Summary of Contents for TRENDnet VIP-L16
- Page 1 1 of 21...
-
Page 2: Table Of Contents
Index Internet Information Services (IIS) Installation ........4 Verifying you have installed Internet Information Services IIS ..... 4 Verifying IIS is working properly ............... 7 Framework .Net v1.1 Installation ............9 Verifying that .Net Framework is already installed ........9 .Net Framework Installation .............. - Page 3 Installation Pre-Requirements Before proceeding VortexIP installation in your server you have to make sure you have installed: Operating System Windows XP Professional • IIS 5.1 (IIS 5.1 must be installed before Microsoft .Net Framework v1.1 If that is not the case you have to uninstall Microsoft .Net Framework v1.1 and install it afterwards.
-
Page 4: Internet Information Services (Iis) Installation
Internet Information Services (IIS) Installation Verifying you have installed Internet Information Services IIS This is an optional package and it comes with Windows CD. To verify if you have it already installed go to: Start ->Control Panel-> Add or Remove Programs. Then press Add or Remove Windows Components And the following screen will pop up. - Page 5 Afterwards go to the item, Services of Internet Information Server (IIS) The press Detail. 5 of 21...
- Page 6 Make sure you have to check the components as show on the screen. And press to accept searching on the CD installation components selected. Make sure you are doing on the road indicated "d: /" or another route if it had more than one reader cds.
-
Page 7: Verifying Iis Is Working Properly
Verifying IIS is working properly Go to Start-> Control Panel-> Administrative Tools Then, double click on Services of Internet Information Server On the Status Bar must say: Active. If you have already installed Windows 2003 Web Edition / Server, make sure you have the license to execute ASP.NET v1.1. - Page 8 To verify this, go to ISS Administrator to the section Services Extensions 8 of 21...
-
Page 9: Framework .Net V1.1 Installation
Framework .Net v1.1 Installation Verifying that .Net Framework is already installed Go to Start->Control Panel-> Administrative Tools. If .Net Framework is already installed, the following icons will be shown: If you do not have these icons, proceed with the installation. .Net Framework Installation Get into the install CD and look for the installer.Net framework or download it from Microsoft’s Web page. - Page 10 Press on any of the links to proceed with the installation, and the following dialog box will appear: Press, Run. Press Yes. Select Accept and then press Install. 10 of 21...
-
Page 11: Verifying Framework .Net V1.1 Sp1 Installation
Once the installation process is finished, press Accept. There is No need to Restart your PC’s Operating System. Then, close Internet Explorer and authenticate yourself again to your VortexIP. Verifying Framework .Net v1.1 SP1 Installation Access the Control Panel, and then go to Add or Remove Programs 11 of 21... - Page 12 Verify you have installed the following package: If you do not have the package installed, you can manually install it looking for the software in the VortexIP CD. You may also download and install carefully the updates related to .Net Framework v1.1 by using Windows Update.
-
Page 13: Vortexip Installation
VortexIP Installation IT IS IMPORTANT DO NO EXECUTE EITHER THE INSTALLER OR THE PROGRAM IF THE USB KEY IS NOT INSTALLED. Once you have pass the pre-requirements, insert the CD or execute Access the CD installation and within the CD to folder VortexIP 2.4.3b Access to the folder VIP2.3.4b For Windows XP Professional: VortexIP_Setup_WinXP_V2.exe... - Page 14 Then select “Administration tools” Then we select “internet information Server Services” 14 of 21...
- Page 15 Then we access SMTP virtual Server and we stop the services 15 of 21...
- Page 16 Once solved this setup process re-run the installer correct as indicated above. Select the Language and press Ok. 16 of 21...
- Page 17 Press Next and read carefully the product’s license: If you agree select, I accept the terms of the license, and press Next. 17 of 21...
- Page 18 Select VortexIP components that you wish to install in your server and press Next. Once the installation is complete, the program will change the script. Press Yes. Then press Yes 18 of 21...
- Page 19 Press Yes Once the installation is completed proceed to restart your Computer. Remember that the USB drive has to be always connected to the server where VortexIP is running. 19 of 21...
-
Page 20: Uninstallation
Uninstall To remove VortexIP installation, go to Control Panel-> Add or Remove Programs: Then, look for VortexIP components as shown on the screen: And press Remove on every single VortexIP component. 20 of 21... - Page 21 21 of 21...
