volume of air moved 450m3/h over four outlets Operating modes... - Page 6 We’ll get to that in a moment. 1) Technically I’m cheating here, because this set of 4.5m DC cable is part of the THERM2200. 2) Digital screen for configuration and understanding 3) Malleable foam air-seal with self-adhesive layer.
- Page 7 STERLING POWER FIRST OPENING CONTROL BREAKDOWN Interior control/filter panel 1) Bolt ‘receivers’, here is where you’ll tighten the nuts to ensure the panel stays in place 2) Screen housing 3) Ventilation ducts Control panel and remote controls 1) Power ON/OFF...
-
Page 8: Beginning The Installation
THERM2200 body that may allow this to be made easier. Make sure that the sealing foam is secure to the THERM2200 body and that there is no space for wrinkling or any air gaps. An example is below. - Page 9 The control panel (which will be mounted over the bolts coming down from the THERM2200) should be used to cover the gap in your roof and will fit in to the polystyrene ‘vent’...
- Page 10 Operating the unit The THERM2200 is a relatively simple unit to use and understand. The control panel screen will give you an update on all currently relevant settings. Adjusting fan speed Fan speed can be adjusted up and down by using the relevant buttons, either on the control panel or on the remote.
-
Page 11: Error Codes And Descriptions
STERLING POWER ERRORS ERROR CODES AND DESCRIPTIONS Error codes We’re most of the way there. Route the power cables down roughly the path you want them to take (that decision Sometimes errors happen- the below list of error codes should help you identify what the error is - and might give is entirely yours...) and go get the control panel. - Page 12 RoHS compliant www.sterling-power.com www.sterling-power-usa.com Warranty (2 years return to factory)
