Zest 00037 Assembly Instructions Manual

Broxton bbq shelter

Advertisement

Quick Links

Assembly Instructions
Broxton BBQ Shelter
Code: 00037
V3 05 24
CAUTION: CONSTRUCTION INVOLVES WORKING AT HEIGHT. SUITABLE EQUIPMENT REQUIRED.
(W x D x H) 2.20m x 2.20m x 2.49m
ONLINE ASSEMBLY VIDEO AVAILABLE
Please scan the QR code or visit zestoutdoorlivingsupport.co.uk
PLEASE KEEP THESE INSTRUCTIONS
www.zestoutdoorliving.co.uk | 01352 873555 | sales@zestoutdoorliving.co.uk
1
of 6
