VMIC VMIVME-5531M-000
Master VMEbus Fiber-Optic Repeater Link
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
In Stock
Used and in Excellent Condition
Buy Today!
https://www.artisantg.com/65228-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r
Advertisement
Table of Contents
Related Manuals for VMIC VMIVME-5531M-000
Summary of Contents for VMIC VMIVME-5531M-000
- Page 1 VMIC VMIVME-5531M-000 Master VMEbus Fiber-Optic Repeater Link In Stock Used and in Excellent Condition Buy Today! https://www.artisantg.com/65228-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
-
Page 2: Product Manual
VMIVME-5531L VMEbus FIBER-OPTIC REPEATER LINK PRODUCT MANUAL DOCUMENT NO. 500-005531-000 B Revised December 21, 1995 VME MICROSYSTEMS INTERNATIONAL CORPORATION 12090 SOUTH MEMORIAL PARKWAY HUNTSVILLE, ALABAMA 35803-3308 (205) 880-0444 1-800-322-3616 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... - Page 3 VMIC reserves the right to make any changes, without notice, to this or any of VMIC’s products to improve reliability, performance, function, or design.
-
Page 4: Record Of Revisions
RECORD OF REVISIONS REVISION PAGES INVOLVED CHANGE NUMBER DATE LETTER 04/19/94 Release 94-0546 12/21/95 Changes per ECO Pages v, vi, 1-1, 1-2, 96-0052 1-3, 3-1, 3-6, 3-7, 6-1 REV LTR PAGE NO. VME MICROSYSTEMS INT'L CORP. 12090 South Memorial Parkway • DOC. - Page 5 VMIC SAFETY SUMMARY THE FOLLOWING GENERAL SAFETY PRECAUTIONS MUST BE OBSERVED DURING ALL PHASES OF THE OPERATION, SERVICE, AND REPAIR OF THIS PRODUCT. FAILURE TO COMPLY WITH THESE PRECAUTIONS OR WITH SPECIFIC WARNINGS ELSEWHERE IN THIS MANUAL VIOLATES SAFETY STANDARDS OF DESIGN, MANUFACTURE, AND INTENDED USE OF THIS PRODUCT.
-
Page 6: Safety Symbols
SAFETY SYMBOLS GENERAL DEFINITIONS OF SAFETY SYMBOLS USED IN THIS MANUAL Instruction manual symbol: the product is marked with this symbol when it is necessary for the user to refer to the instruction manual in order to protect against damage to the system. Indicates dangerous voltage (terminals fed from the interior by voltage exceeding 1000 volts are so marked). -
Page 7: Table Of Contents
500-005531-000 VMIVME-5531L VMEbus FIBER-OPTIC REPEATER LINK TABLE OF CONTENTS Page SECTION 1. INTRODUCTION FEATURES FOR 6U BOARD ..............1-1 FEATURES FOR 3U BOARD ..............1-1 FUNCTIONAL DESCRIPTION .............1-2 REFERENCE MATERIAL LIST............1-2 SECTION 2. PHYSICAL DESCRIPTION AND SPECIFICATIONS SECTION 3. THEORY OF OPERATION OPERATIONAL OVERVIEW..............3-1 THEORY OF OPERATION ..............3-7 BUS ARBITRATION SIGNALS ............3-7... -
Page 8: List Of Figures
500-005531-000 VMIVME-5531L VMEbus FIBER-OPTIC REPEATER LINK TABLE OF CONTENTS (CONTINUED) LIST OF FIGURES Figure Page 3.1-1 Single Link Application Configuration ...........3-2 3.1-2 Star Configuration ................3-3 3.1-3 Block Diagram of VMIVME-5531M Primary Chassis Repeater Link Board ................3-4 3.1-4 Block Diagram of VMIVME-5531S Secondary Chassis Repeater Link Board ................3-5 3.1-5 Block Diagram of the VMIVME-5531S Secondary Chassis... -
Page 9: Introduction
500-005531-000 SECTION 1 INTRODUCTION FEATURES FOR 6U BOARD VMIC’s VMIVME-5531L Fiber-Optic Repeater Link is a software transparent two-board set, with interconnecting cables that allow the user to effectively extend a VMEbus chassis more than 20-slots. "extended" slots, however, only operational for non-interrupting VMEbus slave modules. The extended slots will not support VMEbus master modules. -
Page 10: Functional Description
500-005531-000 Some of the many unique features of the 3U board are listed below: a. Supports 8-, 16-bit data b. Supports 16-, 24-bit addressing c. VMEbus signals supported: Write*, SYSRESET*, DS0*, DS1*, LWORD* d. Supporting cable lengths from 5 to 6,500 feet NOTE: THIS BOARD DOES NOT USE THE P2 CONNECTOR ON THE VMEbus BACKPLANE, WHEN INSTALLED IN A 6U CARD CAGE. -
Page 11: Physical Description And Specifications
500-005531-000 SECTION 2 PHYSICAL DESCRIPTION AND SPECIFICATIONS REFER TO 800-005531-000 SPECIFICATION Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 12: Operational Overview
500-005531-000 SECTION 3 THEORY OF OPERATION OPERATIONAL OVERVIEW The VMIVME-5531 Link is a high performance, yet easy to use method of inking two or more VMEbus systems together via fiber-optic cable. The Repeater Link is a two-board set which allows VMEbus slave boards residing in one VMEbus chassis to be controlled by a VMEbus master residing in another chassis. - Page 13 500-005531-000 GLOBAL MEMORY PRIMARY VMEbus 1 VMIVME-5531M (MASTER) VMIVME-5531S (SLAVE) SECONDARY VMEbus 2 SLAVE SLAVE SLAVE SLAVE MODULES MODULES MODULES MODULES Figure 3.1-1. Single Link Application Configuration Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 14 500-005531-000 MEMORY CHASSIS PRIMARY VMEbus VMIVME-5531M VMIVME-5531M VMIVME-5531M (MASTER) (MASTER) (MASTER) VMIVME-5531S VMIVME-5531S (SLAVE) (SLAVE) SECONDARY SECONDARY VMEbus VMEbus VMIVME-5531S (SLAVE) SECONDARY VMEbus Figure 3.1-2. Star Configuration Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 15 500-005531-000 Figure 3.1-3. Block Diagram of VMIVME-5531M Primary Chassis Repeater Link Board Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 16 500-005531-000 Figure 3.1-4. Block Diagram of VMIVME-5531S Secondary Chassis Repeater Link Board Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 17 500-005531-000 Figure 3.1-5. Block Diagram of the VMIVME-5531S Secondary Chassis Repeater Link Board (3U) Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 18: Bus Arbitration Signals
500-005531-000 THEORY OF OPERATION VMIVME-5531M VMIVME-5531S each consist three state machines, Taxi Transmitter, Taxi Receiver, Fiber-Optic Transmitter, Fiber-Optic Receiver, random logic, and buffers. The three state machines control the VMEbus interface, the Taxi Transmitter and the Taxi Receiver. BUS ARBITRATION SIGNALS The bus arbitration signals are not repeated over the link because the secondary chassis can only contain slave boards. -
Page 19: Programming
500-005531-000 SECTION 4 PROGRAMMING PROGRAMMING VMIC’s VMIVME-5531L Fiber-Optic Repeater Link software transparent. Boards residing in the secondary VMEbus chassis respond to VMEbus transfers as if they were located in the primary VMEbus chassis. Therefore, the Repeater Link requires no special programming considerations, due to the fact that the address and data signals are transmitted to the secondary chassis. -
Page 20: Configuration And Installation
All claims arising from shipping damage should be filed with the carrier and a complete report sent to VMIC together with a request for advice about the disposition of the damaged item(s). PHYSICAL INSTALLATION... -
Page 21: Cable Installation
500-005531-000 CABLE INSTALLATION The Fiber-optic Repeater Link requires two multimode fiber-optic cables with 62.5 µm core. There must be an ST connector at each end of the cable. Refer to Figure 5.4-1 for the cable connections. 1. Connect one cable from the VMIVME-5531M board connector (TX) to the VMIVME-5531S connector (RX). - Page 22 FIBER-OPTIC CABLES 62.5 µm MULTIMODE ST CONNECTORS VMIVME- VMIVME- 5531S 5531M RESET RX LOCK RX LOCK (CABLE LENGTH TO 2000 METERS) VMIC VMIC VMIVME-5531S VMIVME-5531M Figure 5.5-1. VMIVME-5531L Cable Connection Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 23: Maintenance
No components of adjacent boards are disturbed when inserting or removing the board from the chassis Quality of cables and I/O connections If the products must be returned, contact VMIC for a Return Material Authorization (RMA) Number. This RMA Number must be obtained prior to any return. - Page 24 APPENDIX A ASSEMBLY DRAWING, PARTS LIST, AND SCHEMATIC Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 25 “The Next Generation PLC” Registered Trademarks of VME Microsystems International Corporation: UIOC ® (VMIC logo) ® (I/O man figure) Other registered trademarks are the property of their respective owners. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
