SafeUseInstructions This product performance is excellent and reliable in the designed range of use, but it's necessary to avoid man-made damage or destroy for the equipment. Read the manual carefully and keep this manual for reference if need afterwards. Do not put the device close to the water sources or damp places.
Product Introduction Brief Introduction The MW-CANFiber600 is a CAN server with 2 CAN ports and 2 Ethernet optical ports. The MW-CANFiber500 is a CAN server with 2 CAN ports and 1 Ethernet optical port.They can provide better communication between the CAN bus and Ethernet, further expanding CAN transmission distance, connection topology.
Interface and indicator light 1.4.1 The Ethernet RJ 45 interface 10Base-T / 100Base-TX adaptive Ethernet RJ 45 interface, supporting automatic MDI / MDI-X connection; the pin distribution refer to the following figure: The pin number Signal name Send Data + (TD +)
The pin number The DC model pin definition The AC model pin definition power input V+ power input L power input V- power input N grounding grounding 1.4.3 CAN interface The CAN interface uses 4-way 5.08mm wiring terminals, and the pin distribution refer to the...
Flash blink: CAN port is sending and receiving data; Blink Slow blink: CAN only received data and no sent data CAN1/CAN2 CAN port does not send or receive data, or data abnormally Specification parameters MW-CANFiber500 & MW-CANFiber600 Backboard bandwidth 1.4Gbps Exchange Cache 768Kbit...
The interface and configuration of all of the following functions are subject to the actual object. MW-CANFiber500: Support 1 Ethernet, 2 CAN. MW-CANFiber600: support 2 Ethernet, 2 CAN, the following are all introduced by this device as an example. The CAN server has a WEB server built in, providing a convenient way to access and configure the CAN server, and users can access it by IE, Firefox or Google browser.
After changing the IP address of the PC, you can access and configure the WEB page of the CAN server through the default IP address 192.168.16.253. Log in to WEB Open the browser and enter the default IP address of the CAN server in the address bar, as shown in Figure 2-2.
Figure 2-4 Main interface of the WEB server Notice: CAN server can be used normally with IE 7.0 or above version, Firefox, Google mainstream browser , but the Google browser is recommended when the device is upgraded. Main page introduction After entering the correct user name and password and successful authentication, enter the main page of WEB.
Figure 2-5 Introduction to the main interface of the WEB server 2.2.1 Function menu On the left side of the page is the function menu area showing all the configurable software functions of the CAN server. The function menu contains device information, CAN configuration, serial port configuration, port information, network address, user password, system information and system management.
Menu item Page mark Page function network address network address Configure the device IP address, the subnet mask, and the default gateway Ping IP address Check whether the network is connected by ping to the device address User password...
Displays some basic information about the current device.As shown in Figures 2-7. Figure 2-7 Device information 2.3.2 Port information Displays the current status of the device port, as shown in Figure 2-8. Figure 2-8 Port information Fast ring network The fast ring network technology is a technology developed and designed for high reliability industrial control network application.
Figure 2-9 Fast ring network configuration page Ring network enabling:Main switch for the fast ring network function Ring network group: ring network group number, the maximum number value is the maximum number of ring network groups supported by the device.
Page 19
The configuration page of the CAN server is shown in Figure Figure 2-10. Figure 2-10 The CAN configuration page The configuration parameters of this interface are detailed in Table 2-2. Table 2-2 Description of the CAN server configuration parameters...
Item Instruction CAN ID filtering The received CAN frames are filtered through the CAN ID, and only CAN frames within the upper and lower limits of the frame ID are received. Working mode Four option modes available: UDP, TCP_Client, TCP_Server and multicast. The default factory setting is UDP mode.
Figure 2-11 CAN Statistics Network address Configure the IP address, IP mask, and default gateway of the device. The default IP address is 192.168.16.253. The network address configuration is shown in Figure 2-12. Figure 2-12 Network Address Ping Check whether the network is connected through the ping operation, as shown in Figure 2-13.
Figure 2-13 Ping Userpassword The WEB server of this device provides three different permissions. The first type is a visitor, which can only view the current various configurations of the device, but cannot modify the configuration. The username and password are both "none" and cannot be modified; The second type is a regular user, which can configure various functional parameters of the device.
Figure 2-14 User Password 2.10 System information The system information includes configurable device names, as shown in Figure 2-15. Figure 2-15 System Information 2.11 System management This system can perform some system operations on the device, including restarting, restoring factory configuration, downloading/uploading configuration files, and upgrading.
Page 24
Figure 2-16 System Management Notice: 1. Restoring will cause all configurations of the device to be restored to the state they were just released. If you want to retain the IP, please check the "Keep Current IP Address" on the right, otherwise the IP address of the device will also be restored to the default configuration 192.168.16.253.
