- Page 1 Fridge - Freezer / User Manual Congelatore - Frigorifero / Manuale per l’uso Réfrigérateur - Congélateur / Guide D’utilisation RC33KNZA RC33SNZA...
- Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS ................4 1.1 General Safety Warnings ....................4 1.2 Installation warnings .......................8 1.3 During Usage........................8 2 DESCRIPTION OF THE APPLIANCE ............10 2.1 Dimensions ........................11 3 USING THE APPLIANCE ................12 3.1 Information about New Generation Cooling Technology ..........12 3.2 Display and Control Panel ....................12 3.3 Operating your Fridge Freezer ..................12 3.3.1 Freezer Temperature Settings ...................12... -
Page 4: Safety Instructions
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 5 natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
- Page 6 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 7 To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. • Clean regularly surfaces that can come in contact with food and accessible drainage systems •...
-
Page 8: Installation Warnings
1.2 Installation warnings performance of your fridge freezer. • Clearance of at least 150 mm is required Before using your fridge freezer for the first at the top of your appliance. Do not place time, please pay attention to the following anything on top of your appliance. - Page 9 Packaging and the Environment high alcohol content vertically in the fridge compartment and make sure their Packaging materials protect tops are tightly closed. your machine from damage that • When removing ice from the ice-making may occur during transportation. compartment, do not touch it. Ice may The packaging materials are cause frost burns and/or cuts.
-
Page 10: Description Of The Appliance
2 DESCRIPTION OF THE General notes: Fresh Food Compartment (Fridge): Most APPLIANCE efficient use of energy is ensured in the configuration with the drawers in the bottom This appliance is not intended to be used as a built-in appliance. part of the appliance, and shelves evenly distributed, position of door bins does not affect energy consumption. -
Page 11: Dimensions
2.1 Dimensions Overall dimensions 1860,0 595,0 650,0 the height, width and depth of the appliance without the handle. Overall space required in use 981,6 Space required in use 1243,5 2010,0 the height, width and depth of the 695,0 appliance including the handle, plus the space necessary for free 744,1 circulation of the cooling air, plus... -
Page 12: Using The Appliance
3 USING THE APPLIANCE 3.2 Display and Control Panel 3.1 Information about New Generation Cooling Technology Fridges with new-generation cooling technology have a different operating system to static fridges. Other (static) fridges may experience a build up of ice in the freezer compartment due to door openings and humidity in the food. -
Page 13: Cooler Temperature Settings
automatically when the temperature of the temperature. freezer compartment is set to -18°C. Recommended Settings for the Freezer and Cooler Compartment Temperature 3.3.2 Cooler Temperature Settings • The initial temperature value for the Freezer Cooler Remarks Compartment Compartment cooler setting indicator is +4 °C. For regular •... -
Page 14: Accessories
allow it to run for 24 hours in order to you can twist the tray as shown below to reach operating temperature. During this remove the ice cubes. time, do not open the door and do not keep a large quantity of food inside. •... -
Page 15: The Chiller Shelf (In Some Models)
3.5.3 The Chiller Shelf (In some models) (The images are representative) (The images are representative) Chiller shelf If the crisper is full, the fresh dial located Keeping food in the Chiller compartment, in front of the crisper should be opened. instead of the freezer or refrigerator This allows the air in the crisper and the compartments, allows food to retain... -
Page 16: Adjustable Door Shelf (In Some Models)
3.5.7 Adjustable Glass Shelf (In some vegetables is not preferred, use packaging materials such as paper that has a certain models) level of porosity in terms Adjustable glass shelf mechanism provides of hygiene. higher storage spaces with a simple movement. To cover the glass shelf, push There is a membrane filter in this area that control humidity level. -
Page 17: Maxi-Fresh Preserver (If Available)
3.5.8 Maxi-fresh preserver (If available) • Cooked dishes must remain covered when they are kept in the fridge.Do Maxi Fresh Preserver technology helps to not place warm foods in fridge.Place remove ethylene gas (a them when they are cool, otherwise the volatile organic compound temperature/humidity inside the fridge will released naturally from fresh... -
Page 18: Freezer Compartment
NOTE: • The temperature of the fridge compartment should be in the range Potatoes, onions and garlic should not of 0-8 °C, fresh foods below 0 °C are be stored in the refrigerator. iced and rotted, bacterial load increases 4.2 Freezer Compartment above 8 °C, and spoils. - Page 19 • The storage life of frozen food depends on the room temperature, the thermostat setting, how often the door is opened, the type of food, and the length of time required to transport the product from the shop to your home. Always follow the instructions printed on the packaging and never exceed the maximum storage life indicated.
- Page 20 The table below is a quick guide to show you the most efficient way to store the major food groups in your freezer compartment. Maximum storage time Meat and fish Preparation (months) Steak Wrap in foil 6 - 8 Lamb meat Wrap in foil 6 - 8 Veal roast...
-
Page 21: Cleaning And Maintenance
Maximum storage time Vegetables and Fruits Preparation (months) Strawberry and Wash and hull 8 - 12 Blackberry Cooked fruits Add 10 % of sugar to the container Plum, cherry, sourberry Wash and hull the stems 8 - 12 Maximum storage time Thawing time at room Thawing time in oven (months) -
Page 22: Shipment And Repositioning
SHIPMENT AND • Make sure you have disconnected the plug of your appliance before cleaning REPOSITIONING the water tray. 5.2 Transportation and Changing • Remove the water tray from its position Positioning by removing the screws (if it has screws). Clean it with soapy water at specific time •... -
Page 23: Before Calling After-Sales Service
6 BEFORE CALLING AFTER-SALES SERVICE Errors Your fridge will warn you if the temperatures for the cooler and freezer are at improper levels or if a problem occurs with the appliance. Warning codes are displayed in the freezer and cooler indicators. ERROR TYPE MEANING WHAT TO DO... - Page 24 ERROR TYPE MEANING WHAT TO DO 1. Set the fridge temperature to a colder value or set Super Cool. This should remove the error code once the required temperature has been reached. Keep doors closed to improve time taken to reach the correct Likely to occur after: temperature.
-
Page 25: Tips For Saving Energy
7 TIPS FOR SAVING ENERGY There is a build-up of humidity inside the appliance 1. Install the appliance in a cool, well- Check if: ventilated room, but not in direct sunlight • All food is packed properly. Containers and not near a heat source (such as a must be dry before being placed in the radiator or oven) otherwise an insulating appliance. - Page 26 52476612...
