- Page 1 GeoTerra ® Automated Dispenser Operator Manual REV B – Original Instructions...
-
Page 2: Table Of Contents
Under Table Mount ............9 3 General Safety ............... 10 Warning Labels ............... 11 4 Scope and Limits ..............12 Introduction..............12 Auto GeoTerra Controls ........... 13 Auto GeoTerra Connections ..........13 5 Set-up ................... 14 Lifting ................14 Machine Set-up ............... 14 Roll Holder Assembly ............ - Page 3 LANGUAGES OF OPERATION DISCLAIMER The original version of this manual is in English and denoted “Original Instructions” in the top center header. All translated versions are denoted “Translation of Original Instructions” in the same location. October 2024 Copyright Pregis Corporation All Rights Reserved...
- Page 4 EasyPack ® GeoTerra ® Automated Dispenser Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries). Original Instructions. October 2024 Copyright Pregis Corporation All Rights Reserved...
-
Page 5: Authorized Ce Representative
Automated Dispenser Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries). Original Instructions. Property of Pregis LLC 227 W Monroe St Suite 4100 Chicago, IL 60606 United States of America Authorized CE Representative ACC –... -
Page 6: Introduction
Original Instructions. Introduction The Auto GeoTerra dispenses a paper-based wrappable packaging material that provides light cushioning and interleaving protection. The dispenser automatically expands the paper’s lattice structure at a high rate of speed, allowing for faster packaging than manual expansion dispensers. -
Page 7: Machine Specifications
Power Requirements: 120/230 VAC, 60/50 Hz, 3/1.5 A Maximum Speed: 30 inches / second The sound pressure level measured at the operator station does not exceed 70dB(A). 2.1 Overall Dimensions UNITS: [mm] INCH Front Side Profile Overhead October 2024 Copyright Pregis Corporation All Rights Reserved... -
Page 8: Roll Holder - Right Side
Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries). Original Instructions. 2.2 Roll Holder – Right Side Shown with a standard GeoTerra roll. Front Side Profile 2.3 Roll Holder – Left Side Shown with a standard GeoTerra roll. -
Page 9: Under Table Mount
Tech Service Hotline: 886-904-6979 (US), +39 33 11 34 16 65 (Italy), 00800 888 888 44 (All other European Countries). Original Instructions. 2.4 Under Table Mount Iso View Top View (Paper Outfeed) Side View Front View October 2024 Copyright Pregis Corporation All Rights Reserved... -
Page 10: General Safety
Please read and understand the manual including all the danger, warnings, and caution statements. If after reading the manual you have questions, contact your supervisor or your Pregis service technician to get answers before working with the machine. -
Page 11: Warning Labels
The meanings of the warning labels and the potential hazards they represent must be clearly understood before attempting to operate or maintain the machine. If, at any time, a warning label on the machine becomes lost, damaged, or illegible, contact Pregis to order replacement signs. -
Page 12: Scope And Limits
Scope and Limits 4.1 Introduction GeoTerra paper has a series of perforations that expand into a 3D lattice to provide cushioning and abrasion resistance. The Auto GeoTerra dispenser expands GeoTerra paper with two sets of rollers. The Infeed Rollers are conveniently located at the top of the machine for ease of loading. -
Page 13: Auto Geoterra Controls
This cable can be removed to de-energize the machine for maintenance and cleaning. The FOOT PEDAL is used to dispense paper. In a normal running state, the Auto GeoTerra will dispense expanded material if the FOOT PEDAL is held, then stop when the FOOT PEDAL is released. -
Page 14: Set-Up
Set-up 5.1 Lifting Machine Weight: 43 lbs (20kg) The Auto GeoTerra machine should be lifted by two persons by the bottom of the machine. Ensure that the paper roll is removed from the machine before lifting. 5.2 Machine Set-up The machine can be used in a Tabletop or Under Table configuration. -
Page 15: Roll Holder Assembly
00800 888 888 44 (All other European Countries). Original Instructions. 5.3 Roll Holder Assembly These instructions are for Tabletop only. For Under Table installations, please contact Pregis Service. The ROLL HOLDER is packaged partially assembled in three sections. Assemble as shown in the diagram below. -
Page 16: Attaching The Roll Holder
Original Instructions. 5.4 Attaching the Roll Holder These instructions are for Tabletop only. For Under Table installations, please contact Pregis Service. The Roll Holder can be mounted on the LEFT or the RIGHT depending on customer preference. Machine Mounted RIGHT... -
Page 17: Operation
Operation 6.1 Loading Auto GeoTerra • Place the GeoTerra paper roll onto the ROLL HOLDER. Ensure that the roll is fully engaged (touching the flange). • Fold the paper as shown. Before folding, if the paper edge is pre-expanded or tattered, tear the paper until there is a clean edge. - Page 18 If paper has exited the outfeed, the machine has been successfully loaded – skip to the next section (Operation). vii. If paper has not exited the outfeed, see section “Clearing a Jam” before trying to load again. October 2024 Copyright Pregis Corporation All Rights Reserved...
-
Page 19: Operation
When closing the top door, just push down until both SPRING PLUNGERS click into place. Confirm SPRING PLUNGER is fully retracted before dispensing material. PULLING OUT SPRING PLUNGER SPRING PLUNGER RETRACTED SPRING PLUNGER NOT RETRACTED October 2024 Copyright Pregis Corporation All Rights Reserved... -
Page 20: Troubleshooting
1) TOP DOOR is not closed all 1) Open the TOP DOOR and Expanding the way. close again. Ensure both SPRING PLUNGERS are fully retracted. If problems persist, call Pregis Tech Service Hotline. October 2024 Copyright Pregis Corporation All Rights Reserved... -
Page 21: Clearing A Jam
5) Once all large pieces of paper have been removed, check for any remaining debris or small scraps. Pull those out of the machine. 6) Confirm both the Infeed Area and inside the machine are clear of paper. 7) The machine is now ready to be loaded. October 2024 Copyright Pregis Corporation All Rights Reserved... -
Page 22: Preventive Maintenance
00800 888 888 44 (All other European Countries). Original Instructions. Preventive Maintenance The Easypack Auto GeoTerra Paper System requires very little to no maintenance. The following items should be checked on the indicated intervals. 8.1 Monthly Maintenance: 1) Wipe down exterior surfaces. -
Page 23: Revision Table
USER MANUAL: MARKETING UPDATES, NEW CONSUMABLE SERVICE MANUAL UPDATES: ADDED EXPANSION RATIO 14 OCT 2024 2044 ADJUSTMENT, ADDED SPARE PARTS SECTION, ADDED CE DECLARATIONS, ADDED CLARIFICATIONS TO UNDER TABLE AND ROLL HOLDER INSTALLATION, ADDED ROLLER CLEANING PROCEDURE October 2024 Copyright Pregis Corporation All Rights Reserved...
