Summary of Contents for Virtus 62
- Page 1 Virtus Installation Guide Virtus 62, 62.2, 63, 63.2 Components MW6,MW6.2, MT120N, VWB25.4, MXR200.4, MXR300.4V...
-
Page 2: Dear Customer
Thank you for choosing Morel for your car audio speaker solution. Morel prides itself on engineering and producing the best high-fidelity speaker systems. We hope you enjoy your Virtus speakers for years to come. If you have any questions, please contact your Morel dealer or Morel support at... - Page 3 Virtus Components MT120N Tweeter 6.5" Woofer SURFACE OPTIONS VWB25.4 Midrange MXR200.4/MXR300.4V Crossover...
- Page 4 Virtus Woofer, Tweeter, Crossover mounting Unit . MT120N Tweeter Flush Mount CLICK Surface Mount 6.5”: ø141mm (5.55”) VWB25.4 Midrange Crossover 2.5”: ø63 (2.48)
- Page 5 2-WAY System 2-WAY System Wiring 2-WAY System Alignment ACTIVE SET UP Tweeter Use the red jumper Highpass to determinate the tweeter +/- dB level Lowpass Woofer Recommended Active Crossovers 2-Way Component Systems Tweeter HP: 2,800Hz @ 12dB or 24dB slope Woofer LP: 2,800Hz @ 12dB or 24dB slope PASSIVE SET UP TWEETER...
- Page 6 3-WAY System 3-WAY System Wiring 3-WAY System Alignment ACTIVE SET UP (Outputs must be filtered) Tweeter Use the red jumper to determinate the tweeter +/- dB level Highpass Bandpass Midrange Lowpass Woofer Recommended Active Crossover Tweeter HP: 2,800Hz @ 12dB slope Midrange LP: 2,800Hz @ 12dB slope Midrange HP: 500Hz @ 12dB slope Woofer LP: 500Hz @ 12dB slope...
-
Page 7: Specifications
Specifications TWEETER / MIDRANGE VWB25.4 MT120N (62.2) MT120N (62) DRIVER UNIT VIRTUS MW6 VIRTUS MW6.2 90-20000 1800-22000 1800-22000 1200 1200 20 (0.78) 28 (1.125) 28 (1.125) Fiberglass Aluminium Aluminium Copper Copper Copper Double Neodymium Neodymium Neodymium Formed Aluminum Acuflex hand Acuflex... - Page 8 Wishing you many years of sound enjoyment! Morel, Ness Ziona, 70400 Israel. Morel America, Chandler, AZ, USA Tel: +972-8-9301161 Toll free number:1-877-667-3511 Fax: +972-8-9301312 Fax: 1-718-721-1560 E-mail: info@morelhifi.com E-mail: info@morelamerica.com w w w . m o r e l h i fi . c o m...
