Summary of Contents for Jio JioExtender JE6801
- Page 1 Welcome to the Digital World of Jio. You are the proud owner of JioExtender...
- Page 2 Index 1 Accessories 2 Introduction 3 Product Specifications 4 Installation 5 LED Indicator 6 Rear Panel Interfaces 7 Device Management 8 Connecting your Devices 9 Safety Instructions 1 Accessories In-box Device LAN Cable Power Adapter 2 Introduction JioExtender offers best in class WiFi6 networking with its extended range design.
-
Page 3: Product Specifications
JioExtender is enabled with the latest Wi-Fi 6 technology. 3 Product Specifications Item Specifications Product Name JioExtender JE6801 Wi-Fi Standard IEEE 802.11b/g/n/ax and 802.11a/ac/ax Wi-Fi Frequency 2.4GHz and 5GHz dual band... -
Page 4: Installation
concurrent Wi-Fi Data Rate (max.) 2.4GHz: 1148 Mbps, 4T4R 5GHz: 4804 Mbps, 4T4R LAN/WAN Interface 5 X RJ45 Gigabit Ethernet Ports Mesh Backhaul Type Wired and Wireless Rated Power Input 12V DC 2.5A 4 Installation STEP 1 | Setup JioExtender AirFiber Home Router is JioExtender compatible. - Page 5 backside of the device. 5 Now, Connect the JioExtender power adapter to the DC Power jack of your JioExtender and then plug the power adapter into an electrical wall outlet, this will power on the JioExtender automatically. Follow the instruction given on the JioHome app screen and click on “Next”.
-
Page 6: Led Indicator
STEP 2 | Guidelines for placement 1 Place the JioExtender on a table about three to four feet in height from the ground. Do not place it in corners. 2 Do not place JioExtender close to the floor, too high up, very close to the home ceiling or under low roof conditions. -
Page 7: Rear Panel Interfaces
Color Indicator Status Description Blue Slow Blink Device is in unpaired state Blue Fast Blink Device is pairing to Home Router Green Device Backhaul Connected Device booting Slow Blink Backhaul Disconnected Fast Blink Resetting to factory defaults 6 Rear Panel Interfaces Rear Panel Interfaces (from Left to Right): RESET Factory Reset button, press for more than... -
Page 8: Device Management
7 Device Management You can setup and manage your home Wi-Fi by using the JioHome App MyNetwork feature. JioHome App, MyNetwork prepares the HomeGateway, during JioExtender setup procedure. Scan QR code or search on Google Play or iOS App Store to download the JioHome app. -
Page 9: Safety Instructions
Check the power supply wires and cables regularly. If any of these appear damaged, replace it immediately by calling Jio Care. 6 Install JioExtender in a well-ventilated environment. Avoid areas with high temperature or direct sunlight to protect the device and its components from overheating.
