- Page 1 Orbit PTZ 4K/HD Wireless Video and Control for PTZ Cameras Reference Guide © 2021 Teradek, LLC. All rights reserved.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Physical Properties ..........2 Getting Started ........... 4 Power and Connect ........4 Device Operation ......... 5 12G-SDI Input/Output Cables ......5 Custom 3rd Party Cables ....... 5 Power Connector/Cable Pin-Out ....5 Launchpad App ..........6 Pairing............ -
Page 4: Physical Properties
PHYSICAL PROPERTIES ORBIT PTZ TRANSMITTER ORBIT PTZ RECEIVER A: RP-SMA antennas H: RS-232 (Mini-DIN) port N: 6-28V DC power input B: 3G-SDI input I: RS-422 (RJ-45) port O: Network status C: 3G-SDI output J: DC Power output P: Video Status... - Page 5 Teradek, LLC 2021. All rights reserved. v1-0321...
-
Page 6: Getting Started
Connect the output from your video source to either the SDI or HDMI input (PTZ: B or D) on the Orbit PTZ transmitter using the included cable for your specific camera. Connect either the SDI or HDMI output (RX: K or L) from the Orbit receiver to the video input on your monitor. -
Page 7: Device Operation
DEVICE OPERATION • For best results when using multiple Orbit PTZ systems in the same area, place the transmitters and receivers a few feet apart from each other. • Operation of other wireless equipment may interfere with Orbit PTZ. Try to separate other wireless transmitters and receivers as much as possible. -
Page 8: Launchpad App
Enable Bluetooth on your iOS or Android device. Navigate to the Bluetooth menu on the transmitter and receiver, then select Enable. Open the Launchpad App from your iOS or Android device, then tap the Orbit PTZ Devices button. Select the device(s) you want to pair or monitor. - Page 9 Control Dial - Tap and drag the control dial up and down to control the camera’s tilt operation, or left and right for the camera’s pan operation. Teradek, LLC 2021. All rights reserved. v1-0321...
-
Page 10: Pairing
PAIRING Orbit PTZ units purchased as a set (TX and RX), are paired by default, requiring no additional configuration. Units purchased separately need to be paired using the device's front panel (OLED) menu, Launchpad, or the Launchpad App. NOTE: Before starting either pairing process, ensure that both the transmitter and receiver have the same firmware version and have Bluetooth enabled. -
Page 11: Mounting
MOUNTING WITHOUT DUAL MOUNT Orbit PTZ devices have a 1/4”-20 threaded hole (additional 3/8”-16 threaded hole on the receiver) on the bottom for mounting the included light stand adapter or any other mounting accessory. Orbit PTZ RX mounts vertically on a light stand or... -
Page 12: Transmitter Display Operation
TRANSMITTER DISPLAY OPERATION Orbit PTZ’s configuration menus can be accessed from either the transmitter's front panel display or from the Launchpad app. STATUS SCREENS Press the menu joystick (G) to cycle through the status screens or to return from the menu. - Page 13 WIRELESS SETTINGS - ENABLE FIXED FREQUENCY Fixed Frequency Mode bypasses any automatic frequency switching logic, allowing your Orbit PTZ system to always attempt to connect on a specified frequency. Once a frequency is selected, the transmitter will only use that frequency. This allows your transmitter to link/reconnect to the receiver much faster.
- Page 14 The Video Quality menu lets you adjust the balance between your signal’s maximum range and quality according to the number of antennas used to transmit fine information. Orbit PTZ has three picture quality levels that vary based on the lowest quality link or the furthest receiver.
-
Page 15: Bluetooth Settings
- Enables the use of a PIN for authentication when using the Launchpad app NOTE: Bluetooth is disabled by default. In order to configure your Orbit PTZ devices via the Launchpad App, you must first enable Bluetooth. DISPLAY SETTINGS Use the Display Settings to control the OLED display operation. By default, the OLED display will invert every 10 minutes. -
Page 16: Receiver Display/Osd Operation
Use the Menu joystick (G) to navigate the configuration menus. SWITCH TX Orbit PTZ receivers can pair with up to four transmitters at a time. Switch TX allows you to quickly switch from one paired transmitter's camera feed to another paired transmitter. - Page 17 Fixed Frequency Mode enabled, you can only select one frequency for Orbit PTZ to use. Frequencies marked with (DFS) must be scanned for one minute before they can be used, but are typically less crowded. For all available frequencies, refer to the FREQUENCIES BY REGION chart on page 25.
-
Page 18: Spectrum Analyzer
● Figures above 45% indicate good signal quality PAIR Enable pairing on transmitters and receivers. Orbit PTZ units purchased as a set (TX and RX) are paired by default, requiring no additional configuration. If the units were purchased separately, or if they have never been paired, you will need to complete the pairing process (page 5). -
Page 19: Hdmi Settings
480p - 59.94/576p - 50 (via HDMI ports only) ● 480i (NTSC) ● 576i (PAL) ● HDMI SETTINGS Orbit PTZ supports all HDMI output modes. You can select from one of the following options: Auto YCbCr 4:4:4 10bit ● ● RGB 8bit YCbCr 4:2:2 10bit ●... -
Page 20: Test Pattern
● AUDIO SETTINGS Configure Orbit PTZ’s Audio settings. If Beep on REC is activated, you will hear a short tone whenever the camera begins or stops recording. The Mute Settings allow you to completely mute audio or only mute audio while recording. -
Page 21: Device Info
Dim after 10 sec No BurnIn Prevention ● ● RESET ALL SETTINGS Reset all configurable options to their factory defaults. DEVICE INFO Displays the model and serial number. FIRMWARE VERSIONS Displays the device's current firmware versions. Teradek, LLC 2021. All rights reserved. v1-0321... -
Page 22: Launchpad
LAUNCHPAD With Launchpad, you can configure all of your Orbit PTZ devices at once. Available as software for Windows and Mac, Launchpad allows you to pair multiple receivers to your transmitter, select frequencies, load 3D LUTs, and perform firmware upgrades. - Page 23 Next to proceed with the upgrade. You will then be presented with a list of device components and whether or not they are scheduled to be updated, along with two options: Start Upgrade - Update your Orbit PTZ device(s) with the latest firmware version. Advanced Options - View detailed version information for each component and the firmware upgrade package components.
-
Page 24: Frequencies By Region
FREQUENCIES BY REGION NOTE: Pairing the TX and RX is required after a different region is selected. Australia/ Freq Range US (FCC) Canada Japan China/India New Zealand Bandwidth (MHz) 5160 5160 5160 5160 5180 5180 5180 5180 5180 5180 5180 UNII1 5190 5190... -
Page 25: Technical Specifications
Three-conductor 3.5 mm Mini Jack or Connector Serial Connector Serial Connector AUDIO Audio 48kHz 24-bit PCM 48kHz 24-bit PCM Compression Embedded SDI/HDMI Audio Input Audio Input (2 channel) Embedded SDI/HDMI Audio Input Audio Output (2 channel) Teradek, LLC 2021. All rights reserved. v1-0321... - Page 26 ORBIT PTZ TX ORBIT PTZ RX PHYSICAL ATTRIBUTES Dimensions 9.1” x 7.2” x 1.7” 5.3” x 5.5” x 1.2” (230 x 183 x 42.5mm) (133.74 x 139.2 x 30.10mm) Weight 35oz (998g) 23oz (656g) Construction Milled aluminum (chassis), Milled aluminum (chassis),...
- Page 27 (TX to RX) 1080p23.98/24/25/29.97/30/50/59.94/60 1080p23.98/24/25/29.97/30/50/59. 1080psf23.98/24/25/29.97/30 94/60 1080i50/59.94/60 1080psf23.98/24/25/29.97/30 Supported 720p50/59.94/60 1080i50/59.94/60 Resolutions 480p50 576p59.94/60 720p50/59.94/60 480i(NTSC)/576i(PAL) 480p50 576p59.94/60 480i(NTSC)/576i(PAL) Input Cross Yes, HDMI to SDI Conversion Output Video Yes, Framerate and Resolution Scaling Scaling Teradek, LLC 2021. All rights reserved. v1-0321...
- Page 28 ORBIT PTZ TX ORBIT PTZ RX VIDEO PROCESSING Video Uncompressed Uncompressed Compression CAMERA CONTROL PROTOCOL Camera Control VISCA, Panasonic AW VISCA, Panasonic AW Support TALLY Contact Closure Input, Visca, Contact Closure Input, Visca, Interface Panasonic AW Panasonic AW Three-conductor 3.5 mm Mini Jack or Three-conductor 3.5 mm Mini Jack or...
- Page 29 None, Optional P-Tap cable Nominal Power 20 Watts 18 Watts Consumption Operating 0~40 deg-C 0~40 deg-C Temperature GENERAL Mountability Multiple mounting options with M3 and Multiple mounting options with 1/4”-20 1/4”-20 holes and 3/8”-16 holes Teradek, LLC 2021. All rights reserved. v1-0321...
-
Page 30: Regulatory Information
Operating the product without regulatory approval is illegal. Any changes or modifications to the product not expressly approved by Teradek could void the user's authority to operate the equipment and its regulatory approvals. Please make sure you use the latest revision of this document which is available at teradek.com. -
Page 31: Battery
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. Teradek, LLC 2021. All rights reserved. v1-0321... - Page 32 Antenna Information The radio transmitters 7680A-AMN41012 (HD Transmitter), 7680A-AMN42012 (HD Receiver), and 4492A-2832 (BT Module) have been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
-
Page 33: Unintentional Radio Interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Teradek, LLC 2021. All rights reserved. v1-0321... - Page 34 IC STATEMENT This device complies with RSS-247 of the Industry Canada Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 35: Ec Declaration Of Conformity
über Recycling information. SUPPORT RESOURCES In addition to this Reference Guide, you can find more information on Orbit PTZ devices' features and operation by visiting www.teradek.com. If you are unable to find what you need online, please contact Teradek’s support staff.
