DESCRIPTION
Dimensions: 75*123 mm
Weight: 320 gr
Coverage: 100 m²
Power: 1.7W
Input voltage: USB 5V
Lithium battery: 2000 mAh
Consumption: 0.02-0.10 ml/h
Refill: 15 ml
Materials: ABS+PP
CONCENTRATION & CONSUMPTION
Grade
Working(s)
G3
10 s
G2
10 s
G1
5 s
User
5-15 s
PRODUCT DESCRIPTION
USB port
Key
Trou d'accrochage
USER MANUAL
CASA DIFFUSER
Stop(s)
Consumption (ml/h)
60 s
0.1 ml/h
120 s
0.05 ml/h
150 s
0.03 ml/h
60-900 s
Ambient light
control button/
RESET button
CASA
USB CABLE
Notes: It is normal for consumption rates to
fluctuate by 15%. The above data is based on
tests. Consumption rate of different essential
oils varies, above data is for reference only.
USER GUIDE
MANUAL
6.Short click to switch
the light color/long click
to do RESET for the
password
Advertisement
Summary of Contents for SMW CASA
- Page 1 USER MANUAL CASA DIFFUSER DESCRIPTION Dimensions: 75*123 mm Weight: 320 gr Coverage: 100 m² Power: 1.7W CASA USB CABLE MANUAL Input voltage: USB 5V Lithium battery: 2000 mAh Consumption: 0.02-0.10 ml/h Refill: 15 ml Materials: ABS+PP CONCENTRATION & CONSUMPTION Grade...
- Page 2 FUNCTION DESCRIPTION Charging mode: When charging, the indicator light is always red, and when fully charged, the green light is always on. It refers to the charging indicator on the back. Auto power off: When there is no operation, the device will automatically power off after 12 hours. Ambient light: Total of 7 light colors: red, yellow, green, cyan, blue, purple, white.
- Page 3 Timer (PS :There are 5 working periods available) Password After selecting the grade, ALWAYS SAVE before going back MODIFY THE PASSWORD to the CASA page. Settings of the working periods Save Glisser vers le Click on haut ou le bas “change...
