Summary of Contents for AVCOMM AVC-MCS102
- Page 1 AVCOMM Smart Manhole Cover Sensor AVC-MCS102 User Manual AVCOMM Technologies Inc. 333 West Loop North, Suite 460 Houston, TX 77024, USA｜info@avcomm.us｜www.avcomm.us...
- Page 2 Disclaimer Avcomm reserves the right to make changes to this Manual or to the product hardware at any time without notice. Information provided here is intended to be accurate and reliable. However, it might not cover all details and variations in the equipment and does not claim to provide for every possible contingency met in the process of installation, operation, or maintenance.
-
Page 3: Table Of Contents
Index 1 Overview ..................................1 2 Function of AVC-MCS102 Smart Manhole cover Sensor ................1 3 Install NB-IoT SIM Card ............................2 4 Power On ..................................3 5 Reboot Sensor by Magnet ............................3 6 Installation ................................... 4 6.1 AVC-MCS102 Sensor housing installation ..................... 4 6.2 Install AVC-MCS102 sensor to manhole cover .................. -
Page 4: Overview
(not moved). Full/Empty detection: AVC-MCS102 sensor measure the distance from sensor to liquid level. When the distance is less than this threshold 30cm(default), we think the manhole is full, if more than this threshold, think the manhole is empty. -
Page 5: Install Nb-Iot Sim Card
NB-IoT Sim card: Micro card. Insert NB card: sensor use self-elastic card slot, please find the card slot and insert the SIM card, as the following picture, AVCOMM Technologies Inc. 333 West Loop North, Suite 460 Houston, TX 77024, USA｜info@avcomm.us｜www.avcomm.us... -
Page 6: Power On
Move the magnet on the top cover and remove the magnet. This will reboot sensor. If the device is successfully rebooted, the device will report a data after 1min. AVCOMM Technologies Inc. 333 West Loop North, Suite 460 Houston, TX 77024, USA｜info@avcomm.us｜www.avcomm.us... -
Page 7: Installation
When sealing, pay attention to the power cord, do not press the cord. Avoid damage. 3 After installation, the gap between the upper and lower covers is less than 0.5mm, which has achieved the purpose of waterproofing. AVCOMM Technologies Inc. 333 West Loop North, Suite 460 Houston, TX 77024, USA｜info@avcomm.us｜www.avcomm.us... -
Page 8: Install Avc-Mcs102 Sensor To Manhole Cover
Drilling: Punch holes in the manhole cover according to the installation holes of the device and fix the sensor on the manholecover with screws. Initialization: After correctly installing the AVC-MCS102 sensor on the manhole cover, you can use the magnet to restart the sensor, then place the manhole cover on the well within one minute. -
Page 9: Quick Start
Default detection time interval is 10min, therefore, need to wait serval minutes, wait sensor detect the status, or report. Please do not move or turn over the AVC-MCS102 sensor to avoid triggering a move alarm and failing to measure accurate height values when you change the distance for testing the full/empty status. - Page 10 1 minute. After 1 minute, the device starts to initialize and reports data. At this time, the position is set to the initial position and the angle is 0° AVCOMM Technologies Inc. 333 West Loop North, Suite 460 Houston, TX 77024, USA｜info@avcomm.us｜www.avcomm.us...
