Summary of Contents for abiLine Be-Tech 501
- Page 1 Be-Tech 501 User Manual CARD...
-
Page 2: Component Overview
Component Overview Rear Panel Front Panel Rubber Gasket Screw Card Spindle Cylinder Magnet Fixing PIn Card Lock Body Overview Battery Cover Fingerprint RFID Card Reader Keypad CARD Reset Button Cylinder Cover Rear Panel Front Panel... -
Page 3: Installation Overview
Installation Overview... - Page 4 Handle Direction Changing Check the door’s opening direction: if the front body is fastened on the left, it’s left opening, and if it is fastened on the right, it’s right opening. Handle Screw Handle Allen Key 1.Loosen the handle screw with allen key; 2.Take out the handle;...
- Page 5 Handle Direction Changing Right Clutch Hole Handle Handle Clutch Screw Clutch Clutch Screw Screw Left Clutch Hole Right Opening Left Opening (Seen backside of the front panel) Front Panel 1.Loosen the clutch screw 2.Fix the clutch screw to the clutch hole according to the opening direction.
- Page 6 Installation Guide Mortise Philip self-tap screw*2 Insert the mortise to the door hole, then fix the mortise with 2 screws. Insert the cylinder to the mortise, then fix the mortise with cylinder screw. Cylinder Cylinder screw Fixing Insert the spindle to the front panel handle hole, insert the fixing pin.
- Page 7 Installation Guide Fixing Bent the fixing pin, make sure the fixing pin can not go out. Spindle Rubber Front panel Gasket cable Front panel Make the front panel cable and spindle get through the rubber gasket, then make the cable get through the door hole and hold the front panel onto the door.
- Page 8 Installation Guide Battery Put in 4*AA batteries. Battery Cover Screw Install the battery cover and fix it with screw.. ST Screw Put the strike box into the door hole, fix the strike plate and strike box with ST screws. Strike Plate Strike Box...
- Page 9 How To Use With App Scan to download the APP Reset the lock Open the battery cover, press the reset button with a small stick for Reset Button 3s, then release the stick and input “0000+#”. Link to App Open the app and choose “Add Lock” program, press any key to active the lock, then press “Next”...
- Page 10 How To Use With App Lock/ Unlock by app Nearby the lock, touch icon to unlock and long press the icon to lock after unlocking. Ekeys You can send 4 types of Ekey. 1.Timed Ekeys; 2.Permanent Ekeys; 3.One-time Ekeys; 4.Recurring Ekeys. Passcodes You can generate 5 types of passcodes.
- Page 11 You can fix that: 1.Admin password; 2.Remote Unlock; 3.Time of Auto Lock; 4.Passage mode; 5.Sound On/ Off; abiline Poland sp. z o.o. Adres rejestrowy spółki Adres do korespondencji +48 730 961 100 NIP 7773229932 ul. Grunwaldzka 519a/2 ul. Kożuchowska 20c biuro@abiline.pl...
