Solar Radar
Speed Sign
User Manual
Product
Code: MAX-SRS01
Solar Radar Speed Sign with Smile/Sad Face Feedback
User Manual
IntroductIon
The Solar Radar Speed Sign with Smile/Sad Face
Feedback is a radar speed sign equipped with a
24GHz German Doppler radar, an embedded smart
microcontroller, a high-brightness LED display screen
to show smile/sad face and a user LCD screen as
programming interface. The front speed limit panel is
covered by 3M diamond-grade reflective film, increasing
the visual distance range up to 300 meters.
The product can process the speed information provided
from the radar, and will transfer the data to the LED
display together with a happy or sad face in less of 0.1
sec. The use of microwave sensor inside the algorithm
formula makes the system stable all day (including
nighttime) measuring results with high level of accuracy.
Radar speed detection mainly utilises Doppler principle,
when a radar beam with a certain frequency is emitted to
the moving target. The target velocity information carried
by its reflective frequency is different from transmitting
frequency. The difference between the two was named
after Doppler Frequency. The Doppler Frequency is
proportional to the moving speed of the target, on this
account; we can detect the vehicle speed.
In the traffic ways, so many road sections need to restrict
the speed. This product will show a sad face if a vehicle
passed over the limits; in the other situation, a happy
face will reflect that the speed of the current vehicle is
below the established limit. Remind drivers of controlling
speed when a car passes through radar coverage area. It
is usually used in accident black spots and speed-limited
sections, effectively telling drivers their speed on the
alert.
The solar radar speed signs are suitable for a range
of uses and sectors including but not limited to civil
construction, roadworks, mining, manufacturing,
commercial and community areas.
1300 222 862
|
58 Catalano Circuit, Canning Vale WA 6155
accumaxglobal.com.au
sales@accumax.com.au
Advertisement
Table of Contents
Summary of Contents for Accumax MAX-SRS01
- Page 1 Solar Radar Speed Sign User Manual Product Code: MAX-SRS01 Solar Radar Speed Sign with Smile/Sad Face Feedback User Manual IntroductIon The Solar Radar Speed Sign with Smile/Sad Face frequency. The difference between the two was named Feedback is a radar speed sign equipped with a after Doppler Frequency.
-
Page 2: Main Features
Solar Radar Speed Sign with Smile/Sad Face Feedback User Manual Diagram of the System Charger Solar Panel Battery Controller Optional DC-DC AC-DC DC12V to Power Power 5V Power Supply Supply Supply LED Matrix Controller LED Matrix Radar Controller Card Face Card Speed Display... -
Page 3: Technical Specs
Solar Radar Speed Sign with Smile/Sad Face Feedback User Manual Technical Specs Specifications Display Mode: Max displaying speed: 199 Input Voltage: Solar powered, DC12/24V Speed Display: 360mm H x 500mm W Red: 208pcs Green: 208pcs Light Luminous: ≥ 8000 cd/m² Viewing Angle: ±... - Page 4 Solar Radar Speed Sign with Smile/Sad Face Feedback User Manual 4 Installation Guide Name Total Qty Hex Bolt, M12*20 5pcs Solar Panel Bracket, 380*68.5*40mm 1pcs Bracket, 160*35*40mm 3pcs Photovoltaic panel sleeve bracket Hex Bolt, M10*80 6pcs Φ round pole Hex Bol, M10*35 2pcs Nut- M10 8pcs...
- Page 5 Solar Radar Speed Sign with Smile/Sad Face Feedback User Manual 4 Installation Guide Step 1: Use M10 * 40 external hexagonal screws and double-sided flat pads to fix and connect the photovoltaic panel and the photovoltaic panel sleeve bracket (as shown in Figure 2) Step 2: Fix the photovoltaic panel sleeve bracket onto the rod using M8 * 25 external hexagonal screws (as shown in Figure 2)
- Page 6 Solar Radar Speed Sign with Smile/Sad Face Feedback User Manual 4 Installation Guide Before installation, please note: a. The sign fixed on the road is left or right, or just above the road, so that the direction of the radar port is to the car, the tilt angle is not more than 10 degrees.
-
Page 7: Common Problems
Solar Radar Speed Sign with Smile/Sad Face Feedback User Manual Project Case An example of the solar radar speed sign being utilised at one of our customer’s mine sites. In this case, the sign is being used to communicate and monitor speeds on the main site haul road where there is high traffic on entry and exit and risk of serious injury or... - Page 8 Solar Radar Speed Sign with Smile/Sad Face Feedback User Manual Control Card Operating Instructions 7.1 COMPONENTS IO interface SD Card LED display power LED display Date interface Power input Power switch Radar interface RS485 indicator Battery Figure 1 7.2 RADAR BOARD OPERATING GUIDELINES Control Card powered on, and after startup, the LCD screen displays the main screen of Figure 2.
-
Page 9: Radar Check
Solar Radar Speed Sign with Smile/Sad Face Feedback User Manual Control Card Operating Instructions 7.4 LED SET See Figure 3. Note: When the vehicle speed is “0”, the display does not display any characters. When system time is outside the period of working time periods set by user, both the LED display and the speedometer are turned off by system. - Page 10 ENT button to complete the system time modification, see Figure 8. Figure 8 7.6.2 LANGUAGE The system supports Chinese and English language selection, see Figure 9. Figure 9 1300 222 862 sales@accumax.com.au 58 Catalano Circuit, Canning Vale WA 6155 accumaxglobal.com.au...
