Page 1: Table Of Contents
WARNING: Read all instructions and installation information before using this product.Failure to do so can result in serious injury. TECATE FIRE PITS INSTRUCTIONS & INSTALLATION INFORMATION MODELS: G-RD -001, G-SQ - 005, F-RE-009, W-RD-002, W-SQ-003, W-RE-007 CONTENTS SECTION 1: WARNINGS AND SAFETY PRECAUTIONS...
Page 2: Section 1: Warnings And Safety Precautions
SECTION 1: WARNINGS AND SAFETY PRECAUTIONS WARNING: ALWAYS TURN OFF GAS AFTER USING THE FIREPIT. NEVER LEAVE GAS ON BETWEEN LIGHTING THE FIREPIT. FAILURE COULD RESULT IN SERIOUS INJURY. WARNING Failure to read and follow this instruction manual prior to installation may result in fire, explosion, property damage, as well as personal injury and/or death.
Page 3: Section 2: Warranty
Pits will not be responsible for any defects caused by misuse, alteration, or abuse. Use of wood or any fuel not approved for the unit will void any and all warranties. Tecate Fire Pits is not responsible for any injury or property damage incurred due to misuse of product.
Page 4: Section 4: Parts List
SECTION 4: PARTS LIST Part # Part Name Qty. 15” Diameter Burner Ring 18” Diameter Burner Plate 65,000 BTU Orifice 3/8” Male Flared Fitting 3/8” Flex Line Hose Gas Key Valve 39”D x 18”H Fire Bowl Black Lava Rock 50 pounds 3/8”...
Page 5: Section 6: Setup And Installation
well as when the cylinder is no connected to the fire pit. The 20-pound propane gas cylinder must include a collar to protect the cylinder valve. Gas Cylinder Transportation • Transport ONE gas cylinder at a time. Do NOT store additional cylinders near your fire feature. Make sure the cylinder is secure and transported in an upright position.
Page 6: Section 7: Operation Of Fire Table
SECTION 7: OPERATION OF FIRE TABLE 1. Turn outside valve half a turn to start the flow of gas by using the key provided. 2. Ignite flame in the bowl with a fireplace starter (not provided). 3. Extinguish flame by turning valve to the off position. Make sure flame is out. 4.
Page 7: Section 9: How To Safely Move Your Fire Pit
Potential Cause: Improper fuel and/or improper air mixture Solution: If foreign items are in the flame pattern, remove. Check for proper orifice sizing. FIREPIT PRODUCING FOUL ODOR Potential Cause: Gas leak Solution: Check seal for gas leak. Contact local gas company for advice. BURNER FLAME IS TOO LOW OR HIGH Potential Cause: Incorrect gas pressure or gas supply Solution: Check for proper gas supply.
Page 8: Section 10: Receiving Checklist
Notify the carrier immediately and Tecate Fire Pits. 4. PH is ONLY responsible for curbside delivery. 5. Once order is delivered curbside, it is an accepted delivery. Tecate Fire Pits accepts no responsibility for moving fire pit to backyard or other desired location.

This manual is also suitable for:

G-sq-005 F-re-009 W-rd-002 W-sq-003 W-re-007
