  • Page 1 ASUS Service Manual LED Monitor 32" VG32UQA1A...

  • Page 2: Copyright Information

    ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement. This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
  • Page 3 Table of Contents Description Page SAFETY PRECAUTIONS..................... 1 EXPLODED VIEW ......................2 DISASSEMBLY AND ASSEMBLY PROCEDURES ............. 4 TROUBLE SHOOTING ....................10...

  • Page 4: Revision History

    Revision History Date Revision Page Description 2023/11/16 Initial Release Second Release 2023/12/21 modify the Exploded View of Ch.2...

  • Page 5: Safety Precautions

    1. Safety Precautions Caution To ensure safety from fire, electric shock,injury, harmful for people and MNT , the servicing instructions are for use repair station only. These are mandatory requirements, make sure read the manual before servicing. WARNING Please follow this service manual use of substitute replacement parts which do not have the same, specified safety characteristics, might create shock fire or other hazards.
  • Page 7 Exploded BOM ITEM ITEM_DESCRIPTION PANEL MB TO KEY PAD BD CABLE MB TO KEY PAD BD CABLE MB TO KEY PAD BD CABLE MB TO L/B CABLE HINGE BASE ASSY FRONT BEZEL REAR COVER SCREW-MI M4.0*8.0L DISPLAY BD LED BD MAIN BOARD CONFIDENTIAL –...

  • Page 8: Disassembly And Assembly Procedures

    3. Disassembly and Assembly Procedures 3.1 Disassembly SOP Preparation before disassemble: 1. The person who repairs the machine must wear an electrostatic ring and gloves. 2. Make sure that the repaired table is clean before repairing. 3. Make sure the torque of the screw is correct. 4.
  • Page 9 步骤 3： 拆掉机台内所有的醋酸胶带和导电 胶带，拔除主板上的线材和机台上的线材， 拆除前框上的螺丝，取下主板铁件 Step 3: Remove all the acetic acid tape and conductive tape in the machine, remove the wires on the mainboard and the wires on the machine, remove the screws on the front frame, and remove the iron parts of the mainboard 步骤...
  • Page 10 3.2 Assembly process Descriptions Refer photos 步骤 1： 取 LED 线插在 LED 板接口上面， 将 LED 板安装到前框上面，组装前框 Step 1: Insert the LED cable into the LED board interface, install the LED board on the front frame, and assemble the front frame 步骤...
  • Page 11 步骤 4：将加好的主板装到机台上， 锁附 前框螺丝*9，插 L/B 线、灯条线、FFC 线 到主板接口 ， 贴醋酸胶带，导电胶带， 固定线材和铁件 Step 4: Install the added motherboard on the machine, lock the screws *9 of the front frame, insert L/B wire, light bar wire and FFC wire to the interface of the motherboard, paste acetic tape and conductive tape, and fix the wire and iron parts...
  • Page 12 步骤 7：锁后壳螺丝 Step 7 ： Lock the screws on the rear shell 3.3 Twist force for screw Descriptions Refer photos Twist force: 4.5±0.5kgf.cm (M3.0*4.0L *9PCS) Twist force: 4.5±0.5kgf.cm (M3.0*6.0L 5pcs) Twist force: 3.0-3.5kgf.cm (3.0*6.0L 2PCS) CONFIDENTIAL – DO NOT COPY Page 8 / 10 File No.
  • Page 13 Twist force: 4.5±0.5kgf.cm (M3.0*4.0L 1pcs) CONFIDENTIAL – DO NOT COPY Page 9 / 10 File No. SG-0000957...

  • Page 14: Trouble Shooting

    4. Trouble Shooting Problem Possible Solution Power LED is no t ON Press the Power button to check if the monitor is turned on. Check if the power cord is properly connected to the monitor and the power outlet. Check the Power Indicator function in the OSD menu.
