Arch Basket Swings 3.5"
1 Seat, 1 Seat Add-A-Bay
IMPORTANT!
Prior to installation of any components, refer to the "Owner/Operator Manual". This
manual will provide important information pertaining to site preparation, footings, system stabilization and
other necessary information vital to the success of your installation.
MODEL
LT0938
LT0940
Note: An (*) by a part number (Code) indicates: Color Code Required.
1. Concrete for footings, wheelbarrow or mixer, 5 gallon bucket, water supply
2. Digging equipment for footings (spade shovel, post hole digger, auger)
3. Bracing materials (2x4s, wood pieces, concrete blocks, bricks, jackstands, sawhorses, etc.)
4. Tape measure and level
5. Open end wrench set, Allen and 6-lobe wrenches or bits, socket set, screwdrivers
6. Drill, bits, extension cords, power supply
7. Rubber mallet
8. Step ladder
9. Adult installers - 2 minimum
Installation Guide
(inground and surface mount)
DESCRIPTION
3.5" Multi-User Arch Swing
3.5" Multi-User Arch Swing Add-A-Bay
TOOLS AND EQUIPMENT REQUIRED
Also see "Installations 101"
Arch Basket Swings 3.5"
18APR23
Rev. A
LT0938
PAGE
2
3
Page 1 of 15
Advertisement
Related Manuals for Little Tikes LT0938
Summary of Contents for Little Tikes LT0938
- Page 1 Prior to installation of any components, refer to the "Owner/Operator Manual". This manual will provide important information pertaining to site preparation, footings, system stabilization and other necessary information vital to the success of your installation. LT0938 Arch Basket Swings 3.5" MODEL...
- Page 2 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay LT0938 3.5" Multi-User Arch Swing Protective Area: 24' x 32' Top View - Inground Inground Model Shown Top View - Surface Mount 3429mm [11' 3"] 18"...
- Page 3 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay LT0940 3.5" Multi-User Arch Swing Add-A-Bay Protective Area: 24' x 32' Top View - Inground Inground Model Shown Top View - Surface Mount Each Add-A-Bay for these 3429mm [11' 3"] two models use the footing layout shown at left.
-
Page 4: Parts Identification
18APR23 MR0938 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay PARTS IDENTIFICATION MR0938B PN 929412* FRAME - 3.50" STEEL ARCH SWING TITLE: DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN AS INDEXED TOLERANCES UNLESS OTHERWISE STATED THIS DRAWING IS THE SOLE PROPERTY... - Page 5 18APR23 Rev. A MR0940 Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay PARTS IDENTIFICATION PN 929413* FRAME - 3.50" STEEL ARCH SWING (ADD BAY) TITLE: DIMENSIONS ARE IN MM UNLESS STATED OTHERWISE MAT'L: THE INFORMATION CONTAINED IN AS INDEXED TOLERANCES UNLESS OTHERWISE STATED THIS DRAWING IS THE SOLE PROPERTY...
- Page 6 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay PARTS IDENTIFICATION PN 929994* SWING PURCHASED PARTS (shown assembled) Page 6 of 15...
- Page 7 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay PARTS IDENTIFICATION BOLT WASHER HANGER SWING ROPE HANGER BOTTOM D-SHACKLE D-SHACKLE BOLT ROPE CHAIN LINK BASKET CLEVIS SET SCREW CLEVIS BOLT CLEVIS CONNECTOR D-SHACKLE D-SHACKLE BOLT PN 929994* SWING PURCHASED PARTS (exploded view)
- Page 8 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay STEP 1 DIG FOOTINGS (IF APPLICABLE) 1a. Refer to Footing Layout and Construction Drawings for inground and surface mount footing criteria for installation. Surface mount model can be placed on either a 4" concrete slab or a concrete footing.
- Page 9 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay STEP 4 ATTACH SWING HANGERS TO TOP RAIL 4a. Attach the two swing hangers to the top rail, using the pre-drilled holes in the top rail. Apply a drop of thread locking adhesive to the bolt threads before installing bolt.
- Page 10 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay STEP 5 POUR CONCRETE (IF APPLICABLE) 5a. Rope off area to prevent access and pour concrete; allow to cure for 72 hours. For surface mount models, see illustration below.
- Page 11 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay STEP 6 FASTEN SWING ROPES TO ROPE BASKET 6a. Attach d-shackles on end of ropes to the rope basket in four places as shown below. ROPE ROPE BASKET D-SHACKLE...
- Page 12 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay STEP 7 ATTACH ROPES TO SWING HANGERS 7a. Attach the swing ropes to the two swing hangers with hardware as shown below. Attach chain link to clevis connector (on the end of the rope) and to the d-shackle. Screw in clevis bolt, align holes in bolt and clevis, and install clevis set screw.
-
Page 13: Final Step
18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay STEP 8 INSTALL LABELS 8a. Install age appropriate labels per "Placement of Age Appropriate Labels" located in Installations 101 in Installation Manual. FINAL STEP Tighten all hardware. - Page 14 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay 3.5" MULTI-USER ARCH SWING LT0938 CODE DESCRIPTION 929424* FRAME-3.50" STEEL ARCH SWING (SM) (for surface mount) 929412* FRAME - 3.50" STEEL ARCH SWING (for inground) 929422* TOP RAIL - 3.50"...
- Page 15 18APR23 Rev. A Arch Basket Swings 3.5" (inground and surface mount) 1 Seat, 1 Seat Add-A-Bay PC F/ARCH SWING 928468 CODE DESCRIPTION HW928468-1 HRDW PKG ARCH SWINGS S1/1 200142931 ROD THREADED M8 X 75MM-PARTS ROOM HRDW PKG ARCH SWINGS S1/1 HW928468-1 CODE DESCRIPTION 200002145...
