S1700, S2700, S3700, S5700, and S6700 Series
Switches
Quick Start Guide
Issue
03
Date
2023-10-26
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S1700 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Huawei S1700 Series

  • Page 1 S1700, S2700, S3700, S5700, and S6700 Series Switches Quick Start Guide Issue Date 2023-10-26 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
  • Page 3: Table Of Contents

    Contents 1 Packing List..........................1 2 Installing the Device....................... 2 3 Connecting Cables........................6 4 Powering On the Device......................8 5 Logging In to a Device for the First Time................9 Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 4: Packing List

    Installation accessory package: The accessory package may contain the ground cable, mounting brackets, screws, dust plugs, rubber pads, and the Documentation Roadmap & Qualification Card . Floating nuts and M6 screws need to be prepared by the customer. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 5: Cabinet Mounting

    Use M4 screws to attach mounting brackets to the device. Install floating nuts on the mounting rails of the cabinet. Install the device in the cabinet. Figure 2-1 Installing a device in a cabinet using front mounting brackets Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 6: Desktop Mounting

    In this case, you do not need to install rubber pads.) Place the device gently on the desk. (Optional) Install a security lock to lock the switch to the desk. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 7: Wall Mounting

    Make the switch incline forward with the bottom away from the DIN rail, and place the fixture on the top of the DIN rail. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 8 The spring latch then bounces back to fix the switch on the DIN rail. NO TE If the spring latch is too tight to move down, you can pull down the spring latch during the installation. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 9: Connecting Cables

    S1700, S2700, S3700, S5700, and S6700 Series Switches Quick Start Guide 3 Connecting Cables Connecting Cables After installing the device, connect the ground cable, power cable, management cable, and service cables to the device. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 10 Switches Quick Start Guide 3 Connecting Cables NO TE The device in the preceding figure is for reference only. The actual port positions and cables vary depending on the device model. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 11: Powering On The Device

    Turn on the external power supply to power on the device. Check the device after powering it on. When the device is operating properly, the power indicator is steady green and the SYS indicator blinks green slowly. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 12: Logging In To A Device For The First Time

    The table below uses V200R022C00 and V600R023C00 as an example. You can also obtain the default IP address and method for logging in to the web system for the first time from the nameplate at the bottom of the device. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 13 The default IP address is the IP address of VLANIF 1. – At the first login, you need to set the username and password for logging in to the device. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 14 IP address and interface for logging in to the switch through the web system. ip-address : port in the address box of ● Enter https:// the browser to log in to the device. Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
  • Page 15 S5700 and S6700 V600R022C10 Configuration running V600 Guide - Basic Configuration S5700 and S6700 V600R023C00 Web-based Configuration Guide S3700 running V600 S3700 V600R022C10 Configuration Guide - Basic Configuration S3700 V600R023C00 Web-based Configuration Guide Issue 03 (2023-10-26) Copyright © Huawei Technologies Co., Ltd.
