BELGIAN WAFFLE MAKER
For California Customers
WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Model
Voltage
BWM-07
120 V ~ 60 Hz
BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS
Congratulations on the purchase of your WINCO® equipment. WINCO takes pride in the quality of its products.
When used as intended, and with proper care and maintenance, you will experience years of reliable operation
from this equipment. To ensure best results, it is important that you read and follow the instructions in this manual
carefully. It's important to save these instructions for future reference.
Operating Instruction Manual
Power
Amperage
Plug Type
1,000 W
8.3 A
NEMA 5-15P
COMMERCIAL
Overall Dimensions
Length
Depth
Height
10"
17-3/4"
12"
(255 mm)
(450 mm)
(305 mm)
Product
Weight
22 lbs
(9.9 kgs)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BWM-07 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Winco BWM-07

  • Page 1 BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS Congratulations on the purchase of your WINCO® equipment. WINCO takes pride in the quality of its products. When used as intended, and with proper care and maintenance, you will experience years of reliable operation from this equipment.
  • Page 2 Immediately Inspect for Shipping Damage All containers should be examined for damage before and during Congratulations on the purchase of the WINCO® equipment. Please unloading. The freight carrier has assumed responsibility for its take time to carefully read through this manual to ensure the safe transit and delivery.

  • Page 3: Table Of Contents

    • Waffle Maker plastic and cardboard, from the unit. WINCO® prides itself on quality and service, ensuring that at the 2. Clean any glue residue left over from the plastic or tape. time of packing, all products are supplied fully functional and free of damage.

  • Page 4: Important Safeguards

    If there is ever uncertainty about a particular task or the proper method of operating this equipment, ask an experienced supervisor or contact Winco® for assistance. Warnings This manual contains a number of precautions to follow to help promote safe use of this equipment.
  • Page 5 ELECTRIC CODE, ALL LOCAL ELECTRIC CODES AND ORDINANCES, AND ALL THE LOCAL ELECTRICAL COMPANY RULES AND REGULATIONS. 6. The use of accessory attachments not recommended by WINCO Additionally, we recommend a 4" spacing surrounding the unit in may cause fire, electric shock or injury.

  • Page 6: Operation

    Preparation Operation 1. Place Waffle Maker on a flat leveled surface. 1. Allow the unit to preheat to the set temperature. An amber light on the front panel will be illuminated while the unit is still 2. Plug the unit into 120V power source. preheating.

  • Page 7: Cleaning, Care & Maintenance

    Parts protected by the manufacturer or its agent are not to be adjusted by the installer unless the installer is an authorized service agent. If you have any questions or problems DO NOT send unit to WINCO® without first contacting our customer service department.

  • Page 8: Exploded View

    Exploded View MODEL: BWM-07...

  • Page 9: Parts List

    Control ECI 12V Relay Transformer Element 500W This circuit diagram has been provided to assist qualified electricians; only WINCO service agents or qualified electricians should carry out repairs if required. Do not remove any components or service panels on this product.

  • Page 10: Limited Warranty

    Limited Warranty WINCO® warrants to the original purchaser of new equipment that said equipment, when installed in accordance with our instructions within North America and subjected to normal use, is free from defects in material or workmanship for a period of 1 year. The labor warranty is one year from original installation or 18 months from actual factory shipment date, whichever date occurs first.
  • Page 11 WARRANTY SERVICE SELLER. WINCO® NEITHER ASSUMES NOR AUTHORIZES ANY PERSONS TO ASSUME FOR IT ANY OTHER OBLIGATION OR DO NOT send unit to WINCO® without first contacting our customer LIABILITY IN CONNECTION WITH SAID EQUIPMENT. service department: 973-295-3899. Examples of items not covered under warranty, but not limited to just...
  • Page 12 Model: BWM-07 www.wincous.com...
