- Page 1 ® Assembly Instructions max. 120 kg ~ 120 Min. FSCJOT305/365.01.01 Art No. CJ-OT305-A / CJ-OT365-A Outdoor Trampoline Advanced...
- Page 2 Outdoor Trampoline Advanced...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Installation Location ASSEMBLY General Instructions Assembly of the trampoline 2.2.1 Scope of Delivery 2.2.2 Assembly Instructions Assembly of the safety net 2.3.1 Package contents 2.3.2 Assembly Instructions Assembly of the ladder TRANSPORT AND STORAGE General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions... - Page 4 Outdoor Trampoline Advanced...
- Page 5 Whatever you want to do, you can rely on your cardiojump trampoline! We wish you lots of fun! Further information can be found at www.fi tshop.com.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and fi rst use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
- Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.
-
Page 8: General Information
GENERAL INFORMATION Technical Data Weight and dimensions: Article weight (gross, excl. packaging): Ø 305cm: 43 kg Ø 365cm: 60.5 kg Height inclusive safety net: Ø 305cm | H 253cm Ø 365cm | H 274cm Maximum user weight: Ø 305 & 365 cm: 100kg Use class: H Outdoor Trampoline Advanced... -
Page 9: Personal Safety
Personal Safety ⚠ DANGER The trampoline is not suitable for use by children under the age of 6. Children of 6 years and older can only use the trampoline under adult supervision. Never jump onto the trampoline from other objects, e.g. from a roof. Before you start using the trampoline, you should consult your physician that this type of exercise is suitable for you from a health perspective. -
Page 10: Installation Location
⚠ CAUTION The equipment may only be used for its intended purpose. Every other usage is prohibited and potentially dangerous. The manufacturer/retailer will not be held responsible for damages resulting from incorrect usage or usage not for its intended purpose. Wear suitable clothing while using the trampoline. -
Page 11: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suff ocation for children. Keep children away from the equipment during assembly. ⚠ WARNING The assembly and usage of the trampoline should not be undertaken duing wind, rain and storms, also especially with thunder! We recommend that in these conditions that... -
Page 12: Assembly Of The Trampoline
Assembly of the trampoline 2.2.1 Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. -
Page 13: Assembly Instructions
2.2.2 Assembly Instructions Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fi t properly. Tighten the screws using the tool only when you are instructed to do so. - Page 14 Step 1: Connect two top frames (3) with a T connector (9). Insert one leg extension (5) each into the leg receptacle of the T-connectors (9). Secure the leg extensions (5) with a bolt (7). Step 2: Assemble another T-connector (9) and a leg extension (5) at the end of the frame assembly made in step 1.
- Page 15 Step 3: Spread out the mat (1) inside the frame. Step 4: ⚠ WARNING: Crushing hazard! While attaching the springs, please take care NOT to grip the springs with your hand and only to utilise the spring tensioner tool. While releasing the tension it could lead to crushing between the springs.
- Page 16 Step 5: Place the frame pad (2) over the trampoline so that the springs and the frame are covered. Tie the cords that are on the bottom of the frame pad (2) on the frame. Attach the frame pad (2) to the mat sheet (1) using the rope (10). Outdoor Trampoline Advanced...
-
Page 17: Assembly Of The Safety Net
Assembly of the safety net 2.3.1 Package contents The package contents consists of the following illustrated parts and tools. Check that all parts of the package contents have been delivered. Should a part be missing or transport damages are discovered, please immeadiately contact your contract partner. ... -
Page 18: Assembly Instructions
2.3.2 Assembly Instructions Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE The assembly of this safety net should be carried out by at least two adults! Step 1: Connect the bottom and top poles for the safety net (1 &... - Page 19 Step 2: Connect the fi breglass rods (5) using the connectors (6). Spread the net (4) on the ground. Pass the two lengths of poles (5) through the loops at the top of the net (4).
- Page 20 Pass the rods through the loops of the net and join the poles together at one end. To make the last connection, have one person stand on the opposite side. Push the poles towards the centre of the ring until they line up and make the last connection. Outdoor Trampoline Advanced...
- Page 21 Step 3: Put the net in the right position and attach the ring to the upper poles (2). Start at the entrance and connect one hook to each spring. The remaining hooks can now be attached to the ends of the springs.
-
Page 22: Assembly Of The Ladder
Assembly of the ladder NOTICE Dependant on the model, the number of rungs and screws can vary. Step 1: Place the rung between the two rails as pictured. Step 2: Fasten the rungs, each with two screws, two curved washers and two nuts, onto the rails (see fi gure). Step 3: Hang the ladder on the frame of the trampoline. -
Page 23: Transport And Storage
TRANSPORT AND STORAGE General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. ⚠ CAUTION Should you want to move the trampoline, lift the trampoline with at least one other adult. Lift at the connection points and carry it to the desired location. -
Page 24: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the trampoline and its accessories. ⚠ CAUTION Damaged or worn components may aff ect your safety and the life of the trampoline. Therefore, immediately replace damaged or worn components. In such a case, contact your contract partner. -
Page 25: Disposal
DISPOSAL At the end of its operational life, this equipment cannot be disposed of in normal household waste. Instead, it must be disposed of via an electricals recycling centre. Further information can be obtained from your local authority‘s recycling service. The materials can be recycled as per their symbols. -
Page 26: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more effi cient and pleasant, we recommend that you add suiting accessories to your fi tness equipment. For elliptical cross trainers this could for example be a fl oor mat, which makes your fi tness equipment stand more securely and also protects the fl oor from sweat or silicone spray to keep moving parts in good shape. -
Page 27: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. Enter the serial number in the appropriate fi eld. Serial number: Brand / Category: cardiojump / outdoor trampoline Model Name: cardiojump outdoor trampoline 305 cm / 365 cm Article Number: CJ-OT305-A / CJ-OT365-A... -
Page 28: Parts List
Parts List Trampoline Name Qty. 10’ 12’ 14’ TR800 Trampoline Mat,stitched with V-Rings TR801 Frame Pad TR802 Top Frame TR803 Leg Base TR804 Leg Extension TR805 Springs TR806 Screw TR807 spring tool TR808 T connector TR809 Ropes Safety Net Name Qty. -
Page 29: Exploded Drawing
Exploded Drawing TR815 Galv. Connector TR814 Fiberglass Rod TR813 TR811 Top tube TR812 Sleeve TR801 Frame pad TR800 Trampoline mat TR810 Bottom tube TR805 Spring TR802 Top frame TR808 T connector TR804 Leg extension TR803 Leg base TR809 Ropes TR806 Screws... - Page 30 1. LD001 X 2PCS 1. LD001 X 2PCS 2. LD002 X 2PCS 2. LD002 X 3PCS 3. LD003 X 4PCS 3. LD003 X 6PCS 4. LD004 X 4PCS 4. LD004 X 6PCS 5. LD005 X 4PCS 5. LD005 X 6PCS Outdoor Trampoline Advanced...
-
Page 31: Warranty
WARRANTY Products from cardiojump® are subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 32 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
Page 33: Contact
CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER SUPPORT �� �� �� +49 4621 4210-900 80 90 16 50 00800 2020 2772 +494621 4210 944 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fi tshop.dk info@fi tshop.co.uk �� technik@fi tshop.de �� ��... - Page 34 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Fitshop is Europe’s largest specialist store for www.fi tshop.co.uk home fi tness equipment with currently over 70 www.fi tshop.de/blog stores and one of the world’s most renowned online mail order companies for fi tness equipment.
- Page 36 ® Outdoor Trampoline Advanced...
