- Page 1 SMS200 SMS (Text) Module User’s Manual Revision 1.2 Copyright © 2024 Littelfuse, Inc. All Rights Reserved Maretron, a Littelfuse Brand 120 Intracoastal Pointe Dr. Jupiter, FL 33477 http://www.maretron.com Maretron Manual Part #: M003146 Revision 1.2 Page i...
-
Page 2: Revision History
SMS200 User's Manual Revision History Revision Description Initial Release Changes per internal review feedback Added description of LED functionality Page ii Revision 1.2... -
Page 3: Table Of Contents
2.5.2 Cellular Antenna Connection ................5 2.6 Indicators ........................5 Configuring the SMS200 ...................... 6 3.1 Configuring with a DSM-series Display ................6 3.1.1 Maretron SMS200 Configuration ................. 6 3.2 Configuration with N2KAnalyzer ..................9 3.2.1 General Tab ......................9 3.2.2 Advanced Tab ....................10 3.2.3 PGN Enable/Disable Tab .................. - Page 4 SMS200 User's Manual Table of Figures Figure 1 – Mounting the SMS200 ....................4 Figure 2 – NMEA 2000 ® Connector Face Views ............... 5 Figure 3 – SMS200 Connectors ....................5 Figure 4 – SMS200 Configuration Screen ................. 6 Figure 5 –...
-
Page 5: General
NMEA 2000 network and an SMA antenna connector for connecting the included mobile antenna. The Maretron SMS200 is designed to operate within the harsh demands of the marine environment. However, no piece of marine electronic equipment can function properly unless installed, calibrated, and maintained in the correct manner. -
Page 6: Theory Of Operation
SMS200. 2 Installation 2.1 Unpacking the Box When unpacking the box containing the Maretron SMS200, you should find the following items: • 1 – Cable Assembly • 1 – Nearshore Networks SIM Card (Preinstalled in SMS200) •... -
Page 7: Sim Card
2.3 SIM Card 2.3.1 Included SIM Card The SMS200 is supplied with a pre-installed SIM card for Nearshore Networks. Please refer to the instructions supplied with the SMS200 for SIM card activation. Please check Maretron’s website for the latest information. 2.3.2 Installing Your Own SIM Card If you prefer to use your own cellular service rather than the supplied Nearshore Networks service, you will need to install your own SIM card into the SMS200. -
Page 8: Connecting The Sms200
SMS200 User's Manual mounting screws. Place the SMS200 over the drilled holes so that the mounting holes in the SMS200 line up with the drilled holes and install the screws, tightening until snug. Figure 1 – Mounting the SMS200 2.5 Connecting the SMS200 ®... -
Page 9: Cellular Antenna Connection
Figure 2 – NMEA 2000 ® Connector Face Views 2.5.2 Cellular Antenna Connection The SMS200 has one external SMA cellular antenna connector. This connector is intended for use only with the included cellular antenna. Screw the antenna onto the SMA connector and tighten until snug. -
Page 10: Configuring The Sms200
3.1 Configuring with a DSM-series Display 3.1.1 Maretron SMS200 Configuration This describes the configuration of the Maretron SMS200 firmware version 2.0.1.9. The display may be used to configure the Device Instance and Installation Description on the SMS (Text) Module (SMS200). After selecting the SMS200 from the list of devices on the network, the following screen will be displayed. -
Page 11: Figure 5 - Sms200 Advanced Configuration Menu
Figure 5 – SMS200 Advanced Configuration Menu 3.1.1.1.1 Device Instance Program this parameter to the desired instance number for this device. You can program this parameter to any value between 0 and 252. You usually will not need to modify the default value of “0”. -
Page 12: Figure 7 - Sms200 Test Screen
SMS200 User's Manual You can enable or disable the transmission of the various messages, or set the frequency of transmission of the messages by pressing the Enter key ( ) on the message to be configured. Options are: • Disable – The status message will not be transmitted •... -
Page 13: Configuration With N2Kanalyzer
• Phone # - This entry identifies the phone number used by the SMS200. This phone number is defined by the SIM card which is installed in the SMS200. • Signal Strength – This entry shows the signal strength of the cellular network as seen by the SMS200. -
Page 14: Advanced Tab
SMS200 User's Manual Figure 8 – SMS200 General Tab 3.2.2 Advanced Tab This tab contains entries that need to be changed only in specific cases; for instance, if there are multiple instances of this device on a network. Page 10 Revision 1.2... -
Page 15: Pgn Enable/Disable Tab
Figure 9 – SMS200 Advanced Tab 3.2.2.1 Device Instance The device comes from the factory with the device instance value set to 0. If you have multiple of these devices on a network, you may find it necessary to set the device instances of other devices of this type so that they are different. -
Page 16: Installation Description Tab
SMS200 User's Manual Figure 10 – SMS200 PGN Enable/Disable Tab 3.2.4 Installation Description Tab This tab allows you to set values for the installation description properties of the device. Page 12 Revision 1.2... -
Page 17: Test Tab
Figure 11 – SMS200 Installation Description Tab 3.2.4.1 Installation Description #1, #2 This device, along with all other Level A certified NMEA devices, has two user-entry ‘Installation Description’ fields. You may enter text into these fields with information specific to the device, such as date installed, the initials/name of the installer, the physical location of the device, etc. -
Page 18: Figure 12 - Sim100 Test Tab
SMS200 User's Manual Figure 12 – SIM100 Test Tab The top section of the screen shows the current operating status of the SMS200. • SIM Card – This entry shows the status of the SIM card. Normally, it should show “SIM INSERTED”. -
Page 19: Usage
SMS” button. The text in the Message field will be sent to the telephone number in the “Destination Phone Number” field. The bottom section of the screen displays the SMS text messages most recently received by the SMS200. You can test SMS200 message reception by using a cellular telephone to send a SMS text message to the telephone number of the SMS200, and then watching for the message to appear on this section of the screen within a few seconds to a minute or longer, depending on the cellular network. -
Page 20: Maintenance
If the unit is loose, tighten the mounting screws. • Check the security of all cable connections and tighten if necessary. 6 Troubleshooting If you notice unexpected operation of the Maretron SMS200, follow the troubleshooting procedures in this section to remedy simple problems. Symptom Troubleshooting Procedure •... -
Page 21: Technical Specifications
7 Technical Specifications Specifications Parameter Value Comment ® NMEA 2000 Connector DeviceNet Micro-C Industry Standard Waterproof on supplied adapter cable Antenna Connector For use only with supplied cellular antenna Cellular Technologies LTE Cat 4 Supported Bands LTE FDD: North America/Canada B2/B4/B5/B12/B13/B25/B26 WCDMA: B2/B4/B5 Certifications... - Page 22 SMS200 User's Manual Page 18 Revision 1.2...
-
Page 23: Regulatory Compliance
If you require technical support for Maretron products, you can reach us in any of the following ways: Telephone: 1-866-550-9100 Fax: 1-602-861-1777 E-mail: support@maretron.com World Wide Web: http://www.maretron.com Mail: Maretron, a Littelfuse Brand Attn: Technical Support 120 Intracoastal Pointe Dr. Jupiter, FL 33477 USA Revision 1.2 Page 19... -
Page 24: Installation Template
SMS200 User's Manual 10 Installation Template Please check the dimensions before using the following diagram as a template for drilling the mounting holes because the printing process may have distorted the dimensions. Figure 14 – Mounting Template Page 20 Revision 1.2... -
Page 25: Maretron (1 Year) Limited Warranty
11 Maretron (1 Year) Limited Warranty Carling Technologies warrants the Maretron ® SMS200 to be free from defects in materials and workmanship for one (1) year from the date of original purchase. If within the applicable period any such products shall be proved to Carling’s satisfaction to fail to meet the above limited warranty, such products shall be repaired or replaced at Carling’s option. -
Page 26: Warranty Return Procedure
SMS200 User's Manual 11.1 Warranty Return Procedure: To apply for warranty claims, contact Carling Technologies or one of its Maretron dealers to describe the problem and determine the appropriate course of action. If a return is necessary, place the product in its original packaging together with proof of purchase and complete a Return Merchandise Authorization (RMA) on the following web page: https://www.maretron.com/rma_request.php You will be contacted by email with instructions on where to send the unit for repair /...
