Ameriwood HOME Monticello 2524319COMS Manual

Ameriwood HOME Monticello 2524319COMS Manual

2 drawer pull out
Hide thumbs

Advertisement

Quick Links

Download this manual
BBBBB22BBBB (B(MM(M( (MM((
BBBB2BBBBBB (((MMMM( (MMMM(
BMMM MMMMM B MMMMMM BMMM BMM
Date of Purchase: ____/____/_____
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
–Unit can tip over causing severe injury or death.
–Anchor unit to stud in wall (if instructed to)
–Do not allow children climb on unit
–Put heavy items on lower shelves or drawers
BBBBBBBBBBBBBBBBBB
Easy
Follow Ameriwood Home
052024PK
Tough

Advertisement

loading
Need help?

Need help?

Do you have a question about the Monticello 2524319COMS and is the answer not in the manual?

Questions and answers

Related Manuals for Ameriwood HOME Monticello 2524319COMS

Summary of Contents for Ameriwood HOME Monticello 2524319COMS

  • Page 1 Visit: www.ameriwoodhome.com Easy Tough WARNING Follow Ameriwood Home –Unit can tip over causing severe injury or death. –Anchor unit to stud in wall (if instructed to) –Do not allow children climb on unit –Put heavy items on lower shelves or drawers...
  • Page 2 BMMMMMM Us! MM NBT MMMMMM M(is pMM(MMM! Contact our friendly customer service team first for help BMMM Ms! VisiM M(MMiMMM((M(M.MM( 1-800-489-3351 HMMpfMM HiMMs PEOPLE NEEDED FOR ASSEMBLY: B - Open your item in the area you plan to keep it for less heavy lifting. - Identify, sort, and count the parts before attempting assembly.
  • Page 3 BMfMMM YMM BMMMM BMfMMM YMM BMMMM Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
  • Page 4 Please Note: You may need to lightly tap the wood dowels with a hammer into the holes during your assembly process. Wood Dowel Insertion: Insert wood dowel Not Actual Size completely into the hole. Wood Dowel Wood Dowel will Actual Size extend out approximately 3/8”.
  • Page 5 BMMM( I(MMM f MMM MM Not actual size x1 PC x1 PC x1 PC TOP PANEL SIDE PANEL LEFT SIDE PANEL RIGHT x1 PC x1 PC x1 PC BOTTOM PANEL SOLID BACK LEFT SOLID BACK RIGHT x1 PC x1 PC x1 PC CENTER RAIL PULL OUT FRONT...
  • Page 6 BMMM( I(MMM f MMM MM Not actual size x1 PC x1 PC x1 PC PULL OUT LEFT PULL OUT RIGHT PULL OUT BACK x2 PCS x2 PCS x2 PCS DRAWER FRONT DRAWER SIDE LEFT DRAWER SIDE RIGHT x2 PCS x2 PCS x2 PCS LOWER DRAWER BACK LOWER DRAWER BOTTOM...
  • Page 7 BMMM( I(MMM f MMM MM Not actual size ameriwoodhome.com...
  • Page 8 BMMM NM(bMM RMfMMMMMM Each part has a unique part number. Please refer to the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above. BBBBB22BBBB BBBB2BBBBBB LMbMM...

  • Page 9: Actual Size

    BMMM LisM Actual Size FMM MM( MMpMMMM(MMM (MM(MMMM, sMM pMgM 22. TPK0001 TPK0002 TPK0004 TPK0008 CAM BOLT CAM LOCK DOWEL SCREW 15 x 9 M8 x 30 CBS M4 x 38 TPK3013 TPK0032 PH SCREW JCBC SCREW M4 x 18 M6 x 30 ameriwoodhome.com...
  • Page 10 BMMM LisM Not Actual Size x1 SET TPK3012 TPK2004 TPK0014 HANDLE ANTI TIPPING KIT HEX KEY ameriwoodhome.com...
  • Page 11 HMM(MMMM NM(bMM RMfMMMMMM Each part has a unique part number. Please refer to the appropriate part number when contacting customer service for replacement parts. Before throwing any packaging, please verify all contents and make sure you have received all the parts listed above. BBBBB22BBBB BBBB2BBBBBB BM(MM#...
  • Page 12 Step 1 TPK0001 TPK2004 Properly insert Cam Bolts (1) to Top Panel (A) and Bottom Panel (D) and fully tighten Loosely attach Anti-Tipping Kit (8) and (8c) to Top Panel (A). Note: This will be tightened in Step 20. ameriwoodhome.com...
  • Page 13 Step 2 TPK0001 TPK0002 TPK0004 Proper orientation of CAM LOCK Insert Cam Bolts (1), Cam Locks (2), and Dowels (3) to Left Side Panel (B), Right Side Panel (C) and Center Rail (G). ameriwoodhome.com...
  • Page 14 Step 3 TPK0014 TPK0004 TPK0032 Connect Legs (S) to Bottom Panel (D) Insert Dowel (3) into Legs (S). using JCBC Screws (6) and tighten with Hex Key (9) Tight ameriwoodhome.com...
  • Page 15 Step 4 TPK0002 TPK0004 Proper orientation of CAM LOCK Insert Cam Locks (2) and Dowels (3) into Solid Back Left (E), and Solid Back Right (F). ameriwoodhome.com...
  • Page 16 Step 5 Attach Solid Back Left (E) to Left Side Panel (B) and Solid Back Right (F) to Right Side Panel (C), tighten by turning cam locks clockwise. Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 17 Step 6 Attach Center Rail (G) to Left Side Panel (B) and Right Side Panel (C), tighten by turning cam locks clockwise. Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 18 Step 7 Attach Bottom Panel (D) to Left and Right Side Panels (B) & (C) and Solid Back Panels (E) & (F). Tighten by turning cam locks clockwise. Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 19 Step 8 With the assistance of a second person, carefully stand the unit upright. Position and attach Top Panel (A) to Left and Right Side Panels (B) & (C) and Solid Back Panel (E) & (F). Tighten by turning cam locks clockwise.
  • Page 20 Step 9 TPK0001 TPK0002 TPK0004 Proper orientation of CAM LOCK Insert Cam Locks (2), and Dowels (3) to Pull Out Top (I), Pull Out Left (J), Pull Out Right (K), and Pull Out Back (L). Insert Cam Bolts (1) to Pull Out Front (H) and Pull Out Top (I). ameriwoodhome.com...
  • Page 21 Step 10 Attach Pull Out Left (J), Pull Out Right (K), and Pull Out Back (L) , tighten by turning cam locks clockwise. Pull Out Top (I) Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 22 Step 11 TPK0008 Attach Pull Out Left (J) and Pull Out Right (K) to using Screws (4). Pull Out Back (L) Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 23 Step 12 Attach Pull Out Front (H) Pull Out Left (J), Pull Out Right (K) , tighten by turning cam locks clockwise. and Pull Out Top (I) Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 24 Step 13 TPK3013 TPK3012 Connect Handles (7) to Pull Out Front (H) using Screws (5) as illustrated. ameriwoodhome.com...
  • Page 25 Step 14 TPK0001 TPK0002 Proper orientation of CAM LOCK Properly insert Cam Bolts (1) to Drawer Front (M) x 2, and Drawer Back (P) x 2 and fully tighten. Insert Cam Locks (2) to Drawer Side Left (N) x 2, Drawer Side Right (O) x 2 and Lower Drawer Support (R) x 2.
  • Page 26 Step 15 Attach Drawer Side Left (N) and Drawer ) to Drawer Front (M) x 2 Side Right (O by turning cam lock clockwise. ameriwoodhome.com...
  • Page 27 Step 16 Attach Drawer Support (R) to Drawer Front (M) x 2, tighten by turning cam lock clockwise. ameriwoodhome.com...
  • Page 28 Step 17 Insert Drawer Bottom (Q) into the grooves of Left and Right Drawer Sides (N) & (O) and align with the groove in Drawer Front (M). Pro Tip: Second person recommended for ease of assembly on this step. ameriwoodhome.com...
  • Page 29 Step 18 TPK0008 Line up the groove in Drawer Back (P) with Drawer Bottom (Q) and attach to Left and Right Drawer Sides (N) & (O) using Screws (4). Do NOT over-tighten. Attach Drawer Back (P) to Drawer Support (R) and tighten by turning cam lock clockwise.
  • Page 30 Step 19 TPK3013 TPK3012 Connect Handles (7) to Drawer Front (M) using Screws (5) as illustrated x2. ameriwoodhome.com...
  • Page 31 Step 20 For Masonry, Concrete, or other wall materials: Consult your local hardware store for appropriate anchors to securely attach the safety bracket. IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT.
  • Page 32 Step 21 Carefully insert the Pull Out Drawer (H) into the unit as illustrated. Pull out slide NMMM: Please insert all the drawers into correctly direction by following the draft, interlock system will not function if wrong inserted the drawer. ameriwoodhome.com...
  • Page 33 Step 22 Carefully insert the Lower Drawer (M) x 2 into the unit as illustrated. NMMM: Please insert all the drawers into correctly direction by following the draft, interlock system will not function if wrong inserted the drawer. ameriwoodhome.com...

  • Page 34: Maximum Loads

    Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 45 lbs. 20.4 kg 10 lbs. 4.5 kg Each Drawer Warning: Risk of serious injury to person - do not place a television on this furniture. This furniture is not approved for use with a television.
  • Page 35 We would like to extend a big “Thank You” to all to assemble this our customers for taking the of our customers for taking the time to assemble Seeds product, and to give us your valuable this Ameriwood Home product, and to give us your feedback. valuable feedback ameriwoodhome.com...
  • Page 36 Español BMbiMMMM MMMMMMMMM Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
  • Page 37 Español Referencia del número de hardware (página 11) -Cada pieza tiene un número de pieza único. Consulte el número de pieza apropiado al ponerse en contacto con el servicio de atención al cliente para obtener piezas de repuesto. -Antes de lanzar cualquier embalaje, por favor verifique todo el contenido y asegúrese de que ha recibido todas las partes mencionadas anteriormente.
  • Page 38 Visite el sitio web de su distribuidor local, califique su producto comprado y déjenos algunos comentarios! Nos gustaría extender un gran “Gracias” a todos nuestros clientes por tomarse el tiempo para montar este producto Ameriwood Home, y para darnos sus valiosos comentarios Gracias! ameriwoodhome.com...
  • Page 39 Français capot avant Ce livret d’instructions contient d’importantes informations de sécurité. S’il vous plaît lire et conserver pour référence ultérieure. Ne pas retourner ce produit! Contactez notre équipe de service à la clientèle amical pour aider. Appel: 1-800-489-3351 (gratuit) Visite: www.ameriwoodhome.com BIB( (N (ARM( Ce mobilier peut basculer et causer des blessures graves et / ou la mort.
  • Page 40 Français RéféMMMMM (M MM(éMM (M (MMéMiMM (pMgM 22( -Chaque pièce a un numéro de pièce unique. Veuillez consulter le numéro de pièce approprié lorsque vous contactez le service à la clientèle pour des pièces de rechange. -Avant de jeter tout emballage, vérifiez le contenu et assurez-vous d’avoir reçu toutes les pièces énumérées ci-dessus. BMgM 2B Étape 1 - Insérer correctement les boulons de caméra (1) dans le panneau supérieur (A) et le panel inférieur (D) et serrer complètement.
  • Page 41 Visitez le site Web de votre revendeur local, évaluez votre produit acheté et laissez‐nous vos commentaires ! Nous tenons à remercier chaleureusement tous nos clients d’avoir pris le temps d’assembler ce produit Ameriwood Home et de nous avoir fait part de vos précieux commentaires.
