Page 1: Table Of Contents
Thank you for purchasing our product “NC-5000”. Be sure to read our manual thoroughly before using and keep this manual for any future references. NC-5000 is designed to support monitoring patients. Using a NC-5000 will not prevent injury, and is not a guarantee of safety.
Page 2: Safety Instruction
AC adaptor.” Warning IMPORTANT SAFETY INSTRUCTION Unplug NC-5000 from the wall outlet and refer servicing to qualified service personnel under the following conditions. ● When smoke, an unusual noise, or an odor comes from the unit please contact the store that you purchased from for repair.
Page 3 Do not disassemble or alter the product. Do not attempt to disassemble or alter the product. It may cause fire and electric shock. Contact your distributor for inspection, adjustment and repair. Do not wet Do not wet the product. It may cause a fire and an electric shock. Do not harm AC adapter’s cord Follow instruction below;...
Page 4 Rechargeable Battery caution Follow the instruction below. Failure to do so may lead to batteries’explosion and liquid leak of battery, which may lead to fire and injury, or cause mess and damage around the surrounding. ●　Use the specified battery. ●　Never disassemble the battery. ●　Non-rechargeable batteries are not to be recharged.
Page 5: Names Of The Parts
Names of the parts Wireless Adapter Box Front view Back view Transmitter indicator light Transmitter Power light Power Reset Alarm pause light Alarm pause button Pairing button Setting switches Bottom view AC adapter jack Volume control switch Speaker Nurse call output jack Portable Receiver Holes for a neck strap / lanyard Charging...
Page 6 Sensor connection transmitter Front view Back view With a Without a cover view Transmission cover view light NC-5000TXBF Transmitter Mini-plug jack Battery holder Setting switch Floor sensor mat Bed sensor pad A pocket for A pocket for the transmitter the transmitter Side-rail sensor pad (Large) Side-rail sensor pad (Small) A pocket for...
Page 7: Door Sensor
Portable nurse Portable pause button for call button the wireless adaptor box Transmission Transmission light light Pause Pause Call Call button button NC-5000TXPH NC-5000TXPB Magnet sensor Door sensor Transmission light Transmission light NC-5 000 TX MG Magnet Sensor NC-5000TXDR Magnet Door Sensor connecting site Magnet unit...
Page 8: How To Use Transmitter
How to use the transmitters How to use sensor connection transmitter Excel’s bed and/or floor sensor can be connected to the transmitters. For the bed sensor, when an individual’s body weight decreases on the bed (e.g., sitting up or moving close to the edge of the bed) the sensor delivers an alert signal to the receiver wirelessly.
Page 9 How to use the nurse call button When a call button located on the center is pressed an alert signal is transmitted to the receiver. Step 1: Register or pair the nurse call button with the receiver. Please refer to each receiver’s manual for the pairing process. How to use the magnet sensor When a magnet attached to the main unit (a bed or a wheelchair) separates from the main unit an alert signal is sent wirelessly to a nurse call station or...
Page 10: How To Use Wireless Adapter Box
Magnet Sensor Transmitter Transmitter The Excel Engineering’s various caring sensors can be connected to an existing nurse call system through the wireless adaptor Box. *In order to identify your specific needs, please let us know your nurse call system manufacturing company’s name and the type of nurse call...
Page 11 How to pair the transmitter The transmitters must be paired with the adaptor box. One adaptor box can be paired with up to 3 transmitters. Wireless Step 1: Plug the AC adaptor into the wireless adaptor box and adaptor box then plug into an outlet.
Page 12 Indication of low battery status on the transmitter Step 1: When the transmitters’ batteries are low, the wireless adaptor box’s transmission light starts flashing as the adaptor box receives a transmission signal from the transmitters. Please replace the batteries in the transmitter. Step 2: To reset the flashing transmission light on the wireless adaptor box, simply unplug the AC adaptor.
Page 13: How To Use Portable Receiver
How to use the portable receiver When the caring sensor is turned on, a designated number assigned for the transmitter will be displayed. The receiver also starts an alarm sound or vibration. To stop the alarm sound or the vibration, press the stop button on the receiver.
Page 14 About rechargeable batteries in the portable receiver When the rechargeable batteries in the portable receiver become low an alarm sounds one time and a “Low battery” icon appears on the display. When this happens please use the AC adaptor to recharge the batteries immediately. Low battery icon The power light on the receiver turns on while the PRX2...
Page 15 How to unpair the transmitters Unpairing by using the portable receiver Reject Step 1. Turn off the power switch on the portable ▲ receiver. While pressing the “stop” button turn on the ▼ power switch. When the display shows the “pairing mode”...
Page 16 Alarm auto stop function When paired transmitter with the bed sensor sends a reset signal while the portable receiver is alarming by same transmitter's alarm signal, the receiver will stop alarming from same transmitter automatically. Informing a caregiver if a transmitter is outside of a wireless signal transmission range When a paired transmitter is outside of the wireless signal transmission range or not...
Page 17: Testing The System
Testing the system When you complete all desired settings please test each device individually to confirm all devices are functioning properly. How to check if the transmitters function properly For the nurse call button: Press the request button. The transmission light on the transmitter should light up. For the floor and side rail pads: Expose the transmitter from the pocket.
Page 18: Troubleshooting
Troubleshooting Transmitters Solutions Probelms Potential causes No batteries? Insert batteries. The transmission light Low batteries? Install fresh batteries. does not light up… The batteries are installed Check the directions of incorrectly? the batteries. Repeater The AC adapter is plugged Plug in the AC adapter firmly and correctly.
Page 19: Specification
Portable receiver The portable receiver Turn on the power has no power The portable receiver Plug in the AC adaptor and needs to be recharged. recharge the unit. The transmission light on the portable receiver lights Pair the transmitter. The transmitter is not paired. up but it does not start If there is an obstacle between the alarm sound…...
