ANYWAVE

ANY9300 SD/HD/UHD Encoder

User Manual

Version 24.05a – June 4, 2024

Table of Contents

Need help?

Do you have a question about the ANY9300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Anywave ANY9300

Page 1 ANYWAVE ANY9300 SD/HD/UHD Encoder User Manual Version 24.05a – June 4, 2024...
Page 2: Table Of Contents
3.1.1 Factory Default IP ......................9 3.2 Browser-based System Control ....................10 3.2.1 SERVICES Page ......................10 3.2.2 STATUS Page ....................... 24 3.2.3 SYSTEM Page ......................27 3.2.4 INFO Page ........................29 3.2.5 LOGS Page ........................30 ANY9300 Encoder User Manual 24-05a...
Page 3: Introduction
 Do not insert any kind of pointed objects like screw, gimlet, etc. into the ventilation holes of the product. This will damage the product. 4. Grounding  The system must be earthed to the system earth. 5. Location ANY9300 Encoder User Manual 24-05a...
Page 4: Hint For Correct Handling
Do not place the product in an unstable place, such as a rickety table or inclined surface. The product could drop or fall down, resulting in physical injury. Do not place the product in a place that is subjected to strong vibrations. Failures or malfunctions could result. ANY9300 Encoder User Manual 24-05a...
Page 5: Registered Trademark
AW9300 Encoder  Operational Manual (accessible from web UI)  2 x AC Cable (country dependent)  9x or 5x micro BNC M to BNC F Cable * The accessories may vary according to area. ANY9300 Encoder User Manual 24-05a...
Page 6: Product Descriptions
4. USB 3.0: Universal Serial Bus 3.0 port for the future software update 5. Gigabit Ethernet ports: four Gigabit Ethernet ports Please be sure each network port number. These ports will work properly only in 1Gigabit or 100 Mbps network. Slower speed network does not work. ANY9300 Encoder User Manual 24-05a...
Page 7: Main Features
90-264 Vac (100-240 Vac Nominal) Operating Supports Hot Swap Environment Power Consumption Up to 350W FCC Part 15, Subparts B Class A CE Class A Electromagnetic Compliance - EN 55032 - EN 55035 Safety - EN 62368-1 ANY9300 Encoder User Manual 24-05a...
Page 8: Basic Functions
SMPTE 299M Embedded audio MPEG-2 AAC Codecs MPEG-H 3D Audio Dolby Digital, AC-4 Audio Encoder Multichannel Encoding Supports up to 16 channels Sampling Rate 48KHz Bit Depths 16/24-bit SDI#1 port is capable of receiving 12G-SDI signal. ANY9300 Encoder User Manual 24-05a...
Page 9 Yes (PSIP included) ATSC 3.0 ROUTE Multiplex ATSC 3.0 MMTP WebDAV 6Keys – Menu, OK, Up, Down, Left, Right Front keypad Control I/F Web UI SNMP Monitoring I/F System Health Status Through IPMI LAN port ANY9300 Encoder User Manual 24-05a...
Page 10: Installation
 Nominal Frequency: 50 / 60 Hz  Maximum Frequency Range: 47 - 63 Hz 2.3 Power Off There is no power on/off switch in this equipment. In order to power off, please remove both AC cables from the system. ANY9300 Encoder User Manual 24-05a...
Page 11: Operations
Click ‘Remote Control’ and then ‘Launch Console’. Then, enter user name and password. Once user enters user name and password successfully, Linux console page will be shown. Now, IP address can be checked here by ‘ifconfig’ command. ANY9300 Encoder User Manual 24-05a...
Page 12: Browser-Based System Control
In this menu, you can setup details of encoding such as mux mode, bit rate for video, video input mode and audio channel configuration. Dependent on the options, AW9300 may support single service channel or 4 service channels or 8 service channels. ANY9300 Encoder User Manual 24-05a...
Page 13 As the service channel setup web interfaces for single UHD, multi-FHD and multi-HD/SD are basically the same each other, this manual describes for multi-FHD service setup. To set up service channels efficiently, following steps would be recommended: (1) Setting up System Multiplex (2) Setting up Service Multiplex ANY9300 Encoder User Manual 24-05a...
Page 14 Audio/Video timing and wall-clock time is pretty big. For ATSC1.0 operation mode, you can change details of TS output parameters. Press System Multiplex button and click MPEG-2TS to change settings. ANY9300 Encoder User Manual 24-05a...
Page 15 If MPEG-2TS mode has been selected as Multiplex Mode, below menu is shown. 3.2.1.2.2.2 ATSC 3.0 ROUTE/MMTP If ATSC3.0 mode has been selected as Multiplex Mode, you can further select ROUTE or MMTP as in the next example. ANY9300 Encoder User Manual 24-05a...
Page 16 HTTP_GET method is not actively handled by the Encoder but other devices such as ATSC3.0 ROUTE/MMTP packetizer may actively get the DASH segment streams. If MMTP mode has been selected, below menu follows. ANY9300 Encoder User Manual 24-05a...
Page 17 Segment Upload Option: Mostly user should set as ‘A/V’. 3.2.1.2.2.6 AWS or FTP You can alo upload DASH stream with either AWS or FTP method from ROUTE setup page. If AWS has been selected, below items will be shown. Enter correct value. ANY9300 Encoder User Manual 24-05a...
Page 18 Encoder text. Encoder components setup page will be poped up. Mostly, you need to check the number of audio encoder components. Once the number of encoder components is determined, you need to verify the detail values of each ANY9300 Encoder User Manual 24-05a...
Page 19 Open type is for better video quality.  GOP size & IP Period: For 59.94 system, 60 & 4 are recommended. Multiplex-specific page follows common video encoder setup page. Below is for ROUTE-specific video encoder parameter setting. ANY9300 Encoder User Manual 24-05a...
Page 20 10 would be recommended. Below is for MMTP-specific video encoder parameter setting.  Asset ID Scheme: You can use URI or UUID as asset ID scheme. Below is for MPEG-2TS-specific video encoder parameter setting. ANY9300 Encoder User Manual 24-05a...
Page 21 Channels & Bitrate: Select audio channel mode and bitrate. Below is for ROUTE-specific audio encoder parameter setting. For more information, please check ‘Video Encoder Setup’ section. Below is for MMTP-specific audio encoder parameter setting. For more information, please check ‘Video Encoder Setup’ section. ANY9300 Encoder User Manual 24-05a...
Page 22 If MPEG-2TS has been selected as Multiplex Mode, there is nothing to set up for caption service. 3.2.1.2.4 Source Setup AW9300 supports SDI input or IP input. 3.2.1.2.4.1 SDI Input Select SDI as ‘Input Type’ as corresponding number for ‘Input Port’. ANY9300 Encoder User Manual 24-05a...
Page 23 Once you correctly set up all service parameter settings, press Set button. Then, color for corresponding service channel box on the left side of the web page will be changed to purple as in the blow (see red colored box). ANY9300 Encoder User Manual 24-05a...
Page 24 If you want to setup HELD only transmission, you need to upload HELD file only in the below interface, while HELD+NRT data transmission mode requires both HELD file and NRT data file, where NRT data file is multipart formatted file. ANY9300 Encoder User Manual 24-05a...
Page 25 Multicast IP, UDP Port, TSI and Carousel Second. Once ready, press ‘set’ button to take effect. Once the procedure has been done, the encoder system generates the bundled SLS with HELD xml data and NRT data periodically. ANY9300 Encoder User Manual 24-05a...
Page 26: Status Page
3.2.2 STATUS Page STATUS page provides encoding status such as PTS(Presentation Time Stamp) for audio/video, SLS information. This page also provides system status such as input status, temperature of some main components and output bitrate. ANY9300 Encoder User Manual 24-05a...
Page 27 Status is inactive. 3.2.2.1.2 Main block Temerature of Encoder - CPU Temperature - System Temperature Note) Indicator of Encoder tempeature status - Green Box Normal operating temperature condition - Red Box Critical operating temperature condition ANY9300 Encoder User Manual 24-05a...
Page 28 In MMTP-based service channel, click the ‘MPT’ or ‘USBD’ button to view the SLS information or clilck the ‘Download MPT’ or ‘Download USBD’ button to download. 3.2.2.1.4 TxRate In this sub-menu, the use can check the transmission bitrate and encoding status of each channel currently in service. Note) Text based ANY9300 Encoder User Manual 24-05a...
Page 29: System Page
[PTP Transfer Mode] Our system provides two options for the transfer mode – IEEE 802.3 and UDP Ipv4. Select appropriate mode. [PTP Delay Mechanism] AUTO, E2E, P2P options are provided. For the other options, use appropriate value provided by PTP server. ANY9300 Encoder User Manual 24-05a...
Page 30 Encoder is designed for use in Korea and US. In case of the operation in US, time zone setup is also important. Below menu items are for setting up region, UTC local offset in minutes and use of daylight- saving time. ANY9300 Encoder User Manual 24-05a...
Page 31: Info Page
Click ‘Start Update’ to start update. Once update has been completed, the encoder system will automatically reboot. 3.2.4 INFO Page In this menu, you can check the System information. File name shall not be changed. ANY9300 Encoder User Manual 24-05a...
Page 32: Logs Page
3.2.5 LOGS Page For the checking of system error(s), you can download error log file by pressing ‘Save logs’ button. - Blue text Normal operation status of Encoder. - Red text Error or alarm events of Encoder ANY9300 Encoder User Manual 24-05a...
Page 33 ANY9300 User Manual Anywave Communication Technologies Inc. 100 N Fairway Drive, Suite 128, Vernon Hills, IL 60061 Tel: (847) 415-2258 Fax: (847) 415-2112 Email: sales_us@anywavecom.com http://www.anywavecom.net/ ANY9300 Encoder User Manual 24-05a...
