- Page 1 Nookbox Hybrid Installationsmanual...
-
Page 2: System Specifications
1.1 System Specifications Functions Number of areas Number of on-board wired 16 on-board zones, expandable to up to 64 zones in total zones Number of total wired and 80 per area, 640 in total wireless zones Number of wired keypads (via RS-485 connection) (KP-35-COMBO) Number of users... - Page 3 EU: B1 (2100 MHz) / B5 (850 MHz) / B8 (900 MHz) 3G Frequency RF Frequency F1 868 MHz RF encryption Private Encryption Method RF protocol Nookbox ZigBee protocol ZigBee Pro HA 1.2, 2.4GHz Z-Wave 500 series module Z-Wave protocol 868.40 MHz (EU) Wi-Fi 802.11 b/g/n, 2.4GHz...
-
Page 4: What's In The Box
U-shaped Grommet x4 5.6K Resistor (2 resistors for each zone, 32 resistors for 16 zones in total) Screw x4 Wall Plug x4 Tube Fuse x1 (for SLA Battery Panel Only) Power Cable x1 (for Hybrid-Panel-1-AC110/240V, Hybrid-Panel-3-23/45-AC110/240V Only) -
Page 5: Panel Information
2. Panel Information 2.1. Identifying the parts Top Cover (front view) Cover Fixing Screw LED 1 - Area 1 (Green/Red) Full Arm mode - Red lighting up Home/1/2/3 mode - Red flashing Learning mode - Green lighting up ... - Page 6 Back Cover (internal view)
- Page 7 Please refer to 3.3 Hardware Installation for detail. Ensure to turn off all power supplies including Built-in Power Unit and SLA/NiMH Battery before connecting or removing cables or wires. Don’t connect the SLA Battery & NiMH Battery to the same Hybrid Panel board...
- Page 8 Ethernet Port Room for Backup Battery (For Hybrid-Panel-1 models): room for installing 12V 7A or 12V 4A SLA battery pack to serve as a backup power source. Note: ensure to replace the battery pack within 5 years from the date of manufacture, please refer to NFPA-72, 2002 Edition for detail.
-
Page 9: Power Supply
Don’t use the adaptor and the Built-in Power Unit at the same time. Ensure to turn off all power supplies including Built-in Power Unit and SLA/NiMH Battery before connecting or removing cables or wires. Don’t connect the SLA Battery & NiMH Battery to the same Hybrid Panel board... - Page 10 Keypad Wiring ⚫ The RS485 terminals can connect to a maximum of wired keypads (KP-35-COMBO). ⚫ Connect the Control Panel’s “GND” to the “G” terminal on the KP-35-COMBO. ⚫ Connect the Control Panel’s “485A” to the “A” terminal on the KP-35-COMBO. ⚫...
- Page 11 Zone Wiring (Zone 1 -16) ⚫ The 16 zones can be wired to supervise NC (normally close) or NO (normally open) devices. Connect hardwired devices into any Zone terminal. ⚫ Wire gauge: Minimum 20 AWG, maximum 18 AWG. Do not use shielded wire. ⚫...
- Page 12 Double-End-of-Line Resistor Wiring AUX Power Wiring ⚫ The Control Panel can provide a maximum of 12V 400mA current for hardwired zones, auxiliary output and KP-35-COMBO. ⚫ Min/Max operating voltages for devices/detectors is 11.4VDC -13VDC. ⚫ Please note that the total current should not exceed 400mA, otherwise, an additional power supply is required.
- Page 13 PGM Wiring ⚫ The PGM port can be a voltage output port or a dry contact relay output depending on J24 jumper settings. ⚫ When J24 Jumper Switch is disconnected, PGM port will operate as a dry contact relay output. ⚫...
- Page 14 Bell Wiring ⚫ The total current drawn from the PGM-output and Bell port must not exceed 400mA. Min/Max operating voltages for devices / detectors is 11.4VDC -13VDC. ⚫ Be sure to observe polarity when connecting polarized sirens or bells.
