Introduction
Please observe the information and warnings from the user manual.
-
Please refer to the user manual for detailed instructions, conformity and support information.
-
The manual can be found at http://www.odys.de/web/personal-computer_de.html.
Use the hyperlink at „Einstellungen – PC und Geräte – PC-Info".
-
-
There you will also find a guide on how to change the system language.
-
Use the installation assistant to easily configure the device.
Important! Please note, in order to use all features available, a Microsoft user account must be created and it
is necessary to activate your system later on. To reset a forgotten password please visit www.live.com. To
prevent conflicts with other systems we recommend creating a new account. Please close unused apps to
extend the battery lifetime as described on the right. Turn off the device when not in use.
Turning On/Off
To turn on the device, press and hold the Power button on the unit until the status indicator (2) starts to light
up then release. It may take a few minutes to start up the system, please wait before you proceed.
To turn off the device, press and hold the Power button until you see the Power Off screen, click on it and
slide it down to turn off.
Tip: This device will sleep with the screen off if it stays inactive for a few seconds. You can briefly press the
Power button to turn on the screen and wake it up.
Power On and Off the Display
- Shortly press the [Power] button or close the device to turn off the display.
- Press the [Power] button again shortly turn the display on again.
Getting Started
2
11
3
4
5
5
6
8
7
9
1.
Front camera
Front-facing camera for taking avatar pictures.
2.
Status indicator
Device On/Off, Caps Lock. Numlk
3.
Charging indicator
Lights up red while the device is charging.
Turns green when the battery is fully charged.
4.
Power jack
Charge and power the device with the included power adapter.
5.
USB 3.0 connection
Support USB memory and USB devices.
6.
HDMI
To connect an external device.
7.
Headphone jack
Audio output connection for headphones
Note: Speaker output is automatically disabled when headphones
are connected to the player.
8.
Touchpad
9.
Left Mouse Key
10.
Right Mouse Key
11.
Speaker
Charging Battery
The device has a built-in rechargeable battery. No extra battery installation is required.
Just charge the device when it indicates low battery.
To charge the battery, connect the device to any standard wall outlet via the charging socket using the
provided power adaptor. It takes about 3 hours to fully charge the battery.
Note
a. We advice to use only the delivered power adapter with this device.
b. You can operate the device even when it is being charged.
c.
It is recommended to charge the battery before you use the device for the first time.
d. For maximum performance, lithium-ion batteries need to be used often. If you don't use the
ODYS UNIQ 15,6 – Quickstart
1
11
10
device often, be sure to recharge the battery at least once per month.
e. Should the rechargeable battery of the device discharge completely, connect the device (using
the adapter) to the main power source for approximately 5-10 minutes before attempting
normal operation.
f.
In some cases, devices which have been charged for longer periods of time may not be able to be
switched back on. Should this occur you have to make a Reset.
General Safety Precautions
• Do not subject the device to severe impact or drop it from heights.
• Do not use the device in extreme hot or cold, dusty or damp conditions. Do not expose it to direct sunlight.
• Avoid using the device near strong magnetic fields.
• Keep the device away from water and other liquids. In the event that water or other liquids enter the device,
power off the product immediately and clean the device.
• Do not use chemicals to clean the device in order to avoid corrosion. Clean it with a dry cloth.
• We are not responsible for damage or lost data caused by malfunction, misuse, modification of the device or
battery replacement.
• Do not attempt to disassemble, repair or modify the product. This will invalidate the warranty.
• If the device will not be used for an extended period of time, please charge the battery at least once per
month to maintain battery life.
• When the device is being formatted or transferring a file, do not interrupt the connection. Otherwise, data
may be corrupted of lost.
• Please use and install data using the attachments/accessories provided and only according to the
manufacturer's instruction.
• Please refer to the information on the bottom of the device for electrical and safety information before
installing data or operating the device.
• To reduce the risk of fire or electric shock, do not expose this device to rain or moisture. The device should
not be exposed to dripping or splashing. Never place objects filled with liquids, such as vases, on the device.
• There is danger of explosion if the battery is replaced incorrectly. Replacement only with a battery of the
same type and only by trained personnel.
• The battery (battery or batteries or battery pack) should not be exposed to excessive heat such as sunlight,
fire or the like.
• Please follow responsible procedures for battery disposal.
• If the power adaptor is disconnected from the device, the device will remain operable as long as the battery
has sufficient charge.
• The power adaptor is a CLASS II apparatus with double insulation and no external ground is provided.
• Do not leave the device on in a confined space such as a book case or similar. The ventilation should not be
impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains, etc.
• No open flames, such as lighted candles, should be placed on the device.
• Use the device in moderate climates. It is designed for private use only.
Never disconnect the USB cable from your device to the PC during a data transfer or formatting. Correctly
disconnect the device from the operating system. Information loss and malfunctions can occur.
Home screen
Once started, the Windows Desktop will be displayed.
Elements on the Taskbar
Search
Use the search box to search
the internet for certain
terms or to easily locate
device settings and
installed Applications.
Windows Menu
Open the start menu.
Function Bar
Open the Functions-Bar.
Here you may find important information and settings. Alternatively, clicking the appropriate
icon on the Taskbar will also access this menu.
Elements of the Functions-Bar
Enable or Disable WiFi
Activate Airplane Mode
Attention!
All wireless connections will be
disabled.
Select
which notifications you want to
see and hear.
Setup brightness and colour for
nightly work.
Battery status
All settings
Important settings and background
processes may be found here
Battery status and settings
Display and Wireless Network (Wi-Fi) settings
Volume Settings
Click this icon to display all opened Apps side by side. The
active App may also be displayed as the first window in the
list.
Notice: This function is not available when no applications
are running.
Enable or disable Bluetooth.
Enable or disable Battery saver.
Accessibility settings
Volume setting
Edit quick settings
1.0.0
Need help?
Do you have a question about the UNIQ 15,6 and is the answer not in the manual?
Questions and answers
Ich habe den Laptop gerade gekauft. Beim ersten Start funktionierte das w- lan ****
