Winncare TRITON DUAL 150 User Manual

Height adjustable shower and toilet chair with seat tilt
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Scan the QR code for more information
User Manual
TRITON DUAL 150
Height adjustable shower and
toilet chair with seat tilt
Important Information
The user manual must be read before using
the product.
The user manual is intended for care staff
as well as technicians involved in the service
and maintenance of the product.
Date: 30-01-2024. Version: 1

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the TRITON DUAL 150 and is the answer not in the manual?

Questions and answers

Related Manuals for Winncare TRITON DUAL 150

Summary of Contents for Winncare TRITON DUAL 150

  • Page 1 User Manual TRITON DUAL 150 Height adjustable shower and toilet chair with seat tilt Important Information The user manual must be read before using the product. The user manual is intended for care staff as well as technicians involved in the service and maintenance of the product.

  • Page 2: Table Of Contents

    Contents PURPOSE AND SAFETY ....................3 ......................... 3 URPOSE ...................... 3 AFETY NSTRUCTIONS ........................4 EFORE ........................5 ERMINOLOGY ........................5 NPACKING ........................5 RANSPORT INSTALLATION AND OPERATION ..................6 ....................6 IAGRAMS AND UNCTIONS .......................... 7 OADING ................ 8 MERGENCY TOP AND ANUAL OWERING...

  • Page 3: Purpose And Safety

    PURPOSE AND SAFETY TRITON DUAL 150 is an electrically powered shower and toilet chair with an adjustable seat height and angle. The chair has a lifting capacity of 150 kg and can be used in home care, nursing homes, institutions, and hospitals.

  • Page 4: Before Use

    4. Verify that the chair does not produce abnormal sounds, show signs of wear, or have other defects. 5. If the battery alarm is activated, charge the chair first. 6. Check that the recommended annual service has been performed. If in doubt about the use of the chair, contact Winncare Nordic for advice and guidance.

  • Page 5: Terminology

    TRITON DUAL 150 User Manual 1.6 Transport The TRITON DUAL 150 is most safely transported using its original packaging, which contains handling information. If the product needs to be returned, the original packaging should be used. In the absence of the original packaging, ensure the product is otherwise securely and safely protected during transport.

  • Page 6: Installation And Operation

    INSTALLATION AND OPERATION NOTE: Before use, the battery must be charged (see 2.2). 2.1 Pictogram and Functions Manual Operation: UP. Raises the seat. If the seat is angled between +7° and -5°, pressing the up button will simultaneously tilt the chair to -5°. FORWARD TILT.
  • Page 7 2.2 Charging TRITON DUAL 150 has a removable BAL50 battery that can be charged with the attached cable or in an external charging station CHL50. Regular charging is recommended. NOTE: The battery should be charged at least once every 12 months.
  • Page 8 LED 1 - LED 2 - LED 3 LED status Status during normal use LED 1-3 are constantly lit 75-100% SOC LED1+2are constantly lit 50-75% SOC <50% SOC LED 1 is constantly lit LED 1 changes from green The buzzer activates to yellow and blinks slowly.

  • Page 9: Seat And Backrest

    2.5 Footrest The TRITON DUAL 150 comes with one set of footrests. Attach the footrest by placing it in the vertical tube at the front of the chair, guiding it into place with the vertical pin(a).

  • Page 10: Usage

    USAGE 3.1 Users The TRITON DUAL 150 can be used by users who can walk independently or need assistance to transfer into the chair. If a user needs to be transferred into the chair with, for instance, a ceiling lift, the armrests can be rotated to a vertical position for better access.

  • Page 11: Maintenance

    Disposable wipes containing bactericidal agents can also be used. Strong chemicals and solvents must not be used. TRITON DUAL 150 can also be cleaned in a washing machine or tunnel. All parts, including electronic components, are approved for this. Cleaning in a washing machine or tunnel should be carried out in accordance with EN/ISO 60601-2-52:2009.

  • Page 12: Resetting The Control Box

    Armrest and moving parts: Securely attached, lubricated and moves easily up and down. • PU surface is intact. Screws are tightened (Note: Use "Loctite" if removed/loosened). Footplate: Moves up and down. Height adjustment functions. Easily removable. • Emergency stop: Can be activated and deactivated. •...

  • Page 13: Troubleshooting

    Vaseline or acid-free oil (section 4.1). The lift or tilt actuator is not Defective actuator Order a new actuator from Winncare Nordic. working properly or making unusual noises Control box beeps Actuator has lost position Reset control box (section 5.2).

  • Page 14: Technical Specifications And Dimensions

    TECHNICAL SPECIFICATIONS AND DIMENSIONS a) Height 1119 -1497 mm b) Width 620 mm c) Length 840 mm (1000 mm with footrests) d) Seat height 552-930 mm e) Seat width 460 mm f) Seat depth 430 mm g) Height between armrests and seat 210 mm h) Width between armrests 470 mm...

  • Page 15: Electrical Data

    Electrical data: Battery type Lithium-ion technology: NMC Battery capacity: 2.85Ah Output voltage: 25.7VDC Maximum discharge current 10 A Control box input (Charging) 100-240 VAC, 50/60 Hz, -15% / +10% Control box standby power: Maximum 0.5 W Charging time (First time): 12 hours Charging time (Full) Approx.

  • Page 16: Quality And Environment

    QUALITY AND ENVIRONMENT TRITON DUAL 150 has an expected lifespan of at least 10 years, provided the recommended service inspections are adhered to and the general maintenance and care guidelines are followed. 7.1 Guarantee A 2-year guarantee is offered for the product, on the condition that the recommended annual inspections and maintenance are followed, as outlined under annual inspections, and that this can be documented.

  • Page 17: Accessories And Spare Parts

    Round bedpan with handle + lid 047-10316 Wheel with directional lock including screw/washer/spacer 047-00359 Cross lock between armrests 047-10328 Lockable armrest 047-10331 Crossbar for Triton Dual 150 047-00350 Leg strap for footrest 047-00607 Torso/Hip/Thigh belt 047-10340EU External charging station Warning! Do not use cables or accessories that are not listed, as other cables or accessories may negatively affect performance or cause interference.

  • Page 18: Spare Parts

    Small PU upholstery for headrest 047-10327 Screw set for headrest 047-10321 Backrest PUR upholstery 018-08271 Charging cable/EU plug/TRITON/excl. Velcro and clips 047-10325 Velcro and clips for charging cable Contact Winncare Nordic if a desired spare part is not on the list.
  • Page 20 Manufacturer: Phone: +45 70 27 37 20 (EU) 2017/745 CLASS I Winncare Nordic ApS E-mail: info@winncare.dk EN/ISO 17966:2016 Taarnborgvej 12 C IEC 60601-1-2:2015 4220 Korsør Website: www.winncare.dk UM-910-00806EN Denmark...
