A4M SCiO Series

2 or 4 channel amplifier modules

with DSP and remote control

User Manual • Version 1.1 (English)

MADE IN BELGIUM

A4M SCiO series amplifier

modules are pre-fitted in these

AUDIOFOCUS self-powered

loudspeakers:

• Carys C15LSa

• Cyris C210Sa

• Ares 12a

• Ares 8a

• S 21a

• B 18a

• MTSub 218a

• FRX 12a

• FRX 15a

A4M SCiO 1504

A4M SCiO 3004

June 2023 - www.AUDIOFOCUS.eu

Table of Contents

Need help?

Do you have a question about the A4M SCiO Series and is the answer not in the manual?

Questions and answers

Summary of Contents for AUDIOFOCUS A4M SCiO Series

Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: to reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel. The lightning flash with arrowhead sym- vice shall remain readily operable when the appa- bol, within an equilateral triangle, is in- ratus is installed or used.
Page 3 Customer participation is important to minimize the potential affects on the environment and hu- © 1999 - 2022 AUDIOFOCUS man health that can result from hazardous sub- All rights reserved. stances that may be contained in this product.
Page 4: Table Of Contents
Presets menu Hotspot menu Cloud menu Network menu Notes on network 19 - 20 About menu AUDIOFOCUS SCiO Software 21 - 46 Home page menu User gain menu User delay menu User PEQ menu 23 - 25 User X-over menu...
Page 5 Group menu 31 - 32 Group gain menu Group delay menu Group EQ menu 35 - 38 Settings menu 39 - 41 Firmware update 43 - 45 Specifications...
Page 6: Introduction
Thank you for choosing an AUDIOFOCUS loudspeaker fitted with our A4M SCiO amplifier module for your sound reinforcement needs. The A4M SCiO is a professional amplifier module featuring built-in DSP and secure remote control over the cloud, allowing you to log in to the AUDIOFOCUS Cloud and manage your amplifier settings remotely. PRODUCT HIGHLIGHTS FOREWORD...
Page 7: Before You Get Started
The latest manual revision can be downloaded from the download section of the AUDIOFOCUS website: http://www.audiofocus.eu This manual describes use of the A4M SCiO Series amplifier module. INSPECTION AND UNPACKING This appliance has been carefully packed in the factory and the packaging was designed to with- stand rough handling.
Page 8: Panel Description
PANEL DESCRIPTION RJ-45 Ethernet connectors for optional Dante digital audio network card with two network ports; a primary and a secondary. When the device is connected to an active network, the yellow LINK LED illuminates above the connector in use. Data activity on the network is indicated by illumination of the green ACT LED.
Page 9: Signal Flow
SIGNAL FLOW The figure below depicts the audio signal flow for a A4M SCiO series device. The signal flow can be divided in three main blocks, each with its own functionality and processing. These blocks are : input source, group and speaker blocks.
Page 10: Group
GROUP Groups provide powerful control over all channels in a system. Amplifiers can be assigned to up to 6 different Groups. Adjusting group parameters will affect all amplifier channels across the network assigned to that group. Multiple Groups can be used to logically partition a large-scale system. For instance, an amplifier can be assigned to the “frontfill group”...
Page 11: Speaker
SPEAKER PRESETS The amplifier has been pre-loaded with the correct presets for optimal performance with the AUDIOFOCUS loudspeaker in which it has been supplied. Delay IIR HPF IIR LPF RMS LIM Peak Lim Gain Polarity PEQ x 12 30mS 1024 tabs...
Page 12: Presets
PRESETS The A4M SCiO series amplifier module has two types of preset libraries, device and speaker presets. • A Global audio preset file contains all audio DSP settings of the four channels of the amplifier; User, Group and speaker parameters.
Page 13: Back Panel Operation
BACK PANEL OPERATION The back panel gives the user access to the status of the amplifier and also gives the user the ability to set IP parameters and basic audio settings. A single encoder is used to modify various parameters via the menu. When a menu item is selected that permits adjustment of parameter values, the menu’s icon illuminates.
Page 14: Settings Menu
SETTINGS MENU Pressing the encoder inwards will activate selected settings submenu. Pressing “Return” will always return the menu up one level from every menu or sub menu. AUDIO MENU Mixer Gain Delay Signal Generator...
Page 15: Mixer
MIXER From this sub menu, all nine input gains for each source can be set independently. The home screen will indicate output level, IP status, cloud connection status, current preset or output name for each output channel and global preset loaded.
Page 16: Audio Menu Gain
0 dB, but can be set to any value from -80 dB to +15 dB, in 0.1 dB increments. AUDIO MENU/DELAY Each source of the A4M SCiO series may have up to 250 ms of delay inserted. Note: The total amount of delay per channel is 250 ms shared between the channel and the groups that are assigned from that channel.
Page 17: Presets Menu
DSP settings of the amplifier (User, group and preset OEM settings). A speaker preset file contains the OEM speaker loudspeaker settings information which can be recalled on the amplifier. These speaker presets are created by AUDIOFOCUS and are preloaded in the preset folder. Speaker...
Page 18: Hotspot Menu
Every A4M SCiO series amplifier module has a Hotspot option. This allows the user to control the amplifier with any mobile device (smartphone, tablet or laptop). The software of the A4M SCiO series is web based, so there is no need for a software installation. From the panel, turn the Hotspot option on and search for the amp in your device wifi networks.
Page 19: Network Menu
DHCP mode to obtain IP addresses. After a connection is established with the router, the A4M SCiO Series device will receive an IP address that will be displayed in the network menu. Enter this address in your device’s browser and the SCiO software will open on your device.
Page 20: About Menu
IP address will be used; however this address may vary every time the device is connected to the network. If a DHCP server is available on the network then the A4M SCiO Series device will use the IP address provided by it.
Page 21: Audiofocus Scio Software
(MAC, PC, IOS, Android) ( See section Network and hotspot settings section). The SCiO software provides a unified interface for the A4M SCiO series, optimized for a wireless touchscreen, tablet or mobile device. The interface mirrors the powerful, but intuitive design of the hardware, whereby operation is predominantly icon driven.
Page 22: User Gain Menu
USER GAIN MENU Gain: opens a window where you can set gain and phase. Gain can be set with the fader, keyboard arrows or by dialling in the desired level. A double click on the fader will reset the gain to 0 dB. USER DELAY MENU Delay: opens a window where you can set the delay in ms.
Page 23: User Peq Menu
USER EQ MENU The filter icon will turn green when the filter is activated From the Home page tap the PEQ tab to access the EQ main page. From this page you can dial in numeric values for the12 EQ filters. Each EQ can be set to a choice of 16 filter types: Bell-Sym, Bell-Asym, Notch, Low- Shelf 6dB or12dB, High-Shelf 6dB or 12db, All-Pass 90°...
Page 24 To avoid accidental guesture operations in touch mode, there are three “Drag Locking” options. *Locks the gain setting for the selected filter. *Locks the frequency setting for the selected filter *Locks the Q factor for the selected filter The overview screen has different view options in the PEQ window Tap the View options icon to open the PEQ view options panel...
Page 25 The PEQ view window uses different line and colours to indicate in an intuitive way what filters are active and which filter is in edit mode. The blue line indicates the active EQ curve of the PEQ Filter that is in edit mode.
Page 26: User X-Over Menu
USER X-OVER MENU The A4M SCiO amplifier module offers 19 different types of classic X-over filters :Bessel , Butterworth and Linkwitz Riley with slopes from 6 to 48 dB/oct in the user block. From the Home page tap the X-Over tab to access the X-Over main page. Tap the filter symbol to open the filter window.
Page 27 The overview screen has different view options in the X-Over window Tap the View options icon to open the PEQ view options panel The X-over view window uses different lines and colours to indicate in an intuitive way what filters are active and which filter is in edit mode.
Page 28: User Limiter Menu
USER LIMITER MENU Limiter: opens a window where you can adjust the additional limiter parameters when desired for some productions where you would like some extra protection of your system. To fully protect loudspeakers from damage, each output is provided with a two-stage limiter. One stage responds to the RMS level of the signal, the other is a very fast-acting limiter responding to signal peaks.
Page 29 The calculator will calculate start values for the RMS limiter. Click the apply button to copy the calculated values to the RMS limiter. Note: every AUDIOFOCUS preset alreday has limiters set for protection. These limiters are on top when desired for certain applications.
Page 30: Speaker Preset Menu
SPEAKER PRESETS MENU From the speaker preset page you can recall all the AUDIOFOCUS OEM protected speaker preset files that are available for the speaker cabinet. The current speaker preset running on the channel will be displayed with the following icon around it “< >”...
Page 31: Group Menu
GROUP MENU Groups provide powerful control over all amps in a system. Amplifiers can be assigned to multiple groups, and each amplifier channel can be a member of up to six different groups. Adjusting group parameters will affect all amplifier channels across the network assigned to that group. Multiple Groups can be used to logically partition a large-scale system.
Page 32 Tap the edit Group tab to edit names for the six groups. Selecting the Assign Group tab will open or close the Assign Group window. Toggle the arrow to open or close the group assign view for Select tabs to assign amps to one one or all amps in the network.
Page 33: Group Gain Menu
GROUP GAIN MENU Gain: opens a window where you can set gain and phase for the selected group. Values can be set with the fader, keyboard arrows or by dialling in the desired level. Gain range can be set from -80 to +15 dB. Group gain is a relative value that will add or detract gain from the amplifier channel that is part of the group.
Page 34: Group Eq Menu
GROUP EQ MENU PEQ: opens a window where you can select twelve PEQ filters, for each of the selected groups, with the same functionality as for the User PEQ menu (See section User EQ Menu on page 28). The group PEQ filters are on top of the User PEQ. Select one of the six groups to edit with these tabs.
Page 35: Settings Menu
SETTINGS MENU A tab on the settings wheel icon will bring you to all the available settings for the selected device. The Global Device Audio Preset menu gives access to the global preset folders and files. A Global audio preset file contains all audio DSP settings of the amplifier;...
Page 36 Note: After a connection is made with the SCiO software, a security login window will appear on your device. The default settings are admin for both login and password, these settings can be personalized in the network window under the AUDIOFOCUS Cloud...
Page 37 A single A4M SCiO Series amplifier module or a complete network of A4M SCiO Series devices can be accessed and controlled from any place in the world as long as both the A4M SCiO Series and the PC or mobile device are connected to the internet.
Page 38 From this menu Spotify and AirpPlay streaming services can be activated and personalized. Make sure that your mobile device is on the same network as your A4M SCiO series device. A unique Spotify device name can be entered here. It will appear...
Page 39: Firmware Update
Download the zip file : Turn « On » the amplifier Disconnect all speaker cables Open your browser to the A4M SCiO Series UI interface : Go to « Settings » Go to « Settings » Select « Firmware Update » tab...
Page 40 Click « Browse » to select the downloaded zip file (A4M SCiO Series_v1.1.zip) Go to « Settings » Select « Firmware Update » tab...
Page 41 Press « Update Now » button Update Now Update procedure is running 10. After a few seconds, the front panel screen of the amplifier will become black - the update is running in the background. After a few minutes, the screen will go back to normal. At this point, you can manually restart your amplifier.
Page 43: Specifications
SPECIFICATIONS Operating conditions Temperature 0° to 50° C, 10 to 60 % non-condensing Storage temperature -20° to 70° C Safety / Compliance CB Cerificate Amplification and power supply Amplification class Class D technology Power supply model Universal switch mode power supply’s with active PFC Power Factor >...
Page 44 Two channel internal streaming source supporting Spotify and AirPlay Remote control and monitoring Network connection Single port Ethernet Gigabit interface AUDIOFOCUS remote control software SCiO- Web based Back panel indicators Daylight viewable colour OLED display Real time level , limit and fault indicators...
