Axxent AMV7240DSC Operating Instructions Manual

SCOPE OF DELIVERY
• Mixing Amplifier AMV7240DSC
• 19" rack bracket (pre-assembled)
• Mains connection cable
• Adjustment screwdriver
• USB stick with current software
FOREWORD
The axxent AMV7240DSC mixer amplifier is
delivered from the factory with presettings that allow
it to be used immediately in standard sound
reinforcement applications without any further
modifications. For the user, only the front panel
controls are relevant. In addition, the user can recall
the sound parameters stored in memory locations
with the preset push-button.
COMMISSIONING
After unpacking the unit, plug the enclosed protective contact mains cable with the IEC flat plug into the mains
socket of the unit. Before plugging the earthed plug into your mains socket, please make sure that the
"POWER" switch on the right front of the appliance is in the "OFF" position. Then plug in the grounding plug. The main
volume control (MASTER VOLUME) should also be set to zero (completely to the left).
axxent e.K. - Herzbachtal Technology Centre - Zum Wartturm 15 - 63571 Gelnhausen
Fon: (06051) 9165584 - mail@axxent.de - www.axxent.de
®
Operating Instructions
AMV7240DSC
Automatic mixer/amplifier
Unit dimensions:
430x335x88 mm (LxDxH) without rack bracket
Weight:
10.15 kg net, 13 kg shipping weight
All other possible settings, both the ana- logue channel
settings, which can be set via the cover plate on the
top that is to be removed, and the setting of DSP signal
parameters, which can be conveniently set via a
connected computer, are reserved for the installer of
the system.
The user must not open the housing of the
AMV7240DSC for reasons of electrical safety!
1
