- Page 1 F310 P Technical Manual V1.0 Feitian Technologies Co., Ltd. www.FTsafe.com...
-
Page 2: Table Of Contents
F310 P Technical Manual Content Chapter 1. F310 P ProductTechnical Manual ....................3 ProductTechnical Manual..........................3 Product Appearance ............................3 Specifications ................................ 4 1.3.1 Dimensions ........................................4 1.3.2 Screen ..........................................4 1.3.3 Communication Interface..................................4 1.3.4 Audio ..........................................5 1.3.5 Camera ........................................... 5 1.3.6 SIM card ......................................... -
Page 3: Chapter 1. F310 P Producttechnical Manual
Chapter 1. F310 P ProductTechnical Manual 1.1 ProductTechnical Manual Fei�an F310 P is a smart mobile POS product with PCI PTS6.2 cer�fica�on. It has a stylish and smart design. Connect with smart phone or tablet via Bluetooth interface, you can easily and quickly complete the payment process. -
Page 4: Specifications
F310 P Technical Manual Figure 1 F310 P appearance figure 1.3 Specifica�ons 1.3.1 Dimensions Size: 173mm (L) × 82.5mm (W) × 17.2mm (H). 1.3.2 Screen Use a 6.5-inch screen with a resolu�on of 720*1600 and mul� Touch Panel. 1.3.3 Communica�on Interface RF Band LTE-FDD B2/B4/B5/B7,LTE-TDD B38 ... -
Page 5: Audio
F310 P Technical Manual This device can be connected to smart phone or bluetooth headset through this interface. This device supports GPS. supports TYPE A/B and complies with EMV Contactless L1 and qPBOC L1 standards. 1.3.4 Audio Speaker ... -
Page 6: Magne�C Stripe Card Reader
F310 P Technical Manual 1.3.10 Magne�c Stripe Card Reader The magne�c stripe card must be compliant with ISO/IEC 7811, 7813 standard. The magne�c strip card reader can read data from magne�c track 1, 2, 3 at the same �me, support bi-direc�onal swipe, swipe speed ranges from 10mm/s to 100mm/s. -
Page 7: Features
F310 P Technical Manual 1.3.12 Features Tamper-proof and an�-power-down protec�on Support MK/SK and DUKPT key systems RSA、AES、3DES、SHA-1、SHA-256；Support RSA, AES, 3DES, SHA-1, SHA-256 Support SM2, SM3, SM4 Physical tamper-proof has self-destruc�on func�on Support redevelopment 1.4 Cer�fica�ons... -
Page 8: Installation
F310 P Technical Manual 1.5 Installa�on Step 1. Turning on the device Place the battery, Press the power button. • •If required, remove the protective film from the display. Step 2. Mobile payment application Please follow the instructions provided by your bank or service provider to download the mobile application onto this device. - Page 9 F310 P Technical Manual •To read a contactless card it must be positioned in close proximity to the device over the contactless symbol. •Follow the instructions provided by your bank or service provider to complete the transaction. Troubleshooting In the unlikely event you experience issues with this product, please follow the guidelines below. If this does not resolve the issue, please contact your solution provider for further assistance.
- Page 10 •This device is intended for handheld use only or in an approved cradle/stand. •Dispose any part in an environmentally sound manner and in accordance with local laws. •F310 P product will not be held liable for any damage resulting from user operation that does not comply with the above-stated guidance.
-
Page 11: Fcc Statement
1.6 FCC Statement Any Changes or modifications not expressly approved by the party responsibl e for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference This device must accept any interference received, including interference that may cause undesired operation.
