VIS-LED 2

for ZEISS microscopes

Operating Instructions

Helmut Hund GmbH

Artur-Herzog-Str. 2

D-35580 Wetzlar

Germany

Tel. +49 (0) 6441 2004-0, Fax -44

www.hund.de

Technical specifications subject to changes without notice. Possible errors are uninten-

tional. The actual product may differ from the illustration but will be similar to it.

Art.-Nr. 901.3900.1/Rev.: 1.0

August 2024

Table of Contents

Need help?

Do you have a question about the VIS-LED 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hund Wetzlar VIS-LED 2

Page 1 VIS-LED 2 for ZEISS microscopes Operating Instructions Helmut Hund GmbH Artur-Herzog-Str. 2 D-35580 Wetzlar Germany Tel. +49 (0) 6441 2004-0, Fax -44 www.hund.de Technical specifications subject to changes without notice. Possible errors are uninten- tional. The actual product may differ from the illustration but will be similar to it.
Page 2 Rev.: 1.0 - 2 - August 2024...
Page 3: Table Of Contents
Environmental Conditions .................. 6 Unpacking and Installation ................. 6 LED Illuminator VIS-LED 2: Overview ............. 10 Operating the VIS-LED 2 ................. 11 How to keep the VIS-LED 2 clean ..............12 Troubleshooting ....................13 Technical Specifications .................. 14 Warranty ......................15 Waste Disposal Remark ..................
Page 4: General Remarks
We recommend that you keep this manual together with the instru- ment for quick reference. Whenever the VIS-LED 2 needs to be sent back to the factory, e.g. in case of repairs or for maintenance purposes, please make sure that the instrument is cleaned and disinfected (if neces- sary).
Page 5: Symbols Used Throughout This Manual
Symbols used throughout this Manual Special remarks in this manual are indicated by one of the following symbols: Safety remark Caution! Faulty operation may lead to damage of the mi- croscope and/or its accessories! Danger! Hazardous voltages! Explaining remark Rev.: 1.0 - 5 - August 2024...
Page 6: Environmental Conditions
Unpacking and Installation The illuminator VIS-LED 2 is adjusted in the factory and shipped in a secure packing. After opening the packaging, please make sure that the delivery is complete, and that the illuminator has not been damaged during transport.
Page 7 ZEISS. In ei- ther case, microscope or external power supply unit may already be switched on when the illuminator is connected. Select the VIS-LED 2 on the stand TFT monitor or the Micro Toolbox software, if applicable.
Page 8 Fig. 1: Mounting the VIS-LED 2 The VIS-LED 2 must only be operated with the pre- installed connector and only in combination with a ZEISS microscope! Do not modify cable or connector! • Optional: Connect the BNC connector of the trigger input at the back of the illuminator housing with the trigger output of the trigger source.
Page 9 The illuminator VIS-LED 2 must not be operated with a dangerously live voltage according to DIN EN IEC 61010-1! The trigger input of the VIS-LED 2 may only be con- nected to the trigger source through the BNC cable contained in the scope of delivery of the trigger box!
Page 10: Led Illuminator Vis-Led 2: Overview
LED Illuminator VIS-LED 2: Overview back 1 Illuminator housing with cooling ribs 2 Light-emitting aperture 3 Cable with 3-pin connector 4 BNC connector for trigger input Rev.: 1.0 - 10 - August 2024...
Page 11: Operating The Vis-Led 2
Operating the VIS-LED 2 The illuminator VIS-LED 2 can only be operated with ZEISS microscopes or with ZEISS-certified external power supplies. Risk of fire: To avoid overheating, do not cover the VIS-LED 2 during operation, (e. g. with a dust cover)! The configuration of a trigger (level high/low, flanks rising/falling) needs to be set in the ZEN software.
Page 12: How To Keep The Vis-Led 2 Clean
In case of stronger contaminations, optical surfaces can be cleaned with a soft cloth, moistened with pure alcohol. The housing of the VIS-LED 2 can be cleaned with a soft cloth, wettened with isopropyl alcohol. During the cleaning procedure, please make sure that no...
Page 13: Troubleshooting
Troubleshooting The illuminator VIS-LED 2 requires only an absolute minimum of action by the user. In case of a malfunction, i.e. if no light is emitted or the illuminator reacts unexpectedly to control commands from the software, please contact our Technical Service Department by calling +49 6441 20040 or by sending a mail to info@hund.de.
Page 14: Technical Specifications
Technical Specifications Dimensions (diameter x length): 65 mm x 82.5 mm Weight: ca. 580 g Power supply: through ZEISS microscope or external ZEISS-certified power supply unit > 25’000 h Operating lifetime: 3.25 … 12 V DC Operating voltage: Operating current: 1 A (max.) Power consumption: 12 W (max.)
Page 15: Warranty
Max. altitude: Degree of contamination: Warranty The VIS-LED 2 may only be used for the purposes described in this manual. No liability can be accepted for any other application. The appliance manufacturer guarantees that the appliance is free from materi- al and manufacturing defects at the time of delivery.
Page 16: Waste Disposal Remark
The VIS-LED 2 must only be serviced by the manufacturer’s Technical Service or by persons specially authorised by them. No maintenance or repair work may be carried out on the VIS-LED 2 unless specifically stated in these operat- ing instructions. If faults occur on the device, please contact our Technical Service first.
Page 17: Appendix A: Device Markings
