Keith & Koep GmbH 27. February 2006
Trizeps4 and ConXS
Quick-Start-Guide
Version 1.1
This document guides you through the first
steps of using the Trizeps4 running on the
ConXS-Evaluation-Board.
1.0 Introduction
Thank you for purchasing the Trizeps4&ConXS-Evaluation-Kit.
The Trizeps4 is a small and complete SODIMM-size computer. Everything for a
fully working module, like Flash-Storage, RAM etc. is already included and only a
power-supply of 3.3V is needed to run it.
The ConXS-board is designed as motherboard for our SODIMM200-Trizeps-Mod-
ules. It contains several interfaces, and is a good starting point for your own prod-
uct-design. A ligth-version of the ConXS-Board is availlable for use in your
products.
Technical documentation can be found on the CD coming with this Evaluation-
Board and on our FTP-Server [see chapter 4.6]. Sign the Non-Disclosure-Agree-
ment [CD::\Board_Doc\DesignKits\ConXS\nda-conxs-englisch.pdf] to get addi-
tional information, like schematics and VHDL-code.
Support:
Hardware:
Software:
Sales:
2.0 Getting Started
2.1
Evaluation-Kit Contents
Trizeps4-Module
1.
ConXS-Board with display
2.
Power-Supply
3.
Serial Null-Modem-Cable, USB-Cable
4.
CD containing WinCE-Board-Support-Package, Tools and documentation.
5.
hardware@keith-koep.com
software@keith-koep.com
sales@keith-koep.com
1
8
von
Advertisement
Summary of Contents for Keith & Koep Trizeps4
- Page 1 1.0 Introduction Thank you for purchasing the Trizeps4&ConXS-Evaluation-Kit. The Trizeps4 is a small and complete SODIMM-size computer. Everything for a fully working module, like Flash-Storage, RAM etc. is already included and only a power-supply of 3.3V is needed to run it.
- Page 2 <file> or load a file from a storage card. boot pcmcia <file> flash boot. Boots image stored in flash. contr, backlight adjust contrast or brightness of a connected display. Trizeps4 and ConXS Quick-Start-Guide...
- Page 3 Obtain MAC-address of the Ethernet-Controller: „mac“. This will print the cur- rent mac-address. If you wish to change this, enter a new one, else press ESC. (All Trizeps4-modules with Ethernet-Controller have an unique MAC-address shown on the label). Start Cabletron TFTP/BOOTP-Server. Choose BootP-Tab and enter Ethernet- Address, a free IP-Address, and the place, where your image-file resides.
- Page 4 RAM and a WinCE-Image with a size of 12MB, than 52MB free RAM will be reported, if you use the bootloader and only 32MB if you use Eboot. To change the starting address, where eboot will put your image, modify EXECUTABLE_PHYSICAL in mt6_io.inc. ( You will need to rebuild Eboot). Trizeps4 and ConXS Quick-Start-Guide...
- Page 5 The WinCE-BSP helps you in creating your own custom WinCE-images. Prebuild WinCE-Images may be found at [CD::\wince500\Images\CONXS\TRIZEPS- IV\lm8v31] or on our FTP-Server [see chapter 4.6]. Installing the Trizeps4 Board-Support-Package You will need Platform-Builder 5.00 from Microsoft ( free Eval-Versions are availl- able) and our BSP [CD::\wince500\BSP\BSP_TR4CONXS_yyyyQx_z.msi].
- Page 6 For a KITL-connection, you must open Target->Connectivity Options and select „Ethernet“ as transport. Press the Settings-Button next to the listbox. Start your WinCE-Image and wait for the device-name to appear. Select it and close the dia- Trizeps4 and ConXS Quick-Start-Guide...
- Page 7 GUID value in the registry or in the SDK. ActiveSync Tools ActiveSync is a tool, that helps you connect the Trizeps4-Evaluation-Board to your development workstation. Besides the functionality you know from PDA’s or other devices, that use ActiveSync to synchronise your phone-book or download pro- grams, you may also use ActiveSync to debug your program or use some of the remote tools (i.e.
- Page 8 „Build->Set Active Platform...“ “Trizeps500_yyyyQx“ is selected and start a debug-session. Note: On Trizeps4, USB-Host port 2 is disabled during an USB-Slave-connection. KuK-Tools, drvlib_app.dll and the persistant registry drvlib_app.dll is a DLL which contains many useful functions to do device-specific things like reset, storing and erasing the registry and i2c-communication.
