Famco QRT 5 Quick Start Manual

QRT 5
The QRT is an outdoor CPE unit with the following hardware specifications:
Quickstart
Please follow these quick steps to set up your device:
 Mount unit in your desired place, please see
paragraph.
 Slide off latch to access Ethernet port. Please see
Opening latch section.
 Connect your PoE cable to the Ethernet port, please
see Powering section.
 Set your computer IP configuration to automatic
(DHCP).
 From your PC connect to the wireless network name
which starts with "MikroTik".
 Once connected to the wireless network, open
http://192.168.88.1 in your web browser to start
configuration, since there is no password by default,
you will be logged in automatically.
 We recommend clicking the "Check for updates" button
and updating your RouterOS software to the latest
version to ensure the best performance and stability.
 Choose your country, to apply country regulation
settings and set up your password in the screen that
loads.
Powering
The device accepts power from the PoE to the Ethernet port:
Passive Power over Ethernet 8-30 V DC . ⎓
•
The power consumption under maximum load can reach 12 W.
Connecting to a POE Adapter:
1. Connect the Ethernet cable from the device to the POE+DATA port of the POE adapter.
2. Connect an Ethernet cable from your local network (LAN) to the POE adapter.
3. Connect the power cord to the adapter, and then plug the power cord into a power outlet.
Configuration
We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version
to ensure the best performance and stability. RouterOS includes many configuration options in addition to what is
described in this document. We suggest starting here to get yourself accustomed to the possibilities:
mt.lv/help. In case IP connection is not available, the Winbox tool (mt.lv/winbox) can be used to connectto the
MAC address of the device from the LAN side (all access is blocked from the internet port by default). For
recovery purposes, it is possible to boot the device from a network, see the section
Extension slots and ports
Gigabit Ethernet port, passive PoE on Ethernet port.
•
5 GHz wireless, supported protocol 802.11a/n, antenna gain 24 (dBi).
•
See mikrotik.com/products for the latest version of this document.
Mounting
Reset button.
Document #51137 Modified on: 30.JUL.2019
