Summary of Contents for Truper GEN-200
- Page 1 Manual Inverter generator GEN-200 2 200 W Maximum starting power GEN-201 2 200 W Maximum starting power Applies for: Codes Items 103278 GEN-200 103279 GEN-201 GEN-200 GEN-201 Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Contents CAUTION Technical data Fuel requirements To get the most out of the tool, extend its lifespan, claim the Electrical diagram warranty if necessary, and avoid General safety warnings serious risks or injuries, please for inverter generators read this manual thoroughly before using the tool. -
Page 3: Technical Data
Technical data GEN-200 GEN-201 Code 103278 103279 Description Inverter generator Electric start inverter generator Engine rated power 2 300 W (3 Hp) Engine 4 cycles Displacement 80 cm (cc) Fuel Gasoline Fuel tank 2 contacts of 120 V AC (single-phase) -
Page 4: Electrical Diagram
Electrical diagram GEN-200 AC socket Yellow Blue Black Black Orange Yellow/Green Pink Yellow/Green Yellow/Green Inverter Unit White Violet White Inverter Blue Unit winding White Black/Red Orange Digital Meter Blue/White Protector/8A Blue Blue Blue DC socket winding (12V/8.3A) Blue Black Black... - Page 5 Electrical diagram GEN-201 NOTE: Due to the constant improvements of this equipment, the cable diagram is referencial. AC socket Yellow Blue Orange Black Black Pink Yellow/Green Yellow/Green Yellow/Green Inverter Unit White White Inverter Unit winding White Violet Blue Black/Red Digital Meter Orange Blue/White Black...
-
Page 6: General Safety Warnings For Inverter Generators
Service Avoid accidental starts. Disconnect all equipment from the Repair the tool at a TRUPER Authorized Service Center using generator before starting it. only identical replacement parts. Unattended power tools with the switch in the on position can cause accidents. -
Page 7: Safety Warnings For The Use Of Inverter Generators
INJURIES, or DEATH. WARNING The battery requires maintenance; if The warnings and precautions discussed in this manual you have any doubts, contact a TRUPER service center. cannot cover all possible conditions and situations that WARNING FIRE OR EXPLOSION. may occur. The operator must understand that common •... -
Page 8: Operator´s Safety
Operator´s safety WARNING CAUTION ELECTRIC SHOCK. This generator Before each use, check for loose or damaged parts, signs of oil or fuel leaks, and any other produces powerful voltage, and electricity CAN KILL YOU. condition that may affect proper operation. Repair or This generator must be properly grounded to help replace immediately all damaged or defective parts. -
Page 9: Parts
Parts Ventilation knob Carrying handle Fuel tank Recoil starter Oil reservoir guard Control panel Spark plug maintenance guard Noise limiting cover Muffler window ENGLISH... -
Page 10: Control Panel
Control panel GEN-200 GEN-201 Energy-saving switch 120 V polarized 120 V polarized 12 V c.c. restart 12 V c.c. restart Choke lever outlets outlets Energy-saving switch button button DC 12V / 0.3A Electric start button Engine start knob USB Type-A and C port... - Page 11 The ground terminal ( ) is designed to prevent electric shocks when connected to the ground cable. starting hot, open (push) the choke lever ( Applies only to GEN-200 The generator must be properly grounded before NOTE: operation. Energy-saving switch...
- Page 12 Control panel Ventilation knob Electric start button The fuel tank cap is equipped with a ventilation knob To start the generator, press the button ( ) with your to prevent fuel leaks. The ventilation knob must be in finger for 3 seconds. the "ON"...
-
Page 13: Start Up
3.5% for every 305 m (1 000 feet) above 2 100 m (6 890 feet) above sea level. Power loss will be more significant if carburetor adjustments are not made. Consult a TRUPER Authorized Service Center for adjustments. Operation control Upper limit •... - Page 14 Start up • Oil is a crucial factor affecting • • Do not overfill the fuel tank above WARNING WARNING performance and lifespan. Use recommended 4-stroke the upper limit. Overfilling will result in engine automotive oil as outlined in the MAINTENANCE section shutdown.
- Page 15 Generator start up (For GEN-200) Pull the choke lever to close the valve. • Perform the operation checklist and remove all loads. • Turn the ventilation knob on the fuel cap to the "ON"...
- Page 16 ON position valve. If the engine runs unevenly (vibrates), push the choke lever to the halfway open position. Then, push it to the fully open position after the engine runs smoothly. This point applies only to the GEN-200. ENGLISH...
- Page 17 Start up Remote start key (GEN-201) 4. Ensure that electrical devices are in the "OFF" position. • Set the engine ignition knob to the RUN position. 5. Connect and turn on electrical devices. • Press and hold the ON button on the remote control for 6.
- Page 18 Start up Wattage reference Electrical device Rated power Starting power 27” (68.5 cm) computer 5-50 5 -50 Energy-saving lamp 1000 1000 Electric grill Computer Appliances Washing machine Refrigerator 1600 3200 Air conditioner 1000 1500 Electric hammer 3000 6000 Impact hammer Power tools Water pump 2200...
-
Page 19: Maintenance
Maintenance It is the operator's responsibility to complete all scheduled maintenance in a timely manner. Correct any issues before operating the generator. Always follow the inspection and maintenance recommendations, as well as the schedules outlined in this manual. WARNING Incorrect maintenance or failure to address a problem before operation can cause malfunction and result in property damage, serious injuries, or DEATH. - Page 20 1. If the generator is operating in very dusty environments, carry out maintenance more frequently. 2. Go to a TRUPER authorized service center to carry out this service. *This only applies to the first oil change. Generator maintenance Type of recommended oil •...
- Page 21 Maintenance WARNING c. Add the recommended oil up to the upper limit The engine is not filled with oil at the indicated on the dipstick. factory. Any operation before it has been properly filled d. Tighten the dipstick completely. with the recommended type and amount of oil can result e.
-
Page 22: Troubleshooting
• Check the capacities of the cord sets or extensions in the control section; cable size in this manual. • Consult customer service if necessary. If problems persist despite taking the recommended corrective actions, contact an Authorized TRUPER Service Center. ENGLISH... -
Page 23: Storage And Transportation
Storage and transportation Storage Transportation The generator should be started at least once every 2 To avoid fuel spills during transport or temporary storage, weeks and allowed to run for at least 20 minutes. Follow the generator should be secured in an upright position in the instructions below for long-term storage if the its normal operating position, with the engine switch OFF. -
Page 24: Notes
Notes ENGLISH... -
Page 25: Authorized Service Centers
Authorized service centers In the event of any problem contacting a TRUPER Authorized Service Center, please see our webpage WWW.TRUPER.COM to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. -
Page 26: Warranty Policy
It includes transportation expenses for the product resulting from its service network compliance. Tel. 800-018-7873. Made in/Hecho en China. Imported by TRUPER, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Tel. 761 782 9100.
