- Page 1 Installation Guide VIGI Solar System Controller...
-
Page 2: Table Of Contents
Contents Chapter 1 Overview ———————————— 1 Chapter 2 Installation ——————————— 3 Package Contents ..........3 Safety Precautions ..........3 Installation ...............4 Chapter 3 Configuration —————————— 10 Appendix FAQ ——————————————— 11... -
Page 3: Chapter 1 Overview
Chapter 1 Overview The VIGI solar system controller mainly consists of a horizontal mount (containing controller and modular batter y) and many mounting accessories. The horizontal mount is shown as the following figure. Controller LED Four-pin female connector for connecting a solar panel Load Interface Load Interface #1: 9-12.6VDC... - Page 4 Off: PV panels have no voltage. On: Battery power is higher than 20%. Slow Flashing: Battery power is lower than 20%. Quick Flashing: Intelligent auxiliary heating. Off: Battery is abnormal. • Specifications Items VIGI PS20 VIGI PS30 Type Lithium Battery Capacity 20.8AH 31.2AH Battery Working 9~12.6V...
-
Page 5: Chapter 2 Installation
Chapter 2 Installation Package Contents Make sure that the package contains the following items. Please contact your distributor, if any of the listed items are damaged or missing. The figures are for demonstration only. The actual items may differ in appearance and quantity from what is depicted. -
Page 6: Installation
Installation Step 1. Prepare the solar panel It is recommended to use VIGI solar system controller with VIGI solar panels. Step 2. Determine the installation location Choose a location where the solar panel receives the most sunlight throughout the year. Position the solar panel south-facing in the Northern Hemisphere or north-facing in the Southern Hemisphere. - Page 7 2. Install the angle adjustment bracket to the solar panel bracket using four M8*20 mounting screws. 3. Determine the installation inclination according to the location (the inclination can be determined according to the latitude of the location). Recommended solar panel inclination angles (the following inclination angles correspond to the holes on the mount):...
- Page 8 Latitude Range Recommended Inclination 0-5° 5° 5-15° 15° 15-25° 25° 25-35° 35° 35-45° 45° >45° 55° 4. Fix the solar panel on the mount using the solar panel matching screws (M8*100). Step 5. Install the vertical mount and cameras 1. Install the vertical mount to cross the horizontal mount using PTZ Camera Connector Mounting Screws (M6*20).
- Page 9 M6*20 2. Install cameras on the vertical mount using camera mounting screws (M4*20). For PTZ cameras, use PTZ camera connector mounting screws (M6*20). Different types of mounts have varying access methods, and the corresponding type of bracket should be selected for installation according to the actual situation of the device.
- Page 10 1 Install the PTZ camera connector using M6*20 mounting screws. 2 Install the PTZ camera using M6*20 mounting screws. Note: If the product is used in a windy area, it is recommended to tie VIGI 5-Series cameras directly to the pole to reduce the impact of strong wind on the image quality of the camera.
- Page 11 3. After connecting the camera to the load interface, wrap the connection with over two layers of waterproof tape (not included), as shown below. Note: When using waterproof tape, wrap the first layer, then cut. Apply a second layer, ensuring no gaps between the connection and tape for secure waterproofing. Step 6.
-
Page 12: Chapter 3 Configuration
Step 3. Follow the instructions to finish Quick Setup. 1. Download and install the latest TP-Link VIGI app. 2. Open the app and log in with your TP-Link ID. If you don’t have an account, sign up first. 3. Tap the + button on the top right and follow the app instructions to add the VIGI solar system controller. - Page 13 Appendix FAQ Q1. The controller LED status is abnormal. • SYS LED is off: It may be out of power or the system board is damaged. • LAN LED is off: There is no connection. Check whether the RJ45 interface is firmly connected to the network device.
-
Page 14: Safety Information
EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/... - Page 16 To ask questions, find answers, and communicate with TP-Link users or engineers, please visit https://community.tp-link.com/business to join the TP-Link Community. For technical support, user guides and other information, please visit https://www.tp-link.com/support/?type=smb, or simply scan the QR code. © 2024 TP-Link 7106511514 REV1.0.0...
