CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use. Dust regularly with small
brush or vacuum. Spills should be taken care of immediately before they harden or
stain with a slightly damped sponge.
Part List and Hardware List
PIECE
DESCRIPTION
A
Right Leg Panel
Left Leg Panel
B
C
Seat frame
Back Frame
D
Support Bar
E
Seat Cushion
CSH1
CSH2
Back Cushion
QUANTITY
1X
1X
1X
1X
1X
2X
2X
Model# PAT7095
Product Dimensions:
WARNING
PIECE
DESCRIPTION
Screw: M6 x0.5 x80 mm
HW1
HW2
Screw: M6 x0.5 x45 mm
HW3
Allen key 4
51.97" W x 25.98" D x 25"H
400
QUANTITY
4X
6X
1X
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Safavieh Outdoor ROYA PAT7095
Summary of Contents for Safavieh Outdoor ROYA PAT7095
- Page 1 Model# PAT7095 Product Dimensions: 51.97" W x 25.98" D x 25"H CARE AND MAINTENANCE Store outdoor furniture indoors or cover well when not in use. Dust regularly with small brush or vacuum. Spills should be taken care of immediately before they harden or stain with a slightly damped sponge.
- Page 2 Step 2 Step 1 A�ach Le� leg Panel(B) and Right Leg panel(A)to back frame (D) Tighten screw (HW2) with allen key (HW3) to a�ach back frame(D). and Support bar(E), use screws (HW1), �ghten with allen key (HW3). Complete.
- Page 3 CSH2 CSH2 CSH1 CSH1 t S p e t S p e Attach the Seat Panel (C) into the Chair as shown in picture above. Put Seat Cushion (CSH1) and Back Cushion (CSH2) on the Chair. A x the Seat Panel (C) to the Chair using Screws(HW2) and the Allen (HW3). The Chair is ready to be used Note: Insert the Screws(HW2) from the inside to the outside of the Seat Panel(C)
