Summary of Contents for Farmhand TDG55
- Page 2 ITEM # TDG55 2-STROKE GASOLINE POWERED POST DRIVER ASSEMBLY & OPERATING INSTRUCTIONS READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT. This manual provides important information on proper operation & maintenance. Every effort has been made to ensure the accuracy of this manual. These instructions are not meant to cover every possible condition and situation that may occur.
-
Page 3: Table Of Contents
1 piece, 4mm inner hexagon wrench • 1 piece, 5mm inner hexagon wrench • 1 piece, 6mm inner hexagon wrench • • 1 piece, T-shaped inner hexagon wrench 1 piece, straight screwdriver • 1 piece, 8-10mm open wrench • TDG55 2-Stroke Post Driver Instruction Manual... -
Page 4: Part Information / Specifications
Hammer Case button Shock guide Barrel Sleeve Support Plate sleeve Handle sleeve Damping Spring Locating Sleeve Handle Spark Plug Ventilation Door Switch Air Filter Oil Cover Oil Pot Fuel Bubble Steel Cover Throttle Pull TDG55 2-Stroke Post Driver Instruction Manual... -
Page 5: Safety Instructions
17. Before transport, empty fuel inside the oil pot to avoid leakage. 18. Non-professional maintenance staff are prohibited from dismounting post driver to avoid structural damage of parts, shortened service life of post driver or accidents. TDG55 2-Stroke Post Driver Instruction Manual... -
Page 6: Assembly
2.7” Barrel Sleeve to make sure it is tight & secure. Fig. 5) To remove, insert Barrel Removal Tool Fig. 6) Pull hard and wiggle Barrel Sleeve until then rotate Barrel Sleeve. it is removed. TDG55 2-Stroke Post Driver Instruction Manual... -
Page 7: Use And Function
Do not let the recoil handle go back freely. Instead, hold it tightly to avoid injury. When the engine has started, open the choke completely. After idling for approximately 5 minutes, you can start working. TDG55 2-Stroke Post Driver Instruction Manual... -
Page 8: Operation
① Open the Fuel Tank lid. Remove fuel filter from Fuel Tank with a metal hook or pliers. ② When cleaning the fuel filter, clean the Fuel Tank at same time. See Fig.14, 15 and 16. Fig. 15 Fig. 14 Fig. 13 TDG55 2-Stroke Post Driver Instruction Manual... - Page 9 After the machine has been working for 50 hours, the included special grease should be added to the impact cylinder. Open the cover of gear boxes and lubricate the gear and the connecting rod with lubricating oil as shown in Fig. 17, 18, 19. Fig. 19 Fig. 18 Fig. 17 TDG55 2-Stroke Post Driver Instruction Manual...
-
Page 10: Troubleshooting
↓ Serious abrasion in active components → Replace Example 5: The machine is working normally but the work efficiency is very low Rubber ring of impact piston is aged and worn →Replace or renew TDG55 2-Stroke Post Driver Instruction Manual... -
Page 11: Maintenance Cycle
Add oil √ Check √ Silencer Remove carbon deposit √ Check √ Cylinder Cooling Fin Clean √ Check/Adjust the distance √ between electrodes Spark Plug Replace √ Check √ √ Screw and Nut Tighten √ TDG55 2-Stroke Post Driver Instruction Manual... -
Page 12: Parts List
Gas Cap Chain Part No. Name Part No. Name End Cover Rubber Pad Oil Pot Inner Cover Heat Shield Suction Nozzle Screw Assembly M4X8 Gasket Washer 5 Oil Cover Gas Guide Tube Tank Cover Assembly TDG55 2-Stroke Post Driver Instruction Manual... -
Page 13: Parts Diagram
PARTS DIAGRAM TDG55 2-Stroke Post Driver Instruction Manual... - Page 14 Hexagon Socket Head Cap Screw m8×30 Outer-Hexagonal Flange Self-Locking Nut M18×1.5 Handle Connecting Thread Joint Handle Sleeve Handle Soft Sleeve Impact Crank Needle Bearing HK152316 Impact Connecting Rod Retainer Ring Hexagon Socket Head Cap Screw m6×16 TDG55 2-Stroke Post Driver Instruction Manual...
- Page 15 PARTS DIAGRAM 201708 TDG55 2-Stroke Post Driver Instruction Manual...
