Versa Networks CSX4000 Series Install

Install a CSX4000 Series Appliance
This article provides instructions about how to unpack a Cloud Services Switch (CSX) 4000 series appliance and how to
install it.
CSX4000 series appliances have integrated faceplate rack-mount ears for installation into standard 19-inch racks. When
you install a CSX4000 series appliance in a 19-inch rack, allow a minimum of 1-RU space on each side of the appliance
to allow hot air to flow out of the appliance.
When placing a CSX4000 series appliance on a desk, ensure that the vents on the side of the unit are never blocked, to
allow hot air to flow out of the appliance. Covering the vents prevents heat from dissipating out of the appliance, which
can cause the chassis to overheat and then shut down.
Unpack a CSX4000 Series Appliance
The CSX4000 series appliance is packed in a plastic bag, and it is shipped in a cardboard carton, secured with foam
packing material. The carton also contains an accessory box. It is recommended that you unpack the appliance only
when you are ready to install it.
To unpack a CSX4000 series appliance:
1. Open the top flaps of the cardboard carton.
2. Remove from the box the foam packing material holding the appliance and the accessories in place.
3. Remove the accessory box and the appliance from the foam packing material.
4. Remove the accessories from the accessories box.
5. Verify the components against the packing list that is included in the box.
Note: It is recommended that you save the shipping carton and packing material when unpacking the appliance, in case
you need to later move the appliance or return it. See
Packing List for a CSX4000 Series Appliance
The cardboard carton in which a CSX4000 series appliance is shipped contains a packing list. Check the packing list
against the parts that you receive in the shipping carton.
Table 1 lists the parts that are shipped with a CSX4300 or CSX4500 appliance.
https://docs.versa-networks.com/Hardware/Cloud_Services_Switch_4000_Series/03_Planning_and_Installation/03Install_a_C...
How To Return Hardware.
