Heatit Controls 54 304 74 Installer Manual

HEATIT
WIFI PANEL
HEATER/LIST
Installers manual
Heatit WiFi Panel Heater 1000W
54 304 77 / 54 304 87
Heatit WiFi List 1000W
54 304 79*
TABLE OF CONTENTS
1. Introduction
2. Safety advise
3. Installation
4. Add/Remove
5. Factory reset
6. Startup
7. Local settings menu
8. Display menu structure
9. Standby and main screen
10. Temperature shown in
display
11. KWh value in menu
12. Load limit
13. Calibration
14. Brightness
GET THE MYHEATIT APP HERE
PRODUCT
DOCUMENTS
Firmware version Document version
FW 1.0 2024-A
Document date
01.09.2024
Org. doc. date 01.09.2024
Article no. White Article no. Black
54 304 74 54 304 81
54 304 75 54 304 83
54 304 76 54 304 85
54 304 77 54 304 87
54 304 78 54 304 88
54 304 69 54 304 89
54 304 79*
15. Display icons
16. Child lock
17. Disable buttons
18. Open window detection
19. Error codes
20. Safety features
21. Configuration parameters
22. Indicator
23. Dimensions
24. Panel heater controls
25. Disclaimer
26. Cleaning and maintenance
27. Chart - display menu
Product info
1. INTRODUCTION
Heatit WiFi Panel Heater/List is an electrical radiator. The
convector can be controlled using the "MyHeatit" App via
Wi-Fi, Bluetooth (BLE), by the buttons on the top, or through
the open API over Wi-Fi. The convector has a user friendly
interface.
Heatit WiFi Panel Heater has 2 modes; Comfort and Eco.
Heatit WiFi Panel Heater has a modern, slim design and is
aesthetically pleasing. It is easy to install and can be either
mounted on the wall or freestanding on legs (additional
equipment).
The output power can be adjusted from the menu or from the
App. It has child lock and open window detection. The device
has an open API and supports Amazon Alexa and Google
Home (Amazon Alexa and Google Home is pending).
The installer can configure and set up the system via
Bluetooth. After the system is set up, the installer can transfer
the property to the customer. The customer can then transfer
their devices to their Wi-Fi network.
Heatit WiFi Panel Heater has active power metering and it gives
you real time information about your power consumption.
Heatit WiFi panels are supplied both as a traditional convector
and as a skirting panel heater. Heatit WiFi Panel Heaters come
in outputs varying between 400W and 1500W in both white
and black color schemes. Heatit WiFi List only in 1000W.
2. SAFETY ADVISE
READ THIS NOTICE CAREFULLY BEFORE
OPERATING THE APPLIANCE.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
Children of less than 3 years should be kept away
unless continuously supervised.
Children aged from 3 years and less than 8 years shall only
switch on/off the appliance provided that it has been placed
or installed in its intended normal operating position and they
have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards
involved. Children aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance or perform user
maintenance.
WARNING / CAUTION
• Some parts of this product can become
very hot and cause burns. Particular
attention has to be given where children
and vulnerable people are present.
