REVENTA ZEW Professional 1300 Mounting Instructions

Mounting instructions Safety information
1. Basic safety information
Please read these instructions through carefully
and always keep them to hand in the same place,
in the vicinity of the system. All persons who
operate, clean or maintain the system must be
familiar with the contents of these instructions. If
these instructions should become damaged or lost
it is possible to request a replacement copy from
REVENTA .
®
These mounting and operating instructions contain the most important
information with which to operate the system safely.
1.1 Obligations and liability
Observe the information in the mounting and operating instructions:
A basic prerequisite for the safe handling and fault-free operation of
this system is knowledge of the basic safety information and the safety
regulations.
These mounting and operating instructions - in particular the safety
information - must be observed by all persons who work on this system.
Furthermore, the rules and regulations governing accident prevention
applicable at the site of installation also apply.
1.1.1 Dangers when handling the system
The exhaust air duct system has been constructed in accordance with
the latest engineering practice and the recognised health and safety
regulations. However, danger to the life and physical condition of the user
or third parties or impairments to the system or other property can occur
during its use. The system is only
• to be used for the intended purpose and only
• when in safe and faultless
working order.
Malfunctions that may affect safety must be rectified immediately.
1.1.2 Warranty and liability
Warranty and liability claims in the case of personal injury or material
damage are voided if such claims are attributable to one or more of the
following causes:
• Inappropriate use of the system
• Unprofessional assembly, commissioning, operating or maintenance of
the system
• Operating the system with defective safety equipment, or with safety or
protective equipment which has been incorrectly installed or which is not
in proper working order
• A failure to observe information in the operating instructions regarding
transport, storage, assembly,
• commissioning, operation, maintenance and equipping the system
• Unauthorised modifications to the system
• Unauthorised modification of the exhaust air duct (e.g. drive parameters:
capacity and speed)
• Unauthorised changes to a machine or software exclude the manufac-
turer's liability for any damage resulting from this
• Deficient inspection of system parts that are subject to wear and tear
• Improperly executed repairs
• Disastrous events due to the effects of foreign objects or force majeure.
Status 27.06.2018, technical changes and further development reserved.
REVENTA GmbH | Im Gewerbegebiet 3 | D-48612 Horstmar | Phone: +49 (0) 25 58 / 93 92 0 | www.reventa.de
│
1.2 Safety symbols
You will come across the following symbols when reading the mounting
and operating instructions:
Warning of general danger
Warning of dangerous electricity
1.3 Special safety information
The following signs are used for hazards in the mounting and operating
instructions:
Danger
Attention
Note
1.4 Warning and safety information
You will find the following pictograms on your system. These inform you
of functional residual hazards when handling your system and provide
information to help avoid these hazards.
The information signs must always be clearly visible and must not be
damaged. Clean with a solution of water and cleaning agent if dirtied with
dust, animal excrement, food remains, oil or grease, etc.
If an information sign is attached to a part that is to be replaced with a
new part, ensure this is reattached to the new part.
In addition to the pictograms listed here, other signs may also be attached
to this machine or system. The instructions on them must be observed.
1.4.1 Information and meanings of pictograms
The warning signs attached to the machine or system are illustrated with
pictograms. The personnel responsible for the operation and main-
tenance of the system or machine must be well acquainted with the
symbols shown on the pictograms. Appearance and meanings are listed
below.
This symbol means an immediate
threat of danger to the life and health
of personnel. Disregarding these
instructions can result in serious health
impairments, including life-threatening
injuries.
This symbol indicates a possible
threat to the life and health of
personnel or can lead to damage to the
system. Failure to comply with these
instructions can result in serious health
impairments, or can lead to severe
material damage.
This symbol indicates instructions
for the effective, economical and
environmentally friendly handling of
the system. Failure to comply with
these instructions can cause machine
malfunctions or interference within the
system environment.
E-2618
1
